Philips 24PHG4032 Service Manual
  1. Manuals
  2. Brands
  3. Philips Manuals
  4. TV
  5. 24PHG4032
  6. Service manual

Philips 24PHG4032 Service Manual

Hide thumbs Also See for 24PHG4032:
Table of Contents

Advertisement

Quick Links

Download this manual
TPM17.5L
Chassis name
Platform
Model name
TPM17.5L LA
MTK5561
24PHG4032/77
Published by Doris.zheng 1735 Quality
Subject to modification
3122 785 20500
2017-Spe-01
2017
TP Vision Netherlands B.V.
©
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

Advertisement

Table of Contents
loading

Related Manuals for Philips 24PHG4032

Summary of Contents for Philips 24PHG4032

  • Page 1 Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 2: Table Of Contents

    Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 3: Product Inforamtion

    • Picture enhancement: Digital Crystal Clear • Picture Performance Index (PPI): 240 Product specifications are subject to change without notice. For more specification details of this product, Sound see www.philips.com/support • Incredible Surround Power • Clear Sound • Mains power: AC 110-240 V~, 50-60 Hz •...

  • Page 4: Connections Overview

    2. Connections Overview...

  • Page 5: Mechanical Instructions

    3. Mechanical Instructions 3.1 Cable Dressing ECN701 ECN408 CN9101 ECN403 CN8605 CN408 CN701 CN401 (1053) ECN401 CN601 ECN401 IR/LED BOARD (1056) ECN601 ECN401 ECN601 Cable dressing (24" 5022 series)

  • Page 6: Assembly/Panel Removal

    3.2 Assembly/Panel Removal 3.2.1 Rear Cover and stand removal Warning: Disconnect the mains power cord before removing the rear cover. 1. Remove fixation screws [1] that secure the base assy.. 2. The cover is secured by clips, be very careful with releasing those. 3.
  • Page 7 3.2.4 Small Signal Board (SSB) Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the SSB. 1. Release the clips from the LVDS connector that connect with the SSB[1]. Caution: be careful, as these are very fragile connectors! 1.
  • Page 8 3.2.7 Speakers 1. Gently release the tapes that secure the speaker cables. 2. Unplug the speaker connector from the SSB. 3. Take the speakers out. When defective, replace the both units. 3.2.8 WIFI module 1. Unplug the connector from the SSB.. 2.

  • Page 9: Service Modes

    4. Service Modes 4.1 Service Modes The Service Mode feature is split into following parts: Factory Mode.   Customer Service Mode (CSM).SAM and the Factory mode offer features, which can be used by the Service engineer to repair/align a TV set. The CSM is a Service Mode that can be enabled by the consumer.
  • Page 10 How to Exit the Factory mode Use one of the following methods: Select EXIT_FACTORY from the menu and press the “OK” button.  Note: When the TV is switched “off” by a power interrupt, or normal switch to “stand-by” while in the factory mode, the TV will show up in “normal operation mode”...

  • Page 11: Software Upgrading, Error Code And Panel Code

    5. Software Upgrading, Error code and Panel Code 5.1 Software Upgrading 5.1.1. The following update is for .bin file. 1. Rename the file to “Usb_update.bin” 2. Prepare a USB memory. 3. Copy the software to USB flash disk(root directory). 4. Switch off the TV and Insert the USB memory stick that contains the software update files in one of the TV’s USB 2.0 ports. 5.

  • Page 12: Circuit Descriptions

    6. Circuit Descriptions 6.1 Introduction The TPM17.5L LA is a new chassis launched in LA in 2017. The whole range is covered by MTK5561 platform. The major deltas versus its predecessor support DVB-C; DVB-T,DTMB with also USB3.0,WIFI/multi-media, Video out The TPM17.5L LA chassis comes with the following stylings: series xxPUT4032/xx ...
  • Page 13 Always replace a defective fuse with one with the correct specifications! This part is available in the regular market. Consult the Philips Service web portal for the order codes of the boards. Important delta’s with the platform are: •...
  • Page 14 - side-view LED with scanning: PSLS power panel - direct-view LED without 2D-dimming: PSL power panel - direct-view LED with 2D-dimming: PSDL power panel. PSL stands for Power Supply with integrated LED-drivers. PSLS stands for a Power Supply with integrated LED-drivers with added Scanning functionality (added microcontroller). PSDL stands for a Power Supply for Direct-view LED backlight with 2D-dimming.
  • Page 15 6.3.2 Power layout SSB Power SSB Top View 6.4 Front-End Analogue and DVB-C, DVB-T; reception 6.4.1 Front-End Analogue part The Front-End for analogue tuner consist of the following key components: • Silicon Tuner MxL661-AG-R • SCALER MT5561LVNT/B PBGA-329 Below find a block diagram of the front-end application for DVB-C part. 6.4.2 Front-End ISDB Reception DTV part The Front-End for DVT part consist of the following key components: •...
  • Page 16 6.5 HDMI Refer to below for the application. The following HDMI connector can be used: • HDMI 1: HDMI input ( TV digital interface support HDMI1.4/HDCP1.3) with digital audio/PC DVI input/ARC • HDMI 2: HDMI input ( TV digital interface support HDCP) with digital audio/PC DVI input/CEC •...

