SERVICE MANUAL
Sec. 1: Main Section
I Specifications
I Preparation for Servicing
I Adjustment Procedures
I Schematic Diagrams
I CBA's
VIDEO CASSETTE RECORDER
Sec. 2: Deck Mechanism Section
I Standard Maintenance
I Alignment for Mechanism
I Disassembly/Assembly of Mechanism
I Alignment Procedures of Mechanism
25D-850
25D-860
Sec. 3: Exploded views
and Parts List Section
I Exploded views
I Parts List
PAL

Advertisement

Table of Contents
loading

Related Manuals for FUNAI 25D-850

Summary of Contents for FUNAI 25D-850

  • Page 1 Parts List Section I Specifications I Preparation for Servicing I Alignment for Mechanism I Exploded views I Disassembly/Assembly of Mechanism I Parts List I Adjustment Procedures I Alignment Procedures of Mechanism I Schematic Diagrams I CBA’s VIDEO CASSETTE RECORDER 25D-850 25D-860...

  • Page 2: Table Of Contents

    MAIN SECTION VIDEO CASSETTE RECORDER 25D-850/25D-860 Sec. 1: Main Section I Specifications I Preparation for Servicing I Adjustment Procedures I Schematic Diagrams I CBA’s TABLE OF CONTENTS Specifications................1-1-1 Important Safety Precautions.

  • Page 3: Specifications

    SPECIFICATIONS Description Unit Minimum Nominal Maximum Remark 1. Video 1-1. Video Output (PB) Vp-p FL6A 1-2. Video Output (R/P) Vp-p SP Mode, 1-3. Video S/N Y (R/P) W/O Burst 1-4. Video Color S/N AM (R/P) SP Mode 1-5. Video Color S/N PM (R/P) SP Mode 1-6.

  • Page 4: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Product Safety Notice I. Also check areas surrounding repaired locations. J. Be careful that foreign objects (screws, solder Some electrical and mechanical parts have special droplets, etc.) do not remain inside the set. safety-related characteristics which are often not evi- K.
  • Page 5 Safety Check after Servicing Chassis or Secondary Conductor Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts, and wires have been returned to their original posi- Primary Circuit Terminals tions. Afterwards, do the following tests and confirm the specified values to verify compliance with safety standards.

  • Page 6: Standard Notes For Servicing

    STANDARD NOTES FOR SERVICING Circuit Board Indications How to Remove / Install Flat Pack-IC a. The output pin of the 3 pin Regulator ICs is indi- 1. Removal cated as shown. With Hot-Air Flat Pack-IC Desoldering Machine:. (1) Prepare the hot-air flat pack-IC desoldering Top View Bottom View machine, then apply hot air to the Flat Pack-IC...
  • Page 7 With Soldering Iron: (4) Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply (1) Using desoldering braid, remove the solder from all soldering iron to center of the flat pack-IC and heat pins of the flat pack-IC.
  • Page 8 2. Installation Instructions for Handling Semi-conductors (1) Using desoldering braid, remove the solder from the foil of each pin of the flat pack-IC on the CBA Electrostatic breakdown of the semi-conductors may so you can install a replacement flat pack-IC more occur due to a potential difference caused by electro- easily.

  • Page 9: Preparation For Servicing

    PREPARATION FOR SERVICING How to Enter the Service Mode About REC-Safety Switch Caution: The REC-Safety Switch is directly mounted on the About Optical Sensors Main CBA. When the Deck Mechanism Assembly is Caution: removed from the Main CBA for servicing, this switch does not work automatically.

  • Page 10: Cabinet Disassembly Instructions

    CABINET DISASSEMBLY INSTRUCTIONS 1. Disassembly Flowchart (1): Identification (location) No. of parts in the figures (2): Name of the part This flowchart indicates the disassembly steps to gain (3): Figure Number for reference access to item(s) to be serviced. When reassembling, (4): Identification of parts to be removed, unhooked, follow the steps in reverse order.
  • Page 11 (S-1) (S-1) (S-4) (S-3) (S-3) (S-5) [3]VCR (S-4) Chassis Unit (S-3) [1] Top Case (S-1) Fig. 1 (L-2) (L-3) (L-2) Fig. 3 [4] Jack CBA (S-6) [2] Front Desolder Assembly (L-1) Fig. 2 Fig. 4 1-5-2 HC2C0DC...
  • Page 12 FE Head Cylinder Assembly AC Head Assembly SW507 LD-SW [7] Main CBA [6] Deck Assembly [6] Deck Assembly [7] Main CBA Cam Gear (S-7) Hole Shaft Hole [5] Function LD-SW (S-7) [7] Main CBA Desolder from bottom Fig. 6 From From From Capstan Motor...

