INSTALLATION MANUAL
AIR
CONDITIONER
Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
Please retain this installation manual for future reference after reading it
thoroughly.
OUTDOOR UNIT
MFL67448519
Rev.01_011620
Copyright © 2014 - 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG ATUW60GYLP0
Summary of Contents for LG ATUW60GYLP0
- Page 1 Installation work must be performed in accordance with the national wiring standards by authorized personnel only. Please retain this installation manual for future reference after reading it thoroughly. OUTDOOR UNIT www.lg.com MFL67448519 Rev.01_011620 Copyright © 2014 - 2020 LG Electronics Inc. All Rights Reserved.
- Page 2 TIPS FOR SAVING ENERGY TIPS FOR SAVING ENERGY Here are some tips that will help you minimize the power consumption when you use the air conditioner. You can use your air conditioner more efficiently by referring to the instructions below: •...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk. Read the part with this symbol carefully and follow the instructions in order to avoid risk. - Page 4 SAFETY INSTRUCTIONS Operation • Do not share the outlet with other appliances. It will cause an electric shock or a fire due to heat generation. • Do not use the damaged power cord. Otherwise, it may cause a fire or electrical shock. •...
-
Page 5: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS TIPS FOR SAVING ENERGY SAFETY INSTRUCTIONS INSTALLATION OF OUTDOOR UNIT Night Silent Operation setting WIRING CONNECTION Electrical Wiring Connecting Cables between Indoor Unit and Outdoor Unit Connecting the cable to Outdoor Unit CONNECTING PIPES Preparation of Piping Connecting the pipes to the Outdoor unit Forming the piping... -
Page 6: Installation Of Outdoor Unit
INSTALLATION OF OUTDOOR UNIT INSTALLATION OF OUTDOOR UNIT Installation Places - If an awning is built over the unit to prevent direct sunlight or rain exposure, make sure that heat radiation from the condenser is not restricted. - Ensure that the spaces indicated by arrows around front, back and side of the unit. - Do not place animals and plants in the path of the warm air. - Page 7 INSTALLATION OF OUTDOOR UNIT Ceiling Caeestte <Type : 4Way> Pipe Size [mm (inch)] Length A [m] Elevation B [m] CAPACITY Additional CHASSIS Refrigerant [g/m] [Btu/h] Liquid Standard Max. Standard Max. 18 K Ø12.7(1/2) Ø6.35(1/4) U24A 24 K Ø15.88(5/8) Ø9.52(3/8) 36 K Ø15.88(5/9) Ø9.52(3/8) 48 K...
- Page 8 INSTALLATION OF OUTDOOR UNIT Ceiling Caeestte <Type : Round> Pipe Size [mm (inch)] Length A [m] Elevation B [m] CAPACITY Additional CHASSIS Refrigerant [g/m] [Btu/h] Liquid Standard Max. Standard Max. 36 K Ø15.88(5/9) Ø9.52(3/8) 50 K Ø19.05(3/4) Ø9.52(3/8) If installed tube is shorter than 7.5 m, additional charging is not necessary. Additional Refrigerant = (A - 7.5) x Additional refrigerant (g) Indoor unit Outdoor unit...
-
Page 9: Night Silent Operation Setting
INSTALLATION OF OUTDOOR UNIT Night Silent Operation setting Applied Model : Free Joint Single Outdoor, Ceiling Caeestte <Type : 4Way>, Ceiling Suspended Air conditioner, Ceiling Concealed Duct,Floor Standing Air Conditioner - Open the Side panel or Top Cover of outdoor unit. - Set the SW1 or DIP-SW01D. -
Page 10: Wiring Connection
WIRING CONNECTION WIRING CONNECTION Electrical Wiring Perform the electrical wiring work according to the electrical wiring connection. ELCB - All wiring must comply with local Main power source requirements. Switch box - Select a power source that is capable of supplying the current required by the air conditioner. -
Page 11: Connecting Cables Between Indoor Unit And Outdoor Unit
WIRING CONNECTION Connecting Cables between Indoor Unit and Outdoor Unit Outdoor Indoor unit unit CAUTION The power cord connected to the outdoor unit should be complied with IEC 60245 or HD 22.4 S4 (This equipment shall be provided with a cord set complying with the national regulation. - Page 12 WIRING CONNECTION Precautions when laying power wiring Use round pressure terminals for connections to the power terminal block. Power wire Round pressure terminal When none are available, follow the instructions below. - Do not connect wiring of different thicknesses to the power terminal block. (Slack in the power wiring may cause abnormal heat.) - When connecting wiring which is the same thickness, do as shown in the figure below.
