Summary of Contents for Lanzar HTG889
-
Page 2: Table Of Contents
In the interest of safety, LANZAR recommends listening at lower volume levels while driving. -
Page 3: Planning Your System
4/8 GAUGE (Thicker if planning for additional Ampli ers) wire is recommended for both the power and ground wires 12 Gauge, for the remote turn-on wire 16 Gauge. Both types are available at most Mobile Audio Dealers or Installation Shop. www.Lanzar.com... -
Page 4: Wiring Connection
IF YOUR RADIO DOES NOT HAVEA +12 VOLT OUTPUT LEAD WHEN THE RADIO IS TURNED ON， THE "REMOTE" TERMINAL ON THE AMPLIFIER CAN BE CONNECTED TO VEHICLE'S ACCESSORY CIRCUIT THAT IS LIVE WHEN THE KEY lS "ON". HTG559BT - HTG669BT www.Lanzar.com... -
Page 5: Panel Layout
HTG889 PANEL LAYOUT HTG559BT - HTG669BT Front View HTG889 Front View www.Lanzar.com... - Page 6 Rear View HTG559BT HTG669BT HTG889 www.Lanzar.com...
-
Page 7: Control Functions
Do not connect a level control knob from other manufacturers to the Remote Sub Level Control of any ampli er. Even though the connectors t properly, the control knob and connector pin positions may be di erent and the ampli er will be damaged. www.Lanzar.com... - Page 8 7. Auxiliary Outputs The Auxiliary outputs o er LANZAR ampli ers easy, unlimited system expansion. Route RCA's from the line out of the rst ampli er to the line input of a second ampli er when using a single source output.
-
Page 9: Speaker Diagrams Mono Channel
System Diagrams 5 Channel Systems HTG559BT www.Lanzar.com... - Page 10 System Diagrams 6 Channel Systems HTG669BT www.Lanzar.com...
- Page 11 System Diagrams www.Lanzar.com...
- Page 12 System Diagrams 8 Channel Systems HTG889 www.Lanzar.com...
- Page 13 System Diagrams www.Lanzar.com...
-
Page 14: Troubleshooting Guide
If you need to replace the power fuse, replace it only with a fuse identical to that supplied with the system. Using a fuse of di erent type or rating may result in damage to this system which isn't covered by the warranty. www.Lanzar.com... -
Page 15: Specification
Speci cation HTG889 8-Channel Mosfet Ampli er 2 Ohm Stereo Stable with High Pass and Low Pass Filter Controls Features: • Class “AB” High-Current Dual Discrete Drive Stages • Mosfet PWM Power Supply • Bass Boost Circuit • Bridgeable at 4ohms •... - Page 16 LPF Freq. Response: 40Hz-250Hz • HPF Freq. Response: 40Hz-250Hz • BPF Freq. Response: 40Hz-3KHz • Bass Boost (50Hz): 0,6,12dB • Input Sensitivity: 0.2V~6V • Fuse: 30A X 3 • Product Dimensions (L x W x H): 19.29'' x 8.81'' x 2.24'' -inches www.Lanzar.com...
- Page 17 LPF Freq. Response: 40Hz-250Hz • HPF Freq. Response: 40Hz-250Hz • BPF Freq. Response: 40Hz-3KHz • Bass Boost(50Hz) : 0,6,12dB • Input Sensitivity:0.2V~6V • Fuse: 25A X 3 • Product Dimensions (L x W x H): 19.29'' x 8.81'' x 2.24'' -inches www.Lanzar.com...
- Page 18 Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: support@lanzar.com...