  • Page 17: Ic Data Sheet

    7. IC Data Sheets 7.1 M5723B (IC U703)
  • Page 18 7.2 MT5561LVNT/B (IC U401)
  • Page 20 7.3 TAS5729MDDCAR (IC U601)
  • Page 21 7.4 MxL661 (IC U104)
  • Page 22 7.5 TC90537FG (IC U101)

  • Page 23: Circuit Diagrams

    8.Circuit Diagrams 8.1 A 715G7735 PSU 8-1-1 POWER BD9901 36W: BD9901 093G 50460518 KBP208G-C 45W: BD9901 393G0050460A02 36W: L8601 373G0253214X02 45W: L8602 073G 253214 Cold R8612 C8605 L8601 NC/22K 1% NC/100PF 500V NC/47UH FB9903 FB9906 FB9905 D8601 BEAD 127R BEAD SR510-22 VLED+ R9129...

  • Page 24: B 715G7805 Ssb

    8.2 B 715G7805 SSB 8-2-1 System Power +5V Switch 3V3SB +5V_SW 4,5,6,7,8,9,10,11,12,13,14,15,16,17,18 +5VSB 90mil 12V_AMP 12V_AMP CN701 FB703 120R 6A R738 CO-LAY +12V +12V 4.7K 1/16W +12V +5V_SW 9,10,11,12,15 +5V_SW Pre_12V Pre_12V +5VSB 7,9,16 +5VSB Pre-12V_AMP Pre-12V_AMP 12V_AMP 4,8,10,13,14,15 3V3SB 3V3SB Q702 FB701...
  • Page 25 8-2-2 Peripheral U401B DVDD3V3 NAND Flash 3,5,6,7,8,9,10,11,12,13,14,15,16,17,18 PDD0 OSCL0 U405 PDD0 OSCL0 PDD1 OSDA0 W29N01GVSIAA PDD1 OSDA0 PDD2 OSCL1 3V3SB PDD2 OSCL1 3,8,10,13,14,15 3V3SB PDD3 OSDA1 DVDD3V3 3,5,6,8,9,10,11,13,15,16,17,18 DVDD3V3 PDD3 OSDA1 PDD4 PDD4 PDD5 XTALI PDD5 XTALI PDD6 XTALO PDD7 PDD6 XTALO I/O7...
  • Page 26 8-2-3 Audio A-in/I2S/HP C687 22PF 50V FB405 120R 3A 3,4,6,7,8,9,10,11,12,13,14,15,16,17,18 SPDIF_OUT U401C DVDD3V3 3,4,6,8,9,10,11,13,15,16,17,18 DVDD3V3 AIN_R0 ASPDIFO AIN_L0 FB406 120R ARC_SPDIF Y PBPR_R_IN ASPDIFI AIN_R1 Y PBPR_L_IN I2C & UART Interface AIN_L1 AOMCLK MCLK CVBS_R_IN R601 2 2R 1/16W 5% AOMCLK AIN_R2 AOBCK...
  • Page 27 8-2-4 Speaker Amp 3,4,5,7,8,9,10,11,12,13,14,15,16,17,18 12V_AMP PVDD PVDD DVDD3V3 AMP3V3 Close Close 12V_AMP 12V_AMP FB602 U601.4 U601.41 DVDD3V3 3,4,5,8,9,10,11,13,15,16,17,18 DVDD3V3 FB603 120R 3A 50mil 120R 6A C614 C612 C610 C613 C615 C611 10UF 6.3V 20% 10UF 6.3V 20% C609 C616 C690 C617 100NF 16V 10UF 6.3V 20%...
  • Page 28 8-2-5 VGA Close VGA CONN Close MT5561 side VGA IN (V/T) 3,4,5,6,8,9,10,11,12,13,14,15,16,17,18 TP1109 12V_AMP 12V_AMP C1203 R1204 VGA_R VGA_RIN +12V 3,10 +12V R1207 NC/ 100R 1/16W 1% NC/ 10N 50V +5V_SW +5VSB +5VSB 3,9,10,11,12,15 +5V_SW NC/ 0R05 1/16W 3,9,16 +5VSB +5VSB 3V3SB R1201...
