PRODUCT NO.
BASE MODEL NO.
FRT16PRGD0
FRT16PRG
FRT16PRGW0
FRT16PRG
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218613700
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995307534
980521
-EN/SERVICE /JLT
357
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT16PRGW0
FRT16PRGD0
©1998 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT16PRGD0
Summary of Contents for Frigidaire FRT16PRGD0
- Page 1 PRODUCT NO. BASE MODEL NO. FRT16PRGD0 FRT16PRG FRT16PRGW0 FRT16PRG WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218613700 SERVICE DATA SHEET - # 218755000 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR R134a System almond...
- Page 2 Publication No. 5995307534 05/98 FRT16PRGW0, FRT16PRGD0 DOOR P05D0572...
- Page 3 A = FRT16PRG (FRT16PRGD0) B = FRT16PRG (FRT16PRGW0) POS. NO 37A* 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRT16PRGW0, FRT16PRGD0 DOOR PART NO DESCRIPTION 5303288856 Gasket-frzr door,almond ,magnetic 5308007123 Gasket-frzr door,white ,magnetic 5303288857 Gasket-refr door,almond ,magnetic 5318680311...
- Page 4 Publication No. 5995307534 05/98 FRT16PRGW0, FRT16PRGD0 CABINET P05B0357...
- Page 5 A = FRT16PRG (FRT16PRGD0) B = FRT16PRG (FRT16PRGW0) POS. NO 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16PRGW0, FRT16PRGD0 CABINET PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 5303001389...
- Page 6 Publication No. FRT16PRGW0, FRT16PRGD0 5995307534 SHELVES P05S0599 05/98...
- Page 7 A = FRT16PRG (FRT16PRGD0) B = FRT16PRG (FRT16PRGW0) POS. NO 8* # 14 # 16A# 19 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16PRGW0, FRT16PRGD0 SHELVES PART NO DESCRIPTION 218651801 Mullion,almond 218651800 Mullion,white 218781001 Heater-mullion 218279800...
- Page 8 Publication No. FRT16PRGW0, FRT16PRGD0 5995307534 SYSTEM P05C0101 05/98...
- Page 9 A = FRT16PRG (FRT16PRGD0) B = FRT16PRG (FRT16PRGW0) POS. NO 14 # 15 # 21 # 29 # 29 # 30 # 55 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16PRGW0, FRT16PRGD0 SYSTEM PART NO DESCRIPTION...
-
Page 10: Wiring Diagram
Publication No. FRT16PRGW0, FRT16PRGD0 5995307534 WIRING DIAGRAM W193832C 05/98...
