Frigidaire FRS26BRDS Factory Parts Catalog

Frigidaire FRS26BRDS Factory Parts Catalog

Side by side refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
ELECTROLUX HOME PRODUCTS, INC.
N58L00001.eps N58FFDEAA0.eps N58RFDAAB2.eps N58BAAAAA0.eps
P.O. Box 212378, Augusta, GA 30917
N58SJCAAB11.eps N58TAAAAA6.eps N58CAAAAA4.eps N58XDAAAA1.eps
N58YBAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps
FRS26BRDSB1 FRS26BRDSB2 FRS26BRDSB3 FRS26BRDSB4
R134a Gallery
R134a Gallery
stain/blk
stain/blk
115
115
241526901
241526901
240581300
240581300
North America
North America
241585951
241585951
240389616
Publication No.
5995424131
04/12/13
(EN/SERVICE/DCS)
357
R134a Gallery
R134a Gallery
stain/blk
stain/blk
115
115
241526901
241526901
240581300
240581300
North America
North America
241585951
241585951
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26BRDS
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26BRDS

Summary of Contents for Frigidaire FRS26BRDS

  • Page 1 North America North America North America 241585951 241585951 241585951 240389616 240389616 SIDE-BY-SIDE REFRIGERATOR Publication No. 5995424131 04/12/13 (EN/SERVICE/DCS) © Copyright R134a Gallery stain/blk 241526901 240581300 North America 241585951 240389616 Model No. FRS26BRDS 2004 Electrolux Home Products, Inc. All rights reserved.

  • Page 2: Freezer Door

    Publication No: 5995424131 12/04 FRS26BRDS FREEZER DOOR N58FFDEAA0...
  • Page 3 218755503 240352102 240552101 5303918256 # Functional Parts * Non-Illustrated Parts FRS26BRDS FREEZER DOOR A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Gasket-frzr door, black, magnetic A B C D Bin-door, frzr-upper...

  • Page 4: Refrigerator Door

    Publication No: 5995424131 12/04 FRS26BRDS REFRIGERATOR DOOR N58RFDAAB2...
  • Page 5 240328404 240356402 218755401 218755503 # Functional Parts * Non-Illustrated Parts FRS26BRDS REFRIGERATOR DOOR A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Gasket-refr door, black, magnetic A B C D Bin-door, pseudo, bottom...
  • Page 6 Publication No: 5995424131 FRS26BRDS CABINET 12/04...
  • Page 7 240350802 240368701 240479601 240481601 5303305345 # Functional Parts * Non-Illustrated Parts FRS26BRDS CABINET A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Cover-air duct A B C D Cover-evap coil, lower A B C D...
  • Page 8 Publication No: 5995424131 12/04 FRS26BRDS SHELVES N58SJCAAB11...
  • Page 9 215005100 218867405 218867406 240430501 241585951 # Functional Parts * Non-Illustrated Parts FRS26BRDS SHELVES A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Shelf-freezer, flip-up A B C D Shelf-freezer, fixed wire A B C D...
  • Page 10 Publication No: 5995424131 12/04 FRS26BRDS CONTROLS N58TAAAAA6...
  • Page 11 149* 241528303 240394102 240376002 # Functional Parts * Non-Illustrated Parts FRS26BRDS CONTROLS A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Fan Blade, red, evaporator fan A B C D Washer, "slinger", nylon, evap fan shaft...
  • Page 12 Publication No: 5995424131 12/04 FRS26BRDS SYSTEM N58CAAAAA4...
  • Page 13 240553501 240346201 240409302 5303918213 5303918222 # Functional Parts * Non-Illustrated Parts FRS26BRDS SYSTEM A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Condenser A B C D Block-evap coil, styrofoam, (2) A B C D...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995424131 FRS26BRDS ICE & WATER DISPENSER 12/04...
  • Page 15 5304421621 5304421615 218515401 5303918256 # Functional Parts * Non-Illustrated Parts FRS26BRDS ICE & WATER DISPENSER A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Tube-water-DOOR A B C D Tube-water inlet, inlet valve, to ice maker...

  • Page 16: Ice Container

    Publication No: 5995424131 12/04 FRS26BRDS ICE CONTAINER 37A 34 34 33 N58YBAAAA1...
  • Page 17 5304404363 5304404331 241577302 240323808 240507202 # Functional Parts * Non-Illustrated Parts FRS26BRDS ICE CONTAINER A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Auger-ice A B C D Cam-drive A B C D...

  • Page 18: Ice Maker

    Publication No: 5995424131 FRS26BRDS ICE MAKER 12/04...
  • Page 19 5308000133 240387101 55 # 240531101 # Functional Parts * Non-Illustrated Parts FRS26BRDS ICE MAKER A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Tube-water-DOOR A B C D Tube-water inlet, inlet valve, to ice maker...
  • Page 20 Publication No: 5995424131 FRS26BRDS ICE MAKER 12/04...
  • Page 21 218737900 5303001549 218888001 240352411 # Functional Parts * Non-Illustrated Parts FRS26BRDS ICE MAKER A FRS26BRDS (FRS26BRDSB1) B FRS26BRDS (FRS26BRDSB2) C FRS26BRDS (FRS26BRDSB3) D FRS26BRDS (FRS26BRDSB4) DESCRIPTION A B C D Screw, hex head, 10-32 x 0.500 A B C D...

  • Page 22: Wiring Schematic

    Publication No: 5995424131 FRS26BRDS WIRING SCHEMATIC 12/04...

  • Page 23: Wiring Diagram

    FRS26BRDS Publication No: 5995424131 WIRING DIAGRAM 12/04 # Functional Parts * Non-Illustrated Parts...
