Operation
Manual
Pan and Cover
DHB2PT-20
Power On/Off Switch
DHB2PT-27
Pan and Cover
LIMITED WARRANTY
This product is warranted to be free from defects in material and/or
workmanship for a period of 1 year from date of original installation, not to
exceed 18 months from the date of manufacture.
Any component which proves to be faulty in material and/or workmanship
will be replaced or repaired (at the option of Prince Castle, Inc.) without
cost to the customer for parts and labor. This warranty covers on-location
service (i.e. trip charges and/or mileage). Travel mileage is limited to
100 miles (200 Kilometers) round trip (one trip warranty) from an
authorized service agency or its sub-service agency.
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this warranty.
• All labor to be performed during regular work hours. Overtime premium
(the incremental amount) will be charged to the customer.
• Damage caused by carelessness, neglect and/or abuse (e.g.,
dropping, tampering or altering parts, equipment damaged in shipment,
by fire, flood or an act of God) is not covered under this warranty.
• All problems due to operation at voltages other than that specified on
equipment nameplates are not covered by this warranty. Conversion to
correct voltage is the customer's responsibility.
• This equipment must be serviced by Prince Castle Authorized Service
Agency or a Prince Castle Service Technician during the warranty
period.
542-517revC-EN
Product Identification
Button Bar
Temperature Control Panel
PRINCE CASTLE
LOGO Button
LED Timers (tri-color)
(qty. 4, 6 or 8)
Pan Buttons
(qty. 4, 6 or 8)
Temperature
Control
Panel
Power
On/Off
Button Bar
Switch
355 East Kehoe Blvd. • Carol Stream, IL 60188 USA
Telephone: 630-462-8800 • Toll Free: 1-800-PCASTLE
Fax: 630-462-1460 • www.princecastle.com
Upper Pan Displays
(qty. 2 or 3)
Transfer Button
UP and DOWN Arrow
Buttons
DHB2PT-33
Pan and Cover
TABLE OF CONTENTS
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
®
CastleNet
Communications Network . . . . . . . . . . . . . . . . . . . . . . . . .
Factory Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exploded View and Parts List (DHB2PT-20B) . . . . . . . . . . . . . . . . . . .
Exploded View and Parts List (DHB2PT-27B/-27BCE) . . . . . . . . . . . .
Exploded View and Parts List (DHB2PT-33) . . . . . . . . . . . . . . . . . . . .
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Holding Bin
DHB2PT Series
BKFT (Breakfast) LED
MENU/ENTER Button
REG (Regular Menu) LED
Temperature
Control
Panel
Power
On/Off
Button Bar
Switch
7 – 10
Printed in USA 10/10 © 2010
1
2
2
3
4
11
12
13
14
15
16
17
Advertisement
Related Manuals for Prince Castle DHB2PT Series
Summary of Contents for Prince Castle DHB2PT Series
- Page 1 Installation ..........will be replaced or repaired (at the option of Prince Castle, Inc.) without Operation .
- Page 2 Refer to CASTLENET COMMUNICATIONS NETWORK in this manual. Prince Castle reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
- Page 3 Product Holding Bin DHB2PT Series Operation Turn power On/Off switch to ON position. Press all PAN buttons. Load pan covers (if used) onto pan racks and insert racks into the unit. Allow 30 minutes for heaters to reach operating temperature. The...
- Page 4 Operation (continued) To change a menu selection for a specific pan cavity, use the following steps: A. Press and hold the PRINCE CASTLE LOGO button for 6 seconds. All D. Press the UP or DOWN Arrow E. Press the MENU/ENTER button Pan displays will show PROG.
- Page 5 U225 Press the UP or DOWN Arrow button until the desired setpoint Press the PRINCE CASTLE LOGO button to save the new temperature is displayed. setpoint value. Repeat steps 2 – 5 to change the setpoint for any other heater.
- Page 6 A. Press and hold the PRINCE CASTLE LOGO and ACTUAL A. Press the UP or DOWN Arrow button until the temperature TEMP buttons for 5 seconds. The colon (:) LED indicator will displayed matches the reading obtained in Step 2.
- Page 7 A. The SET PRODUCT TIME menu is used to change the Hold and Cook-More times. B. Press and hold the PRINCE CASTLE LOGO button, then immediately press and hold the MENU/ENTER button until the display shows one of the programming menus.
- Page 8 A. The Alternating Display Interval allows the timer bar displays to alternate between the product name and remaining Hold time. The default setting is 5 seconds. B. Press and hold the PRINCE CASTLE LOGO button, then immediately press and hold the MENU/ENTER button until the display shows one of the programming menus.
- Page 9 A. The EDIT PRODUCT NAME menu is used to change a default product name to one of your own choosing. B. Press and hold the PRINCE CASTLE LOGO button, then immediately press and hold the MENU/ENTER button until the display shows one of four programming menus.
- Page 10 A. The SET MAXIMUM TRANSFER TIME menu is used to set the amount of time allowed to make a product transfer from one pan to another. B. Press and hold the PRINCE CASTLE LOGO button, then immediately press and hold the MENU/ENTER button until the display shows one of the programming menus.
- Page 11 BIN 1 BIN 2 BIN 3 bin. A PDA (or similar device) or a notebook with Prince Castle ® MenuView software is used to connect to the network and enter the desired changes.
- Page 12 Product Holding Bin DHB2PT Series Factory Presets Product Menu Details Product Display Name Hold Minutes Cook-More Minutes Burger BUR1 Burger BUR2 Chicken Patty CHX1 Chicken Patty CHX2 Chicken Patty CHX3 Chicken Wing WING Fish FISH Eggs EGGS Sausage SAUS Bacon...
- Page 13 Product Holding Bin DHB2PT Series Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION Display flashes Open relay. Circuit inoperable. Replace power circuit board. Display flashes Shorted relay. Circuit inoperable. Replace power circuit board. Open heater. Test heater resistance (150.2 Ohms). Replace heater if necessary.
- Page 14 Product Holding Bin DHB2PT Series Exploded View and Parts List (DHB2PT-20B) Ref. Part No. Description Ref. Part No. Description 542-121S Upper Heater Assy 72-200-15S Power Cord 542-059S Lower Heater Assy 541-959S PCB Audio Interface Kit 541-723E4S Cover (Pkg of 4)
- Page 15 Product Holding Bin DHB2PT Series Exploded View and Parts List (DHB2PT-27B/-27BCE) Ref. Part No. Description Ref. Part No. Description 541-833S Upper Heater Kit (DHB2PT-27B) 541-719S Display PCB Kit 541-669S Upper Heat Assembly (DHB2PT-27BCE) 88-709-2-11S Speaker Kit 541-832S Lower Heater Kit (DHB2PT-27B)
- Page 16 Product Holding Bin DHB2PT Series Exploded View and Parts List (DHB2PT-33B) Ref. Part No. Description Ref. Part No. Description 541-376S Upper Heater Kit 541-735S Main PCB Kit 541-375S Lower Heater Kit 541-719S Display PCB Kit 541-636S Rack Kit 88-709-2-11S Speaker Kit...
- Page 17 Product Holding Bin DHB2PT Series Wiring Diagram 355 East Kehoe Blvd. • Carol Stream, IL 60188 USA Telephone: 630-462-8800 • Fax: 630-462-1460 Printed in USA 10/10 © 2010 Toll Free: 1-800-PCASTLE Prince Castle LLC. www.princecastle.com...
