- Page 1 Bonded VDSL2/G.fast Wireless AC Gateway Router Model # T3200BV User Guide 0xxx-00xx-000 rev. x...
-
Page 2: Table Of Contents
Table of Contents 1 Introduction Package Contents Minimum System Requirements Features Getting to Know the Gateway Connecting the Gateway 2 Accessing the Home Screen Accessing the Home Screen Icon Bar Connection Status 3 Checking the Gateway’s Status Accessing the Status Screens Connection Status Line 1/Line 2 Status WAN Ethernet... - Page 3 Table of Contents 5 Configuring Firewall Settings Accessing Firewall Settings Firewall IPv6 Firewall Port Forwarding Applications DMZ Hosting IPv6 DMZ Hosting UPnP 6 Advanced Settings Accessing the Advanced Setup Screens Services Blocking Website Blocking Scheduling Access Parental Controls WAN IP Addressing IPv6 WAN Settings LAN IP Settings IPv6 LAN Settings...
- Page 4 Table of Contents IPv6 Ping Test Traceroute IPv6 Traceroute Time Zone Config Download/Upload Upgrade History DLNA Load Customer Default Config Print Server xDSL Diagnostics A Specifications General Wireless Operating Range LED Indicators Power Adapter Environmental Notices Warranty Important Safety Instructions FCC Class B Equipment Important Note on Wi-Fi Contact Info...
-
Page 5: Introduction
Introduction Congratulations on purchasing the T3200BV Bonded VDSL2 /G.fast Wireless AC Gateway Router. The Gateway is a single platform device that supports universal WAN access, FTTN, FTTdp, FTTB, or FTTP. With support for advanced 802.11ac 4x4 WiFi, the Gateway enables blazing fast HD video streaming, with multi-channel HD video throughput. -
Page 6: Features
T3200BV Gateway Features • ADSL2+, VDSL2, G.fast, WAN Ethernet and Fiber in a single CPE • Dual Band WiFi delivering up to 2.3 Gbps with 802.11ac 4x4 5GHz and 802.11n 3x3 2.4GHz • Optimized for IPTV and Video over WiFi •... - Page 7 Introduction Rear Panel The rear panel of the Gateway features 10 ports, and a Reset button. Power Port The Power port is used to connect the Power cord (Model No. CDS036- W120U, made by Adapter Technology Co Ltd) to the Gateway. Reset Button Depressing the Reset button for 10 seconds will restore the Gateway’s factory default settings.
-
Page 8: Connecting The Gateway
T3200BV Gateway DSL Ports (2) The DSL ports are used to connect the Gateway to a DSL wall outlet via DSL cable. For single line DSL, use the DSL 1 port. Connecting the Gateway There are many variables involved when connecting the Gateway, depending on the type of Internet service available. - Page 9 Introduction 1. Get the Gateway and black Power cord from the box. 2. Plug the black Power cord in the black port on the back of the Gateway and then into a power outlet. 3. Plug the yellow Ethernet cable from the box into one of the four yellow Ethernet ports on the back of the Gateway.
-
Page 10: Accessing The Home Screen
Accessing the Home Screen This chapter gives a short overview of the Home screen of the Gateway’s graphical user interface (GUI). Accessing the Home Screen To access the Home screen: 1. Open a Web browser on computer connected, via Ethernet cable, to one of the Gateway’s LAN ports. - Page 11 T3200BV Gateway 2. The Gateway’s Home screen appears. 3. Enter the username admin and the password found on the sticker on the side of the Gateway in the Username and Password text boxes at the top right side of the screen, then click Login.