  • Page 13: Electrical Adjustment Instructions

    ELECTRICAL ADJUSTMENT INSTRUCTIONS Head Switching Position Adjustment General Note: "CBA" is an abbreviation for "Circuit Board Assembly." Purpose: NOTE: To determine the Head Switching point during 1.Electrical adjustments are required after replacing playback. circuit components and certain mechanical parts. Symptom of Misadjustment: It is important to do these adjustments only after all repairs and replacements have been com- May cause Head Switching noise or vertical jitter...

  • Page 14: Block Diagrams

    BLOCK DIAGRAMS Servo/System Control Block Diagram (DECK ASSEMBLY) IC501 AL+5V TP507 FUNCTION CBA (SERVO/SYSTEM CONTROL) MAIN CBA SW507 AC HEAD ASSEMBLY S-INH RS501 LD-SW CL505 CN651 REMOTE KEY SWITCH D502 REMOCON-IN KEY- 1 KEY-1 SENSOR SWITCH S-LED KEY-2 KEY SWITCH CL287 CL504 AL+5V...
  • Page 15 Video Block Diagram REC-VIDEO SIGNAL PB-VIDEO SIGNAL MODE: SP/REC MAIN CBA I2C BUS SDA TO SERVO/SYSTEM IC501 (OSD) I2C BUS SCL CONTROL BLOCK CHARACTER COLOR IC301 Q351 BUFFER (Y/C SIGNAL PROCESS) (DECK ASSEMBLY) SERIAL V-IN1 Y. DELAY DECORDER SERVO/SYSTEM CYLINDER ASSEMBLY TU-VIDEO CONTROL BLOCK CL253...
  • Page 16 Audio Block Diagram PB-AUDIO SIGNAL REC-AUDIO SIGNAL Mode : SP/REC MAIN CBA N-A-PB TO Hi-Fi N-A-REC AUDIO BLOCK IC301 (AUDIO SIGNAL PROCESS) TUNER PB-ON LINE MUTE (DECK ASSEMBLY) SP/LP-ON ACE HEAD ASSEMBLY REC-ON Q401 CL287 CL504 A-PB/REC AUDIO 4 A-PB/REC Q402 HEAD A-COM...
  • Page 17 Hi-Fi Audio Block Diagram PB-AUDIO SIGNAL REC-AUDIO SIGNAL Mode : SP/REC JACK CBA MAIN CBA JK101 CL101 CL151 A-IN1(R) A-IN1(R) A-IN1(L) A-IN1(L) A-OUT1(R) 6 A-OUT1(R) A-OUT1(L) A-OUT1(L) 12 JK751 JK102 CL102 CL152 A-OUT(R) A-IN2(R) A-IN2(R) A-IN2(L) A-IN2(L) REAR A-OUT2(R) A-OUT2(R) 6 A-OUT(L) A-OUT2(L) A-OUT2(L) 11...
  • Page 18 Power Supply Block Diagram NOTE : CAUTION CAUTION ! Fixed voltage (or Auto voltage selectable ) power supply circuit is used in this unit. The voltage for parts in hot circuit is measured using FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, If Main Fuse (F001) is blown, check to see that all components in the power supply hot GND as a common terminal.

  • Page 19: Function Indicator Symbols

    FUNCTION INDICATOR SYMBOLS Note: The following symbols will appear on the indicator panel to indicate the current mode or operation of the VCR. On-screen modes will also be momentarily displayed on the tv screen when you press the operation buttons. Display panel "...

