- Page 1 DISH Pro 34 Multi-Dish Switch Installation Guide...
-
Page 2: Table Of Contents
Contents Why Install a DP34 Switch ..........3 Important Safety Instructions ..........2 How to Install The DP34 Switch........5 Wiring Diagrams ............11 Limited Warranty ............14 If You Need Help............18 Important Safety Instructions You must keep safety in mind when you install and use the DP34 switch. -
Page 3: Why Install A Dp34 Switch
Why install a DP34 Switch A DP34 switch allows you to receive signals from two or three DISH Network satellites, and route these signals to as many as four DishPro satellite receivers per switch. DP34 switches allow you to add as many as four DishPro receivers to your system by adding just one DP34 switch. - Page 4 Warning: The DP34 switch can be used only with DishPro LNBFs and DishPro receivers. DishPro products can be identified by the DishPro logo shown below. If your system has LNBFs that do not have the DishPro logo, you cannot use the DP34 Switch in your system. However, you can use the DP34 Switch if there are receivers in your system that do not have the DishPro logo if you buy a DishPro Adapter for each of these receivers.
-
Page 5: How To Install The Dp34 Switch
How to Install a DP34 Switch 1. Mount the DP34 switch onto the side of a building, or on some other sturdy structure. Make sure that the mounting location is stable, and that you fasten the switch tightly to the surface. The DP34 should be fixed by suitable hardware for the wall or ceiling. - Page 6 Figure 1 2. Connect the coaxial cables from a DISH 500 or a DISH 300 to the ports on the DP34 switch labeled “to Dish” (see also the wiring diagrams that begin on page 11. 3. Connect the cables from the Dish receiver’s back panel Satellite In port(s) to the DP34 ports labeled “to Receiver Satellite In.”...
- Page 7 • Do not connect the receiver to the ports labeled “To additional switch” as this can cause other receivers in the system to experience loss of video. 4. The switch takes the place of a ground block. Article 820-40 of the National Electrical Code (NEC) states that you should locate a ground block as close as possible to where you have the system connected to the ground (for example, to a water pipe or rod driven in the ground).
- Page 8 Figure 2 3. Select Check Switch. The Check Switch screen will open. Select Check. 4. The Check Switch procedure will run. When it finishes, you will see an Installation Summary screen. This screen should identify the installed switch as a DP34.
- Page 9 Figure 3 5. While your screen may not look exactly like the one shown here, you must see Dish input from both satellites (or all three satellites, if applicable), the “Satellite reception verified” message, and your LNBFs (Devices) correctly identified. If you do not, you will need to check all cables and switches, and then run Check Switch again.
- Page 10 If you still do not see the “Satellite reception verified” message, select Details. This screen provides information that may be helpful in trouble-shooting the problem or in reporting it to the DISH Network Customer Service Center. Page 10...
-
Page 11: Wiring Diagrams
Wiring Diagrams DISH 500 with DishPro Twin LNBF and a DP34 Switch Connect both ports (connections) on the DishPro Twin LNBF to any two ports on the DP34 Switch that are marked “to Dish.” Make sure there is no more than 200 feet of cable between the LNBFs and the receiver(s). - Page 12 DISH 500 with DishPro Twin LNBF and Dish 300 with Single DishPro LNBF and a DP34 Switch Connect both ports (connections) of the DishPro Twin LNBF to any two ports on the DP34 Switch that are marked “to Dish.” Connect the DishPro Single LNBF to any port of the DP34 marked “to Dish.”...
- Page 13 Connecting Several DP34 Switches Two DP34s for Eight Optional DishPro Receivers Three DP34s for Twelve DishPro Receivers Connect DishPro LNBFs to ports marked “to Dish.” Connect DP34 Switches together between ports marked “to Additional Switch” or “to Dish.” You must have at least one satellite receiver connected to each DP34 switch in order to provide power to that switch.
-
Page 14: Limited Warranty
Limited Warranty This warranty extends only to the original user of the DISH Network DP34 Switch (“you,” “your”) and is limited to the purchase price of the switch. EchoStar Communications Corporation and its affiliated companies (“we,” “our,” “us”) warrant this switch control against defects in materials or workmanship as follows. - Page 15 DAMAGE RESULTING FROM THE USE OF, OR INABILITY TO USE, THIS DEVICE. UNDER NO CIRCUMSTANCES SHALL OUR LIABILITY, IF ANY, EXCEED THE PURCHASE PRICE PAID FOR THIS DEVICE. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS DEVICE IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
- Page 16 Advance Exchange Program The Advance Exchange Program allows you to have replacement equipment shipped immediately to you (depending upon where you live, it could take three to five business days). Along with replacement equipment, you will receive a prepaid shipping label and instructions on how to return the defective equipment.
- Page 17 Accessory Warranty An accessory is any DISH Network branded equipment, displaying the DISH Network logo, excluding the receiver, Smart Card, cables and hookups, and non-mechanical components. A one-year warranty becomes effective upon the activation of the DISH system or date of purchase, if bought separately.
-
Page 18: If You Need Help
If You Need Help Review this Guide. Call the DISH Network Service Center at 1-800-333-DISH (3474). Have the date of purchase and your customer account number ready. A Representative will assist you. The Representative will try to troubleshoot any problem you may be having. He or she also will check whether the switch is covered under this warranty. - Page 19 FCC Rules Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio...
- Page 20 Notes Page 20...
- Page 21 Notes Page 21...
- Page 22 Notes Page 22...
- Page 23 Inverness Terrace East, Englewood, Colorado 80112. Document Number: 123320 Printed in China. DISH Network is a trademark and service mark of EchoStar Communications Corporation. All product names, trade names, or corporate names mentioned in this Guide are acknowledged to be the proprietary property of the registered owners.