-
Page 12: Icon Bar
Home Screen Icon Bar At the top of the Home screen is the Icon Bar. Here, you can quickly access the other four main sections of the Gateway’s GUI by clicking on the appropriate icon: Status (see chapter 3 for more details); Wireless Setup (see chapter 4 for more details);... -
Page 13: Checking The Gateway's Status
Checking the Gateway’s Status This chapter explains the options available on the Status screens, which display information about the Gateway’s network connections. Accessing the Status Screens To access the Gateway’s Status screens: 1. Open a Web browser. In the Address text box, type: http://192.168.0.1 then press Enter on the keyboard. -
Page 14: Connection Status
T3200BV Gateway 3. The Connection Status screen appears. From here, all the Status screens can be accessed from the menu on the left. Connection Status Clicking Connection Status from any Status screen generates the Connection Status (see figure, above). Information concerning the devices connected to the Gateway’s network, whether wired or wireless, is displayed here, along with the... -
Page 15: Line 1/Line 2 Status
Status Line 1/Line 2 Status Click Line 1 Status from any Status screen to generate the Line 1 Status screen. This screen displays the Gateway’s DSL connection parameters for DSL Line 1 port. Clicking Line 2 Status genreates the Line 2 Status screen, which displays the con- nection parameters for the Gateway’s DSL Line 2 port. -
Page 16: Wan Ethernet
T3200BV Gateway WAN Ethernet Click WAN Ethernet from any Status screen to generate the WAN Ethernet Status screen. This screen displays the Gateway’s WAN (wide area network) parameters. Routing Table Click Routing Table from any Status screen to generate the Routing Table screen. -
Page 17: Firewall Status
Status Firewall Status Click Firewall Status from any Status screen to generate the Firewall Status screen. This screen displays parameters concerning the Gateway’s firewall. NAT Table Click NAT Table from any Status screen to generate the NAT Table screen. This screen displays the Gateway’s WAN (wide area network) parameters. -
Page 18: Wireless Status
T3200BV Gateway Wireless Status Click Wireless Status from any Status screen to generate the Wireless Status screen. This screen displays the Gateway’s wireless network parameters. - Page 19 Status Advanced Wireless Status Click Advanced Wireless Statistics from the bottom of the Wireless Status screen to generate the Advanced Wireless Statistics screen. This screen displays the Gateway’s additional wireless network parameters. Wireless Monitor Click Modemstatus Wireless Monitor from the bottom of the Wireless Status screen to generate the Wireless Monitor screen.
-
Page 20: Modem Utilization
T3200BV Gateway Modem Utilization Click Modem Utilization from any Status screen to generate the Modem Utilization screen. This screen displays statistics related to the Gateway’s modem operation. -
Page 21: Lan Status
Status LAN Status Click LAN Status from any Status screen to generate the LAN Status screen. This screen displays the Gateway’s LAN (local area network) parameters. ARP Table Click ARP Table from any Status screen to generate the ARP Table screen. This screen displays the Gateway’s ARP (address resolution protocol) table. -
Page 22: Network Devices
T3200BV Gateway Network Devices Click Network Devices from any Status screen to generate the Network - Devices screen. This screen allows the user to scan the Gateway’s networks for new devices at a selected time interval. Interface Statistics Click Interface Statistics from any Status screen to generate the Estimated Interface Statistics screen. -
Page 23: Multicast Statistics
Status Multicast Statistics Click Multicast Statistics from any Status screen to generate the Multicast Statistics screen. This screen displays the Gateway’s multicast statistics. System Log Click System Log from any Status screen to generate the System Log screen. This screen displays the Gateway’s system log, which keeps track of all events that occur on the Gateway. -
Page 24: Configuring Wireless Settings
Configuring Wireless Settings This chapter explains the options provided in the Wireless Settings section of the Gateway’s firmware, including basic and advanced settings, and WPS. Accessing Wireless Settings To access the Wireless Settings screens: 1. Open a Web browser. In the Address text box, type: http://192.168.0.1 then press Enter on the keyboard. -
Page 25: Basic Settings
T3200BV Gateway 2. The Gateway’s Main screen appears. Enter the user name and password, then click Wireless Settings from the row of icons at the top of the screen. 3. The Basic Settings screen appears, with a menu of other wireless options listed on the left side of the screen. -
Page 26: Advanced Settings