  • Page 20: Schematic Diagrams / Cba's And Test Points

    SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS Standard Notes Notes: WARNING 1. Do not use the part number shown on these draw- ings for ordering. The correct part number is shown Many electrical and mechanical parts in this chassis in the parts list, and may be slightly different or have special characteristics.
  • Page 21 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE. 2. CAUTION: Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F001) is blown, first check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply.
  • Page 22 Main 1/5 Schematic Diagram Comparison Chart of Models and Marks MODEL MARK 25D-850 25D-860 1-8-3 1-8-4 1-8-5 HC4C5SCM1...
  • Page 23 Main 2/5 Schematic Diagram 1-8-6 1-8-7 1-8-8 HC4C5SCM2...
  • Page 24 Main 3/5 Schematic Diagram 1-8-9 1-8-10 1-8-11 HC4C5SCM3...
  • Page 25 Main 4/5 Schematic Diagram NOTE : CAUTION CAUTION ! THE VOLTAGE FOR PARTS IN HOT CIRCUIT IS MEASURED USING FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, Fixed voltage (or Auto voltage selectable ) power supply circuit is used in this unit. HOT GND AS A COMMON TERMINAL.
  • Page 26 Main 5/5 Schematic Diagram 1-8-15 1-8-16 HC4C5SCM5...
  • Page 27 Jack Schematic Diagram 1-8-17 1-8-18 HC4C5SCJ...
  • Page 28 AFV Schematic Diagram 1-8-19 1-8-20 HC4C5SCAFV...
  • Page 29 Function Schematic Diagram 1-8-21 1-8-22 HC4C5SCF...
  • Page 30 Main CBA Top View BECAUSE A HOT CHASSIS GROUND IS PRESENT IN THE POWER CAUTION ! SUPPLY CIRCUIT , AN ISOLATION TRANSFORMER MUST BE USED. Fixed voltage (or Auto voltage selectable ) power supply circuit is used in this unit. ALSO , IN ORDER TO HAVE THE ABILITY TO INCREASE THE INPUT CAUTION If Main Fuse (F001) is blown, check to see that all components in the power supply...
  • Page 31 Main CBA Bottom View BECAUSE A HOT CHASSIS GROUND IS PRESENT IN THE POWER CAUTION ! SUPPLY CIRCUIT , AN ISOLATION TRANSFORMER MUST BE USED. Fixed voltage (or Auto voltage selectable ) power supply circuit is used in this unit. ALSO , IN ORDER TO HAVE THE ABILITY TO INCREASE THE INPUT CAUTION If Main Fuse (F001) is blown, check to see that all components in the power supply...
  • Page 32 Jack CBA Top View Jack CBA Bottom View BHC400F01018-E 1-8-29 1-8-30...
  • Page 33 Function CBA Top View Function CBA Bottom View BHC400F01018-B 1-8-31 1-8-32...
  • Page 34 AFV CBA Top View AFV CBA Bottom View BHC400F01091 1-8-33 1-8-34...

  • Page 35: Waveforms

    WAVEFORMS (TP751 of Main CBA) V-OUT E-E 10usec 50mV x 10 (TP751 of Main CBA) UPPER (TP302 of Main CBA) LOWER V-OUT 0.1V x 10 RF-SW 0.5V x 10 50usec (TP301 of Main CBA) UPPER (TP302 of Main CBA) LOWER C-PB 10mV x 10 RF-SW...

  • Page 36: Wiring Diagrams

    WIRING DIAGRAM NOTE FOR WIRE CONNECTORS: 1. PREFIX SYMBOL "CN" MEANS CONNECTOR. AC CORD (CAN DISCONNECT AND RECONNECT.) FRONT REAR 2. PREFIX SYMBOL "CL" MEANS WIRE-SOLDER VIDEO AUDIO AUDIO AUDIO AUDIO HOLES OF THE PCB. (WIRE IS SOLDERED DIRECTLY.) IN (R) IN (L) OUT (R) OUT (L)

  • Page 37: Ic Pin Function Descriptions

    IC PIN FUNCTION DESCRIPTIONS IC501( SERVO / SYSTEM CONTROL IC ) Signal Active Function Name Level “H” ≥ 4.5V, “L” ≤ 1.0V N.U. Not Used Signal Active Function Name Level N.U. Not Used Input Signal from N.U. Not Used SC2-IN L/Hi-z Pin 8 of SCART2 N.U.
  • Page 38 Signal Active Signal Active Function Function Name Level Name Level N.U. Not Used CTL Amp Gain 84 OUT FF/REW- Switching Signal (FF/ N.U. Not Used REW=”L”) Composite N.U. Not Used PULSE C-SYNC Synchronized Pulse P-DOWN- Power Voltage Down 59 OUT 8POUT-1 SCART 1 8Pin Detector Signal Output Control Signal Capstan Motor...

