Frigidaire FRT21G3C Factory Parts Catalog
Top-mount refrigerator r134a series
Hide thumbs
Also See for FRT21G3C:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00004.eps N05DBDCKA0.eps N05BBAABA6.eps N05SAAADF11.eps
N05CAAAAA9.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT21G3CW4 FRT21G3CW6 FRT21G3CW7 FRT21G3CW9
R134a
R134a
R134a
white
white
white
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
North America North America North America North America
240572115
240572115
240572115
240379014
240379014
240379014
240568300
240568300
Publication No.
5995422275
04/11/17
(EN/SERVICE/WC)
390
Copyright
R134a
white
115
240398801
240400111
240572115
240379014
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21G3C
©
2004 Home Pr
oducts, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT21G3C
Summary of Contents for Frigidaire FRT21G3C
- Page 1 Product No. FRT21G3CW4 FRT21G3CW6 FRT21G3CW7 FRT21G3CW9 Series R134a R134a R134a R134a Color white white white white Volts Wiring Diagram 240398801 240398801 240398801 240398801 Owner's Guide 240400111 240400111 240400111 240400111 Market North America North America North America North America Energy Guide 240572115 240572115 240572115...
- Page 2 Publication No: 5995422275 FRT21G3C DOOR N05DBDCKA0 11/04...
- Page 3 FRT21G3C Publication No: 5995422275 DOOR Model Index: A FRT21G3C (FRT21G3CW4) B FRT21G3C (FRT21G3CW6) C FRT21G3C (FRT21G3CW7) D FRT21G3C (FRT21G3CW9) POS. NO PART NO. DESCRIPTION 240514607 A B C D Gasket, seal, white, frzr door, magnetic 240514608 A B C D Gasket, seal, white, refr door, magnetic 240534901 A B C D...
- Page 4 Publication No: 5995422275 FRT21G3C CABINET 11/04...
- Page 5 FRT21G3C Publication No: 5995422275 CABINET Model Index: A FRT21G3C (FRT21G3CW4) B FRT21G3C (FRT21G3CW6) C FRT21G3C (FRT21G3CW7) D FRT21G3C (FRT21G3CW9) POS. NO PART NO. DESCRIPTION 240355402 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut, push-on 241523701 A B C D...
- Page 6 Publication No: 5995422275 FRT21G3C SHELVES N05SAAADF11 11/04...
- Page 7 FRT21G3C Publication No: 5995422275 SHELVES Model Index: A FRT21G3C (FRT21G3CW4) B FRT21G3C (FRT21G3CW6) C FRT21G3C (FRT21G3CW7) D FRT21G3C (FRT21G3CW9) POS. NO PART NO. DESCRIPTION 215667501 A B C D Tray, ice cube, plastic 240358003 A B C D Shelf, freezer, full-width, wire 5303299664 A B C D Spacer, shelf...
- Page 8 Publication No: 5995422275 FRT21G3C SYSTEM N05CAAAAA9 11/04...
- Page 9 FRT21G3C Publication No: 5995422275 SYSTEM Model Index: A FRT21G3C (FRT21G3CW4) B FRT21G3C (FRT21G3CW6) C FRT21G3C (FRT21G3CW7) D FRT21G3C (FRT21G3CW9) POS. NO PART NO. DESCRIPTION 240444401 A B C D Condenser, dynamic 218944001 A B C D Drier-filter, R134a System 6* # 240388701 A B C D Wiring Harness, control box...
-
Page 10: Wiring Schematic
Publication No: 5995422275 FRT21G3C WIRING SCHEMATIC 11/04... -
Page 11: Wiring Diagram
FRT21G3C Publication No: 5995422275 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