Wireless Advanced Settings Click Advanced Settings from any Wireless Settings screen to generate the Advanced Settings screen. This screen displays a series of settings relating to the advanced capabilities of the Gateway’s wireless network, including compatibility mode, channel width, and WMM power save. -
Page 27: Wps
T3200BV Gateway Click WPS from any Wireless Settings screen to generate the WPS (Wi-Fi Protected Setup) screen, which allows the user to configure WPS by following the onscreen instructions. -
Page 28: Mac Address Control
Wireless MAC Address Control Click MAC Address Control from any Wireless Settings screen to generate the Wireless MAC Authentication screen, which allows the user to configure allow or deny access to the Gateway’s wireless network using the MAC address of the wireless device. -
Page 29: Band Steering
T3200BV Gateway Band Steering Click Band Steering from any Wireless Settings screen to generate the Band Steering Configuration screen, which allows the user to configure the Gateway to automatically connect 2.4GHz and 5GHz wireless devices to the appropriate wire- less network bandwidth. Also, this screen can be used to assign a certain wireless network and/or bandwidth to a particular wireless device. -
Page 30: Configuring Firewall Settings
Configuring Firewall Settings This chapter explains the options provided in the Firewall section of the Gateway’s firmware, including setting up port forwarding and DMZ hosting. Accessing Firewall Settings To access the Firewall screens: 1. Open a Web browser. In the Address text box, type: http://192.168.0.1 then press Enter on the keyboard. -
Page 31: Firewall
T3200BV Gateway 2. The Firewall screen appears, with a menu of other wireless options listed on the left side of the screen. Firewall Click General from any Firewall Settings screen to generate the Firewall screen, as shown in the figure above. To configure basic settings of the Gateway’s firewall,... -
Page 32: Ipv6 Firewall
Firewall IPv6 Firewall Click IPv6 Firewall from any Firewall Settings screen to generate the IPv6 Firewall screen. To set up, follow the onscreen instructions. -
Page 33: Port Forwarding
T3200BV Gateway Port Forwarding Click Port Forwarding from any Firewall screen to generate the Port Forwarding screen. Activating port forwarding allows the network to be exposed to the Internet in certain limited and controlled ways, enabling some applications to work from the local network (game, voice, and chat applications, for example), as well as allowing Internet access to servers in the local network. -
Page 34: Applications
Firewall Applications Click Applications from any Firewall screen to generate the Applications screen. This screen allows the user to designate certain applications to be forwarded, cir- cumventing the usual firewall security settings. If changes are made in this screen, click Apply at the bottom of the screen to save them. -
Page 35: Dmz Hosting
T3200BV Gateway DMZ Hosting Click DMZ Hosting from any Firewall screen to generate the DMZ Hosting screen. The DMZ host feature allows one device on the network to operate outside the firewall to use an Internet service that otherwise would be blocked, or to expose a networked device to all services without restriction or security. -
Page 36: Ipv6 Dmz Hosting
Firewall IPv6 DMZ Hosting Click IPv6 DMZ Hosting from any Firewall screen to generate the IPv6 DMZ Hosting screen. The DMZ host feature allows one device on the network to operate outside the firewall to use an Internet service that otherwise would be blocked, or to expose a networked device to all services without restriction or security. -
Page 37: Upnp
T3200BV Gateway UPnP Click UPnP from any Firewall screen to generate the UPnP screen, which activates UPnP (Universal Plug and Play). To activate, set the preferred UPnP options, then click Apply. -
Page 38: Advanced Settings
Advanced Settings This chapter explains the options available with the Advanced Setup screens, which configure some of the more complex settings on the Gateway. Accessing the Advanced Setup Screens To access the Gateway’s Advanced Setup screens: Open a Web browser. In the Address text box, type: http://192.168.0.1 then press Enter on the keyboard. -
Page 39: Services Blocking
T3200BV Gateway The Services Blocking screen appears. From here, all the Advanced Setup screens can be accessed from the menu on the left. Services Blocking Click Services Blocking from any Advanced Setup screen to generate the Services Blocking screen (see the figure, above). This feature allows the user to block certain services from accessing the Gateway’s network(s). -
Page 40: Website Blocking
Advanced Website Blocking Click Website Blocking from any Advanced Setup screen to generate the Website Blocking screen. This feature allows the user to block certain websites from access- ing the Gateway’s network(s). Follow the onscreen instructions to configure. -
Page 41: Scheduling Access