  • Page 39: Lead Identifications

    LEAD IDENTIFICATIONS 2SC1815-Y(TPE2) PT-6958-FN-TP BN1F4M-T 2SC1815-GR(TPE2) BA1F4M-T 2SC3266-Y (TPE2) KTA1266(GR) 2SC2120-Y(TPE2) KTC3199(Y,GR,BL) KTC3203(Y) 2SC2785(J.H.F.K) 2SC1815-BL(TPE2) KRA103M 2SA1020(Y) KRC103M 2SB892(S) KRA104M KTC3205(Y) 2SD1246(S,T) 2SA1015-GR(TPE2) BN1L4M-T KTA1281(Y) LA71750AM-MTB E C B E C B QSZAB0RMB111 QSZAA0RMB121 BR24C02(04)F-W AT24C02(04)N-10SC LTV-817(B.C)-F M24C02(04)-MN6 EL817(A,B,C) CAT24WC02(04)JI MSP3417G-QG-B8-V3 LA72646SM-A-MPB MSP3417G-QG-B8...
  • Page 40 DECK MECHANISM SECTION VIDEO CASSETTE RECORDER 25D-850/25D-860 Sec. 2: Deck Mechanism Section I Standard Maintenance I Alignment for Mechanism I Disassembly/Assembly of Mechanism I Alignment Procedures of Mechanism TABLE OF CONTENTS Standard Maintenance..............2-1-1 Service Fixtures and Tools .

  • Page 41: Standard Maintenance

    STANDARD MAINTENANCE Service Schedule of Components H: Hours : Check I: Change Deck Periodic Service Schedule Ref.No. Part Name 1,000 H 2,000 H 3,000 H 4,000 H Cylinder Assembly Loading Motor Assembly Pulley Assembly Tension Lever Sub Assembly AC Head Assembly B573,B574 Reel S, Reel T Capstan Motor...
  • Page 42 Cleaning Cleaning of Audio Control Head Clean the head with a cotton swab. Cleaning of Video Head Procedure Clean the head with a head cleaning stick or chamois 1.Remove the top cabinet. cloth. 2.Dip the cotton swab in 90% isopropyl alcohol and Procedure clean the audio control head.

  • Page 43: Service Fixtures And Tools

    SERVICE FIXTURE AND TOOLS J-1-1, J-1-2 Ref. No. Name Part No. Adjustment J-1-1 Alignment Tape FL6A Head Adjustment of Audio Control Head J-1-2 Alignment Tape FL6N8 Azimuth and X Value Adjustment of Audio Control (1 speed only) Head / Adjustment of Envelope Waveform FL6NS8 (2 speed only) Guide Roller Adj.Screwdriver...

  • Page 44: Mechanical Alignment Procedures

    MECHANICAL ALIGNMENT PROCEDURES Explanation of alignment for the tape to correctly run B. Method to place the Cassette Holder in the tape- starts on the next page. Refer to the information below loaded position without a cassette tape on this page if a tape gets stuck, for example, in the 1.
  • Page 45 1.Tape Interchangeability Alignment Note: To do these alignment procedures, make sure that the Tracking Control Circuit is set to the center position every time a tape is loaded or unloaded. (Refer to page 2-3-4, procedure 1-C, step 2.) Equipment required: Dual Trace Oscilloscope VHS Alignment Tape (FL6N8) Guide Roller Adj.
  • Page 46 1-A. Preliminary/Final Checking and 3. Check to see that the tape runs without creasing at Alignment of Tape Path Take-up Guide Post [4] or without snaking between Guide Roller [3] and AC Head. (Fig. M3 and M5) Purpose: 4. If creasing or snaking is apparent, adjust the Tilt To make sure that the tape path is well stabilized.
  • Page 47 6. Press CH DOWN button on the unit until the CTL 1-D. Azimuth Alignment of Audio/Control/ waveform has shifted from its original position (not Erase Head the position achieved in step 5, but the position of Purpose: CTL waveform in step 4) by approximately -2msec. To correct the Azimuth alignment so that the Audio/ Make sure that the envelope is simply attenuated Control/Erase Head meets tape tracks properly.