  • Page 29 8-2-6 Video YPbPr/CVBS Merged Analog 3.3V Power Analog 1.2V Power 3,4,5,6,7,9,10,11,12,13,14,15,16,17,18 AVDD1V2 3V3SB 3V3SB 3,4,10,13,14,15 3V3SB 3V3SB U401D 20mil AVDD1V2 3,13,15 AVDD1V2 R1301 33R 1/16W 5% VGA_SCL 20mil 20mil 3,4,5,6,9,10,11,13,15,16,17,18 DVDD3V3 DVDD3V3 VGA_SCL VGA_SDA AVDD12_DEMOD AVDD33_VIDEO_STB AVDD33_RGB_STB TP405 TP R1302 33R 1/16W 5% RF_AGC VGA_SDA...
  • Page 30 8-2-7 SPDIF/ Mute contorl DVDD3V3 10mil D602 Audio Mute for SCART 3,4,5,6,7,8,10,11,12,13,14,15,16,17,18 AC OFF +5VSB 3,4,5,6,8,10,11,13,15,16,17,18 DVDD3V3 DVDD3V3 DVDD3V3 R657 BAS316WS 10K +-1% 1/16W +5VSB 3,7,16 +5VSB DC OFF 10mil R664 3,10,11,12,15 +5V_SW +5V_SW D601 HP_AC_MUTE +5V_SW 1K 1/16W 1% A_MUTE C681 R658...
  • Page 31 8-2-8 LVDS_Keypad_IR U401G 3,4,5,6,7,8,9,11,12,13,14,15,16,17,18 TX_AO0P AO0P TX_AO0N +12V AO0N +12V DEMOD_RST TX_AO1P LVDSVDD FB401 Panel_VCC 3,9,11,12,15 +5V_SW +5V_SW TCON0 AO1P TX_AO1N 3V3SB TCON1 AO1N 3,4,8,13,14,15 3V3SB HP_MUTE TX_AO2P DVDD3V3 TCON2 AO2P 3,4,5,6,8,9,11,13,15,16,17,18 DVDD3V3 TX_AO2N 120R 6A TCON3 AO2N DVDD3V3 TX_AO3P C409 R409 TCON4...
  • Page 32 8-2-9 TUNER 3,4,5,6,7,8,9,10,12,13,14,15,16,17,18 +5V_SW 3,9,10,12,15 +5V_SW DVDD3V3 3,4,5,6,8,9,10,13,15,16,17,18 DVDD3V3 DVDD3V3 IF Interface FAT_IN- ADCINN_DEMOD 8 FAT_IN+ ADCINP_DEMOD 8 R159 R160 D_IFP D_IFP D_IFN 2.2K 1% 2.2K 1% D_IFN T_SCL TUNER_SCL Control Interface R162 100R 1/16W 5% T_SDA TUNER_SDA R165 100R 1/16W 5% IFAGC_Scaler IFAGC_Scaler 8 OSCL1...
  • Page 33 8-2-10 DDR3 3,4,5,6,7,8,9,10,11,13,14,15,16,17,18 +5V_SW 3,9,10,11,15 +5V_SW DDRV U401A Main Chip Ref Voltage. DRAM POWER DDRV +5V_SW DDRV DDRV DDRV DDRV U411 L401 DDRV DDRV 2.2UH DDRV DDRV R456 R455 C425 RVREF C428 G5695T11U C426 C427 1K 1/16W 1% NC/100N 16V DDRVREF R460 33K 1/16W 1%...
  • Page 34 8-2-11 HDMI/MHL 3,4,5,6,7,8,9,10,11,12,14,15,16,17,18 3,9,10,11,12,15 +5V_SW +5V_SW 3,7,9,16 +5VSB +5VSB 3,4,8,10,14,15 3V3SB 3V3SB 3,4,5,6,8,9,10,11,15,16,17,18 DVDD3V3 DVDD3V3 3,8,15 AVDD1V2 AVDD1V2 REAR HDMI 2 100ohm differential impedance (with ARC) I2C & UART Interface for TMDS traces. CN502 HDMI_SCL2 HDMI_SCL2 U401E HDMI_SDA2 HDMI_SDA2 RX_2_2 HDMI_SCL2/RX HDMI_1_RX_CB SHELL3...