T3200BV Gateway Scheduling Access Click Scheduling Access from any Advanced Setup screen to generate the Scheduling Access screen. This feature allows the user to schedule access to the Gateway’s network(s) for certain devices. Follow the onscreen instructions to configure. -
Page 42: Parental Controls
Advanced Parental Controls Click Parental Controls from any Advanced Setup screen to generate the Parental Controls Configuration screen. This feature allows the user to allow or prevent access to certain websites for devices on the Gateway’s network. Follow the onscreen instruc- tions to configure. -
Page 43: Wan Ip Addressing
T3200BV Gateway WAN IP Addressing Click WAN IP Addressing from any Advanced Setup screen to generate the WAN IP Address screen. This feature allows the user to set the protocol used by the ISP for Internet access. Follow the onscreen instructions to configure. -
Page 44: Ipv6 Wan Settings
Advanced IPv6 WAN Settings Click IPv6 WAN Settings from any Advanced Setup screen to generate the IPv6 WAN Settings screen. This feature allows the user to set the IPv6 protocol used by the ISP for Internet access. Follow the onscreen instructions to configure. WARNING: This setting should be configured by experienced network technicians only, since any changes could affect the Gateway’... -
Page 45: Lan Ip Settings
T3200BV Gateway LAN IP Settings Click LAN IP Settings from any Advanced Setup screen to generate the LAN IP and DHCP Settings screen. This feature allows the user to set LAN IP and DHCP server settings on the Gateway. Follow the onscreen instructions to configure. -
Page 46: Ipv6 Lan Settings
Advanced IPv6 LAN Settings Click IPv6 LAN Settings from any Advanced Setup screen to generate the IPv6 LAN Settings screen. This feature allows the user to set the IPv6 LAN IP settings on the Gateway. Follow the onscreen instructions to configure. -
Page 47: Dhcp Reservation
T3200BV Gateway DHCP Reservation Click DHCP Reservation from any Advanced Setup screen to generate the DHCP Reservation screen. This feature allows the user to lease a permanent DHCP- allocated address to a client on the Gateway’s network. Follow the onscreen... -
Page 48: Dynamic Dns
Advanced Dynamic DNS Click Dynamic DNS from any Advanced Setup screen to generate the Dynamic DNS screen. This feature allows the user to associate the WAN IP address of the Gateway with a host name. Follow the onscreen instructions to configure. -
Page 49: Dns Host Mapping
T3200BV Gateway DNS Host Mapping Click DNS Host Mapping from any Advanced Setup screen to generate the DNS Host Mapping screen. This feature allows the user to create a static host name for a specified IP address. Follow the onscreen instructions to configure. -
Page 50: Moca Lan Setup
Advanced MoCA LAN Setup Click MoCA LAN Setup from any Advanced Setup screen to generate the MoCA LAN Setup - Basic screen. This feature allows the user to enable privacy settings on the Gateway’s MoCA LAN. Follow the onscreen instructions to configure. WARNING: Enabling or modifying MoCA Privacy Settings will result in the loss of connectivity to all other MoCA devices on the network. - Page 51 T3200BV Gateway Advanced MoCA LAN Click Advanced from the MoCA LAN Setup - Basic screen to generate the MoCA LAN Setup - Advanced screen. This screen allows the user to modify additional MoCA LAN settings. Follow the onscreen instructions to configure.
-
Page 52: Remote Gui
Advanced Remote GUI Click Remote GUI from any Advanced Setup screen to generate the Remote GUI screen. This feature allows the user to access the Gateway’s graphical user interface from a remote location. Follow the onscreen instructions to configure. Remote Telnet Click Remote Telnet from any Advanced Setup screen to generate the Remote Telnet screen. -
Page 53: Dynamic Routing
T3200BV Gateway Dynamic Routing Click Dynamic Routing from any Advanced Setup screen to generate the Dynamic Routing (RIP) screen. This feature allows the user to set up the Gateway on the net- work behind a modem using dynamic routing. Follow the onscreen instructions to... -
Page 54: Static Routing
Advanced Static Routing Click Static Routing from any Advanced Setup screen to generate the Static Routing screen. This feature allows the user to set up the Gateway with static routes. Follow the onscreen instructions to configure. -
Page 55: Admin Password
T3200BV Gateway Admin Password Click Admin Password from any Advanced Setup screen to generate the Admin Password screen. This feature allows the user to change the password for accessing the Gateway’s graphical user interface. Follow the onscreen instructions to configure. -
Page 56: Storage Device Info
Advanced Storage Device Info Click Storage Device Info from any Advanced Setup screen to generate the Storage Service screen. This feature allows storage devices connected to the Gateway to be easily accessed. Any storage devices connected to the Gateway will be listed in the table at the bottom of the screen. -