  • Page 48: Disassembly/Assembly Procedures Of Deck Mechanism

    DISASSEMBLY/ASSEMBLY PROCEDURES OF DECK MECHANISM Before following the procedures described below, be sure to remove the deck assembly from the cabinet. (Refer to CABINET DISASSEMBLY INSTRUCTIONS on page 1-5-1.) All the following procedures, including those for adjustment and replacement of parts, should be done in Eject mode;...
  • Page 49 REMOVAL INSTALLATION STEP START- REMOVE/*UNHOOK/ /LOC. PART ADJUSTMENT Fig. No. UNLOCK/RELEASE/ CONDITION UNPLUG/DESOLDER Loading Arm S(B) (+)Refer to Alignment [35] [25] DM2,DM15 Assembly Sec.Pg.2-4-9 Loading Arm T(B) (+)Refer to Alignment [36] [35] DM2,DM15 Assembly Sec.Pg.2-4-9 [2],[25] M Brake T(HI) Assembly DM1,DM16 *(P-6) [37] [38]...
  • Page 50 Top View [45] [46] [50] [47] [14] [13] [11] [15] [39] [40] [10] [12] [38] [37] [44] [33] [42] [31] [32] [41] [43] Fig. DM1 Bottom View [19] [36] [35] [24] [26] [27] [25] [23] [28] [22] [29] [20] [34] Fig.
  • Page 51 (S-1) (S-1) (S-2) (P-1) (S-4) (S-3) Fig. DM5 Fig. DM3 [50] Type A Pin D Pin C Type B [51] [50] (L-9) Pull up Slide Pin A (L-8) Pin B Slot A Slots B (S-5) Slot A First, while pushing the locking tab as shown in the right, slide and pull up the right side on [2] to release Pin A and Pin B from the slots A.
  • Page 52 (S-7) (S-9) [14] (S-10) [15] Desolder from bottom (S-6) Lead with White Stripe Belt View for A Fig. DM7 Fig. DM9 (L-2) Adj. Screw [17] After removing the Screw (S-11), [11] while pressing the Locking Tab (L-3) (L-1) (L-3), remove [16]. (P-3) [16] [13]...
  • Page 53 (C-1) Cap Belt [20] [19] [21] Fig. DM12 (S-12) Fig. DM11 2-4-6 U25PALDA...
  • Page 54 [25] (C-5) (C-2) (C-3) [22] [23] (S-15) [26] (L-4) (P-4) [27] (C-6) [29] (C-4) [28] [30] [24] [31] (P-4) [28] [32] When installing [23], install the spring (P-4) to [28] as Position of Mode Lever when installed shown in the left figure, and Pin of [38] then install [23] while Pin on...
  • Page 55 Refer to the Alignment Section, Page 2-4-9. [46] [45] [47] (P-5) (L-7) [34] [33] [36] [35] (L-5) Fig. DM17 Fig. DM15 [39] (C-8) [42] (C-7) (P-7) [44] [41] turn (L-6) [43] [48] [49] Slide (P-6) [38] turn [37] [40] Fig. DM18 turn Fig.

