Frigidaire FRT16NRGD0 Factory Parts Catalog

Frigidaire frt16nrgd0: supplementary guide
Hide thumbs Also See for FRT16NRGD0:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
FRT16NRGD0
FRT16NRGW0
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218613700
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624
BASE MODEL NO.
SERIES
FRT16NRG
R134a System
FRT16NRG
R134a System
Publication No.
5995307708
-EN/SERVICE /JLT
FACTORY PARTS CATALOG
REFRIGERATOR
COLOR
almond
white
980527
357
©1998 White Consolidated Industries, Inc.
All rights reserved
VOLTS
115
115
REFRIGERATOR
Model No.
FRT16NRGW0
FRT16NRGD0

Advertisement

loading

Related Manuals for Frigidaire FRT16NRGD0

Summary of Contents for Frigidaire FRT16NRGD0

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT16NRGD0 FRT16NRG FRT16NRGW0 FRT16NRG WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218613700 SERVICE DATA SHEET - # 218755000 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR R134a System almond...
  • Page 2 Publication No. 5995307708 05/98 FRT16NRGW0,FRT16NRGD0 DOOR P05D0573...
  • Page 3 A = FRT16NRG (FRT16NRGD0) B = FRT16NRG (FRT16NRGW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT16NRGW0,FRT16NRGD0 DOOR PART NO DESCRIPTION 5303288856 Gasket-frzr door,almond ,magnetic 5308007123 Gasket-frzr door,white ,magnetic 5303288857 Gasket-refr door,almond ,magnetic 5318680311 Gasket-refr door,white ,magnetic 218359001...
  • Page 4 Publication No. 5995307708 05/98 FRT16NRGW0,FRT16NRGD0 CABINET 8 58 P05B0362...
  • Page 5 A = FRT16NRG (FRT16NRGD0) B = FRT16NRG (FRT16NRGW0) POS. NO 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16NRGW0,FRT16NRGD0 CABINET PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 5303001389 Plug-button,almond...
  • Page 6 Publication No. FRT16NRGW0,FRT16NRGD0 5995307708 SHELVES 05/98...
  • Page 7 A = FRT16NRG (FRT16NRGD0) B = FRT16NRG (FRT16NRGW0) POS. NO 8* # 14 # 16A# 19 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16NRGW0,FRT16NRGD0 SHELVES PART NO DESCRIPTION 218651801 Mullion,almond 218651800 Mullion,white 218781001 Heater-mullion 218279800 Tapping Plate,mullion mtg ,(2)
  • Page 8 Publication No. FRT16NRGW0,FRT16NRGD0 5995307708 SYSTEM P05C0101 05/98...
  • Page 9 A = FRT16NRG (FRT16NRGD0) B = FRT16NRG (FRT16NRGW0) POS. NO 13 # 14 # 15 # 21 # 29 # 30 # 55 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16NRGW0,FRT16NRGD0 SYSTEM PART NO DESCRIPTION 218491000...

  • Page 10: Wiring Diagram

    Publication No. FRT16NRGW0,FRT16NRGD0 5995307708 WIRING DIAGRAM W193832C 05/98...