Page 57: Reboot
T3200BV Gateway Reboot Click Reboot from any Advanced Setup screen to generate the Reboot screen. Reboot the Gateway by clicking Reboot. Restore Defaults Click Restore Defaults from any Advanced Setup screen to generate the Restore Defaults screen. To restore certain settings on the Gateway, click the appropriate... -
Page 58: Speed Test
Advanced Speed Test Click Speed Test from any Advanced Setup screen to generate the Speed Test screen. This screen allows the user to perform a speed test on the Gateway’s Internet (or WAN) connection. Enter the URL for a server at a speed test site, then click Test. -
Page 59: Ping Test
T3200BV Gateway Ping Test Click Ping Test from any Advanced Setup screen to generate the Ping Test screen. To perform a ping test on the Gateway, follow the onscreen instructions. -
Page 60: Iperf Test
Advanced Iperf Test Click Iperf Test from any Advanced Setup screen to generate the Iperf Test screen. To perform an iperf test on the Gateway, follow the onscreen instructions. -
Page 61: Ipv6 Ping Test
T3200BV Gateway IPv6 Ping Test Click IPv6 Ping Test from any Advanced Setup screen to generate the IPv6 PingTest screen. To perform an IPv6 ping test on the Gateway, follow the onscreen instructions. -
Page 62: Traceroute
Advanced Traceroute Click Traceroute from any Advanced Setup screen to generate the Traceroute screen. To perform an route trace on the Gateway, follow the onscreen instructions. IPv6 Traceroute Click IPv6 Traceroute from any Advanced Setup screen to generate the IPv6 Traceroute screen. -
Page 63: Time Zone
T3200BV Gateway Time Zone Click Time Zone from any Advanced Setup screen to generate the Time Zone screen. Use this screen to set the time zone on the Gateway. Config Download/Upload Click Config Download/Upload from any Advanced Setup screen to generate the Configuration Download and Upload screen. -
Page 64: Upgrade History
Advanced Upgrade History Click Upgrade History from any Advanced Setup screen to generate the Upgrade History screen. This screen displays a list of firmware upgrades applied to the Gateway. Click ALG from any Advanced Setup screen to generate the Firwall - ALG / Pass- Through screen. -
Page 65: Dlna
T3200BV Gateway DLNA Click DLNA from any Advanced Setup screen to generate the DLNA screen. This screen allows the user to configure DLNA settings on the Gateway. Load Customer Default Config Click Load Customer Default Config from any Advanced Setup screen to generate the Load Customer Default Config screen. -
Page 66: Print Server
Advanced Print Server Click Print Server from any Advanced Setup screen to generate the Print Server screen. This screen allows the user to select and configure a print server for the Gateway’ s network. xDSL Diagnostics Click xDSL diagnostics from any Advanced Setup screen to generate the xDSL Diagnostics screen. -
Page 67: A Specifications
Specifications General Model Number(s) T3200BV (Wireless 11ac Bonded VDSL2 Modem Gateway) Standards IEEE 802.3 (10BaseT) IEEE 802.3u (100BaseTX) IEEE 802.11 b, g, n, ac (Wireless) G.dmt G.lite t1.413 RFC 1483, 2364, 2516 Protocol LAN - CSMA WAN - , Static... -
Page 68: Wireless Operating Range
T3200BV Gateway Cabling Type Ethernet 10BaseT: UTP/STP Category 3 or 5 Ethernet100BaseTX: UTP/STP Category 5 Wireless Operating Range Indoors Up to 91M (300 ft.) @ 300 Mbps Outdoors Up to 457M (1500 ft.) @ 300 Mbps Topology Star (Ethernet) LED Indicators... -
Page 69: Environmental
Specifications Environmental Power External, 12V DC, 3A Certifications FCC Part 15 Class B, Class C and E, FCC Part 68, UL Operating Temperature 0º C to 45º C (32ºF to 113ºF) Storage Temperature -20ºC to 70ºC (-4ºF to 158ºF) Operating Humidity 10% to 85% non-condensing Storage Humidity 5% to 90% non-condensing... -
Page 70: Notices
Under such local law, certain disclaimers and limitations of this Warranty Statement may not apply to the customer. Go to http://www.actiontec.com/products/warranty.php for more information. Important Safety Instructions Basic safety precautions should always be followed to reduce the risk of fire, electri- cal shock, and personal injury, including the following: •... -
Page 71: Fcc Class B Equipment
• Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Actiontec Electronics, Inc, may void the user’s authority to operate the equipment. -
Page 72: Important Note On Wi-Fi
Notices Declaration of Conformity for Products Marked With the FCC Logo This device complies with part 15 of the FCC. Operation is subject to the following two conditions: 1. This device may not cause harmful interference; 2. This device must accept any interference received, including interference that may cause undesired operation of the device. -
Page 73: Contact Info
If trouble is experienced with this equipment, please contact: Company Name: Actiontec Electronics, Inc. Address: 760 N. Mary Ave., Sunnyvale, CA 94085 TEL:...