  • Page 56: Alignment Procedures Of Mechanism

    ALIGNMENT PROCEDURES OF MECHANISM Alignment 1 The following procedures describe how to align the individual gears and levers that make up the tape Loading Arm, S and T Assembly loading/unloading mechanism. Since information about the state of the mechanism is provided to the Install Loading Arm S and T Assembly so that their System Control Circuit only through the Mode Switch, triangle marks point to each other as shown in Fig.
  • Page 57 Alignment 3 Cam Gear (A), Rack Assembly Install the Rack Assembly so that the first tooth on the gear of the Rack Assembly meets the first groove on the Cam Gear (A) as shown in Fig. AL4. Cam Gear (A) Top View Alignment 3 First tooth...
  • Page 58 EXPLODED VIEWS AND PARTS LIST SECTION VIDEO CASSETTE RECORDER 25D-850/25D-860 Sec. 3: Exploded views and Parts List Section I Exploded views I Parts List TABLE OF CONTENTS Exploded Views ............... . 3-1-1 Mechanical Parts List.

  • Page 59: Exploded Views

    EXPLODED VIEWS Front Panel 3-1-1 HC4C0FEX...
  • Page 60 Cabinet 2L011 2B18 2L011 2L011 2L011 JACK CBA 2L011 2L012 2L022 2L042 2L021 2L041 2L021 2L022 2L022 2L021 2L051 2L022 2L021 2L021 SENSOR CBA AFV CBA 2L041 2L041 2L031 2B14 MAIN CBA 2L099 2B46 [ 25D-860 ] SENSOR CBA 2B49 FUNCTION CBA 3-1-2 HC4C5CEX...
  • Page 61 Packing Some Ref. Numbers are not in sequence. [ 25D-860 ] X20C X20B X20A Unit 3-1-3 HC4C5PEX...
  • Page 62 DECK EXPLODED VIEWS Deck Mechanism View 1 Mark Description (Blue grease) Floil G-374G SLIDUS OIL #150 L1467 B494 B553 L1191 B411 B567 L1053 B410 L1051 Chassis Assembly Top View (Lubricating Point) B501 B560 L1450 B426 L1466 B121 B126 L1468 B492 B571 Some Ref.
  • Page 63 Deck Mechanism View 2 Mark Description B587 Note: Both TENSION Floil G-374G (Blue grease) LEVER ASSEMBLY MK11(B27) and the TENSION SANKOUL FG84M (Yellow grease) LEVER ASSEMBLY MK11 (B587) can be used. B574 B508 B148 B487 B573 L1406 B522 B518 B520 B521 B564 B499...
  • Page 64 Deck Mechanism View 3 Mark Description Floil G-374G (Blue grease) L1321 B347 Note: There are two different, but interchangeable types of CLEANER LEVER(B359) in this model, and have different combination with B361. Please L1321 see Table 1 for details and combination. (Refer to DECK PARTS LIST section.) Table 1 (B359 and B361 Combination) B359 CLEANER LEVER...

  • Page 65: Mechanical Parts List

    XB0M451T0001 Comparison Chart of Models and Marks DRY BATTERY(SUNRISE) R6SSE/2S XB0M451MS002 RF CORD PAL 1.2M or WPZ0122LG001 Model Mark RF CABLE CC1001020012010 WPZ0122LW001 25D-850 ACCESSORY BAG K8092BA 0VM404632 X20A! OWNER'S MANUAL(ENGLISH) HC4C5ED 0VMN03211 25D-860 X20A! OWNER'S MANUAL(CZECH) HC4C6ED 0VMN03315 X20B!