-
Page 13: Connecting The Cable To Outdoor Unit
WIRING CONNECTION Connecting the cable to Outdoor Unit Remove the side panel for wiring connection. Use the cord clamp to fix the cord. Earthing work - Connect the cable of diameter more to the earthing terminal provided in the control box and do earthing. -
Page 14: Connecting Pipes
CONNECTING PIPES CONNECTING PIPES Preparation of Piping Main cause of gas leakage is defect in flaring work. Carry out correct flaring work in the following procedure. Cut the pipes and the cable. Copper - Use the accessory piping kit or the pipes Slanted Uneven Rough 90°... -
Page 15: Connecting The Pipes To The Outdoor Unit
CONNECTING PIPES Connecting the pipes to the Outdoor unit Align the center of the piping and sufficiently tighten the flare nut by hand. Finally, tighten the flare nut with torque wrench until the wrench clicks. - When tightening the flare nut with torque wrench, ensure the direction for tightening follows the arrow on the wrench. -
Page 16: Forming The Piping
CONNECTING PIPES Forming the piping In cases where the outdoor unit is installed above the indoor unit perform the following. Form the piping by wrapping the connecting Tape the piping and connecting cable from portion of the indoor unit with insulation down to up. -
Page 17: Plumbing Materials And Storage Methods
CONNECTING PIPES Plumbing materials and storage methods Pipe must be able to obtain the specified thickness and should be used with low impurities. Also when handling storage, pipe must be careful to prevent a fracture, deformity and wound. Should not be mixed with contaminations such as dust, moisture. Refrigerant piping on three principles Drying Cleanliness... -
Page 18: Nitrogen Substitution Method
CONNECTING PIPES Nitrogen substitution method Welding, as when heating without nitrogen substitution a large amount of the oxide film is formed on the internal piping. The oxide film is a caused by clogging EEV, capillary, oil hole of accumulator and suction hole of oil pump in compressor. -
Page 19: Leakage Test And Evacuation
LEAKAGE TEST AND EVACUATION LEAKAGE TEST AND EVACUATION CAUTION Air and moisture remaining in the refrigerant system have undesirable effects as indicated below. To avoid nitrogen entering the refrigerant - Pressure in the system rises. system in a liquid state, the top of the cylinder must be higher than its bottom - Operating current rises. -
Page 20: Evacuation
LEAKAGE TEST AND EVACUATION Evacuation Indoor unit - Connect the charge hose end described in the preceding steps to the vacuum pump to evacuate the tubing and indoor unit. Confirm the "Lo and Hi" knob of the manifold valve is open. Then, run the vacuum pump. The operation time for evacuation varies with Outdoor unit tubing length and capacity of the pump. -
Page 21: Test Running
TEST RUNNING TEST RUNNING Precautions In Test Running - The initial power supply must provide at least 90 % of the rated voltage. Otherwise, the air conditioner should not be operated. CAUTION For test run, carry out the cooling operation firstly even during heating season. If heating operation is carried out firstly, it leads to the trouble of compressor. - Page 22 TEST RUNNING CAUTION After the confirmation of the above conditions, prepare the wiring as follows: Never fail to have an individual power specialized for the air conditioner. As for the method of wiring, be guided by the circuit diagram pasted on the inside of control box cover.
-
Page 23: Function
FUNCTION FUNCTION Forced Cooling Operation Adding the refrigerant in winter. Setting Procedure - Set the DIP Switch as follow after shutting the power source down. Free Joint Single Outdoor, Ceiling Caeestte <Type : 4Way>, Ceiling Suspended Air conditioner, Ceiling Concealed Duct, Floor Standing Air Conditioner U4: 48 kBtu/h U4: 36 kBtu/h... -
Page 24: Self-Diagnosis Function
SELF-DIAGNOSIS FUNCTION SELF-DIAGNOSIS FUNCTION Error Indicator (Outdoor) (Unit : sec) 2 Times 1 Time 2 Times 1 Time 2 Times 1 Time Outdoor Error (RED) Ex) Error 21 (DC Peak) UL2: 18 kBtu/h U24A: 24 kBtu/h (Unit : sec) 2 Times 2 Times 2 Times LED 1... - Page 25 SELF-DIAGNOSIS FUNCTION (Red) (Red) Indoor Error Code Description status LED 1 LED 2 (Red) (Green) 2 times ◑ 1 time ◑ DC Peak(IPM Fault) 2 times ◑ 2 times ◑ Max. CT(CT2) 2 times ◑ 3 times ◑ DC Link Low Volt. 2 times ◑...
-
Page 26: Installation Guide At The Seaside
INSTALLATION GUIDE AT THE SEASIDE INSTALLATION GUIDE AT THE SEASIDE CAUTION In case, to install the outdoor unit on the seaside, set up a windbreak not to be exposed to the sea wind. • Air conditioners should not be installed in areas where corrosive gases, such as acid or alkaline gas, are produced. -
Page 27: Convenient Functions
CONVENIENT FUNCTIONS CONVENIENT FUNCTIONS Pressure compensation function (for Round Type) If you use additional pipe to install the cooling operation, this function can compensate the target of pressure by setting DIP switch. * Pressure compensation function is release at initial state as standard. * This function is used only if the length of pipe >...
