PRODUCT NO.
BASE MODEL NO.
FEF336BCB
FEF336B
SERVICE DATA SHEET - # 316259195
WIRING DIAGRAM - #316255162
OWNER'S GUIDE - # 316257114
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
stainless
North America
Publication No.
5995379111
021002
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF336B
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FEF336B
Summary of Contents for Frigidaire FEF336B
- Page 1 PRODUCT NO. BASE MODEL NO. FEF336BCB FEF336B SERVICE DATA SHEET - # 316259195 WIRING DIAGRAM - #316255162 OWNER’S GUIDE - # 316257114 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 COLOR MARKET stainless North America Publication No.
- Page 2 Publication No. FEF336BCB 5995379111 BACKGUARD 10/02...
- Page 3 POS. NO 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF336BCB BACKGUARD PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316248900 Spacer,shield ,rear wall 316241000 Shield,end cap ,RH 316241001 Shield,end cap ,LH 316022500 Light/Lamp,indicator ,125 V 316220216 Support,backguard ,black ,RH 316220217...
- Page 4 Publication No. FEF336BCB 5995379111 BODY 10/02...
- Page 5 POS. NO 14 # 37 # 62 # 66 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF336BCB BODY PART NO DESCRIPTION 316201300 Back,main 316230116 Panel,bodyside ,black ,RH 316230117 Panel,bodyside ,black ,LH 316021132 Screw,bodyside ,8-18 X 11/16 ,black 316129200 Screw,leveling ,plastic ,with stop 316067902...
- Page 6 Publication No. FEF336BCB 5995379111 TOP/DRAWER 10/02...
- Page 7 POS. NO 15 # 15A# 15B# # = Fast-moving Parts * = Non-Illustrated Parts FEF336BCB TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231500 Liner,drawer 316248802 Panel,drawer ,stainless 3051163 Glide,drawer ,rear 316010206 Element,surface ,8" ,2200 W ,radiant 316010205 Element,surface ,6" ,1200 W ,radiant 316224200 Element,surface ,9"...
- Page 8 Publication No. FEF336BCB 5995379111 DOOR 10/02...
- Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF336BCB DOOR PART NO DESCRIPTION 316240000 Glass,oven door ,black ,outer 316222711 Shield,wool ,black ,oven door 316237100 Glass,oven door ,clear ,heat barrier 316230605 Liner,oven door 316001015 Screw,waf hd sq ,10-24 x 1.25 ,(2) ,handle mtg 316008401 Washer,3/4 OD x 1/4 ID ,steel 316239700...
-
Page 10: Wiring Schematic
Publication No. FEF336BCB 5995379111 WIRING SCHEMATIC 10/02... -
Page 11: Wiring Diagram
FEF336BCB Publication No. 5995379111 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