  • Page 66: Electrical Parts List

    CHD1EZB0F104 CHIP CERAMIC CAP. FZ Z 0.1µF/50V or CHD1JZBFZ104 Model Mark CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104 25D-850 CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104 25D-860 CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104 C157 ELECTROLYTIC CAP. 1µF/50V M H7...
  • Page 67 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104 CHIP CERAMIC CAP. CG J 68pF/50V or CHD1JJBCG680 CHIP CERAMIC CAP. FZ Z 0.1µF/50V or CHD1JZBFZ104 CHIP CERAMIC CAP. CH J 68pF/50V or CHD1JJ3CH680 CHIP CERAMIC CAP.
  • Page 68 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. CHIP CERAMIC CAP. CG J 68pF/50V CHD1JJ3CG680 CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104 C351 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221 CHIP CERAMIC CAP. FZ Z 0.1µF/50V or CHD1JZBFZ104 C352 ELECTROLYTIC CAP.
  • Page 69 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104 CHIP CERAMIC CAP. CG J 100pF/50V or CHD1JJBCG101 CHIP CERAMIC CAP. FZ Z 0.1µF/50V or CHD1JZBFZ104 CHIP CERAMIC CAP. CH J 100pF/50V or CHD1JJ3CH101 CHIP CERAMIC CAP.
  • Page 70 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. C751 CHIP CERAMIC CAP. B K 2200pF/50V or CHD1JKB0B222 ZENER DIODE MTZJT-779.1C QDTC0MTZJ9R1 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222 D018 SWITCHING DIODE 1N4148M or NDTZ01N4148M C752 CHIP CERAMIC CAP. B K 2200pF/50V or CHD1JKB0B222 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133...
  • Page 71 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. IC:EEPROM CAT24WC04JI NSZBA0SBG002 TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815 IC561 IC:LED DRIVER PT6958-FN-TP NSZBA0TG2003 TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815 COILS Q054 TRANSISTOR KTC3205(Y) or NQSY0KTC3205 TRANSISTOR 2SC3266-Y(TPE2) or QQSY02SC3266 L001 BEAD CORE B16 RH 3.5X10X1.3 or XL03010XM001 TRANSISTOR 2SD1246(S) or QQSS02SD1246...
  • Page 72 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. CARBON RES. 1/4W J 680 Ω Q552 RES. BUILT-IN TRANSISTOR KRC103M or NQSZ0KRC103M R068 RCX4JATZ0681 CHIP RES.(1608) 1/10W J 2.2k Ω or RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M R251 RRXAJB5Z0222 CHIP RES.(1608) 1/10W J 2.2k Ω...
  • Page 73 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. CHIP RES.(1608) 1/10W J 180 Ω or CHIP RES.(1608) 1/10W J 22k Ω or R351 RRXAJB5Z0181 R452 RRXAJB5Z0223 CHIP RES.(1608) 1/10W J 180 Ω CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0181 RRXAJR5Z0223 CHIP RES.(1608) 1/10W J 150 Ω...
  • Page 74 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. CHIP RES.(1608) 1/10W J 10k Ω CARBON RES. 1/4W G 4.7k Ω RRXAJR5Z0103 RCX4GATZ0472 CHIP RES.(1608) 1/10W J 10k Ω or CHIP RES.(1608) 1/10W J 390k Ω or R506 RRXAJB5Z0103 R540...
  • Page 75 Ref. No. Mark Description Part No. Ref. No. Mark Description Part No. CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152 X'TAL 4.433619MHz 1811388 CHIP RES.(1608) 1/10W J 1k Ω or R852 RRXAJB5Z0102 X501 X'TAL 12.000MHz FXD126LDS001 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102 X502 X'TAL 32.768kHz(20PPM) or...
  • Page 76 Ref. No. Description Part No. Ref. No. Description Part No. CARBON RES. 1/4W J 4.7k Ω CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104 RCX4JATZ0472 CARBON RES. 1/4W J 68 Ω CHIP CERAMIC CAP. FZ Z 0.1µF/50V or CHD1JZBFZ104 R108 RCX4JATZ0680 CHIP RES.(1608) 1/10W J 75 Ω...
  • Page 77 Ref. No. Description Part No. CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0 CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0 CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0 CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0 CHIP CERAMIC CAP.

  • Page 78: Deck Parts List

    DECK PARTS LIST Notes: Ref. No. Description Part No. 1. There are two different, but interchangeable types of CAP BELT MK10 0VM411138 CLEANER LEVER(B359) in this model, and have FE HEAD ASSEMBLY MK11 or N9742FEL different combination with B361. Please see Table 1 FE HEAD(MK11) MH-131SF11 or DHVEC01Z0005 for details and combination.
  • Page 79 Ref. No. Description Part No. B559 CLUTCH ASSEMBLY(HI)(2) MK11 0VSA12367 B560 KICK SPRING MK10 0VM411475A B562 C DRIVE LEVER L MK10 0VM304408 B563 SLIDER SHAFT MK10 0VM411112 B564 M GEAR(HYT) N12G5F* 0VM412378 B565 SENSOR GEAR MK11 0VM305080 B567 PINCH ARM(B) MK10 0VM304396 B568 BT ARM MK10...