  • Page 35 8-2-12 GPIO 3,4,5,6,7,8,9,10,11,12,13,15,16,17,18 3,4,8,10,13,15 3V3SB 3V3SB LVDS_PWR_EN LVDS_PWR_EN 10 BL_ON/OFF BL_ON/OFF USB_PWR_EN0 3V3SB USB_PWR_EN0 15 U401I SY S_EEPROM_WP SY S_EEPROM_WP 4 LED_POWER_RED OPCTRL0 LED_PWR_Blue LVDS_PWR_EN BL_DIMMING OPCTRL1 GPIO0 BL_DIMMING HTV_OPCTRL2 BL_ON/OFF LED_POWER_RED LED_POWER_RED 4,10 OPCTRL2 GPIO1 AMP_MUTE USB_PWR_EN0 LED_PWR_Blue R499 LED_PWR_Blue 4,10 OPCTRL3 GPIO2...
  • Page 36 8-2-13 USB/ HTV U401F 3,4,5,6,7,8,9,10,11,12,13,14,16,17,18 USB_DM_P0 USB_DM0 USB_DP_P0 USB_DP0 3,9,10,11,12 +5V_SW +5V_SW USB_DM1 3,4,5,6,8,9,10,11,13,16,17,18 DVDD3V3 DVDD3V3 USB_DP1 3V3SB 3,4,8,10,13,14 3V3SB R1114 2.5 = > NORM AL AVDD1V2 3,8,13 AVDD1V2 < 2.0 = >OC +5V_SW 10K +-1% 1/16W RXVN TP410 DVDD3V3 TP411 RXVP USB_OC...
  • Page 37 +5VSB 1Y 0 +12V Debug mode NC BAS316 C408 NC 74HC4052PW NC 100NF 16V HDMI_SCL2/RX R493 HDMI_SCL2 0R05 1/16W For Philips: HDMI_SDA2/TX HDMI_SDA2 R493 and R494 use 0ohm R494 0R05 1/16W 5/31 DVDD3V3 10mil R468 10K +-1% 1/16W DVDD3V3 For ARC...
  • Page 38 8-2-15 VCCK & DVSS U401J VCC3IO 3,4,5,6,7,8,9,10,11,12,13,14,15,16,18 DVDD3V3 3,4,5,6,8,9,10,11,13,15,16,18 DVDD3V3 DVSS VCC3IO VCCK VCCK DVSS VCC3IO 3.3V IO Power DVSS VCC3IO DVSS VCCK DVSS DVDD3V3 VCC3IO DVSS DVSS VCCK DVSS VCCK DVSS VCCK C446 C463 DVSS VCCK C447 C448 DVSS VCCK 1UF 10V 10UF 6.3V 20%...
  • Page 39 8-2-16 DEMOD_Toshiba TC90537 XT_O DVDD3V3 DVDD3V3 R136 3,4,5,6,7,8,9,10,11,12,13,14,15,16,17 XT_I 1M 1/10W 5% R138 close with TC90537 3,4,5,6,8,9,10,11,13,15,16,17 DVDD3V3 DVDD3V3 R111 R126 R137 DEMOD_TSCLK 1.2K OHM 1/16W 1% to avoid spurious. DEMOD_TSCLK NC/ 10K+-5%1/16W NC/ 10K+-5%1/16W DEMOD_TSVAL DEMOD_TSVAL DEMOD_TSSY NC DEMOD_TSSY NC SLADRS0 SLADRS1 X101...

  • Page 40: J 715G8576 Ir Panel

    8.3 715G8576 IR/LED 8-3-1 IR LED LED_R 15K 1/16W 5% Vout TSOP75436TR 2.2uF 10V CONN 033G8032 5F 2K7 1/16W 5% LED1 GPSS008RC4 LED_R 22K 1/16W 5% BC847BW 100N 16V 22K 1/16W 5%...

  • Page 41: E 715G7088 Keyboard Control Panel

    8.4 715G7088 KEY 8-4-1 KEY...

  • Page 42: Styling Sheet

    1053 1184 0050R 0040 1057 0050L 1184 1054 0095 0030 1050 Pos No. Description Remarks 0030 Bezel 0040 Rear cover 0050R Stand_R 0050L Stand_L 0095 V0 SHEET 1056 1050 Display panel 1053 Panel SSB 1054 Power Supply Unit 1056 IR/LED panel 1057 Keyboard control panel 1176...
