Frigidaire FGF312B Factory Parts Catalog

Gas range
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FGF312BSA
FGF312B
WIRING DIAGRAM - # 316255203
OWNER'S GUIDE - # 316257501
INSTALLATION INSTRUCTIONS -# 316259312
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
white
North America
Publication No.
5995384525
030124
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
GAS
RANGE
Model No.
FGF312B
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FGF312B

Summary of Contents for Frigidaire FGF312B

  • Page 1 PRODUCT NO. BASE MODEL NO. FGF312BSA FGF312B WIRING DIAGRAM - # 316255203 OWNER’S GUIDE - # 316257501 INSTALLATION INSTRUCTIONS -# 316259312 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 COLOR MARKET white North America Publication No. 5995384525 030124 -EN/SERVICE /ECL ©2003 Electrolux Home Products, Inc.
  • Page 2 Publication No. FGF312BSA 5995384525 BACKGUARD 01/03...
  • Page 3 POS. NO 12 # # = Fast-moving Parts * = Non-Illustrated Parts FGF312BSA BACKGUARD PART NO DESCRIPTION 316032404 Thermostat 316097602 Insulator 316263404 End Cap,white ,RH 316263405 End Cap,white ,LH 316263301 Panel,backguard ,white 316102303 Knob,thermostat ,white 316009009 Knob,top valve ,white ,(4) 316201805 Panel,manifold ,white 316021108...
  • Page 4 Publication No. FGF312BSA 5995384525 BURNER 01/03...
  • Page 5 POS. NO 10 # 10A# 11A# 14 # 17 # 18 # 19 # # = Fast-moving Parts * = Non-Illustrated Parts FGF312BSA BURNER PART NO DESCRIPTION 316134400 Pipe,manifold 5303935189 Valve,top burner ,2 position ,w/mtg screw 316134300 Screw,10-24 ,valve mounting 316001828 Wiring Harness,ignitor ,with switches 316135700...
  • Page 6 Publication No. FGF312BSA 5995384525 BODY 01/03...
  • Page 7 POS. NO 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF312BSA BODY PART NO DESCRIPTION 316029416 Panel,main back 316230114 Panel,bodyside ,white ,RH 316230115 Panel,bodyside ,white ,LH 316021131 Screw,bodyside ,8-18 X 11/16 ,white 316067210 Burner Box 316129200 Screw,leveling ,plastic ,with stop 316067902 Rack,oven 316216502...
  • Page 8 Publication No. FGF312BSA 5995384525 TOP/DRAWER 01/03...
  • Page 9 POS. NO 20 # # = Fast-moving Parts * = Non-Illustrated Parts FGF312BSA TOP/DRAWER PART NO DESCRIPTION 316110201 Carriage,low broil 316236401 Liner,low broil 316110800 Shield,broiler 316237600 Shield,low broil ,top 316231211 Panel,drawer ,white 316129100 Fastener,push-in nut ,nylon ,spacer 316081900 Pan,broiler 316082000 Insert,broiler pan 316111502 Glide,low broil ,chassis...
  • Page 10 Publication No. FGF312BSA 5995384525 DOOR 01/03...
  • Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF312BSA DOOR PART NO DESCRIPTION 316222705 Shield,wool ,oven door 316236801 Insulation,oven door 316230603 Liner,oven door 316001009 Screw,waf hd sq ,10-24 x 1.88 ,(2) ,handle mtg 316008401 Washer,3/4 OD x 1/4 ID ,steel 316239700 Seal,oven door 316202603...

  • Page 12: Wiring Schematic

    Publication No. FGF312BSA 5995384525 WIRING SCHEMATIC 01/03...

  • Page 13: Wiring Diagram

    FGF312BSA Publication No. 5995384525 WIRING DIAGRAM # = Fast-moving Parts 01/03 * = Non-Illustrated Parts...
