• Keep the motor running while pulling the bit out of a
drilled hole. This will help reduce jamming.
• Make sure switch turns drill On and Off.

Drilling in Wood

Holes in wood can be made with the same twist drill bits
used for metal or with spade bits. These bits should be
sharp and should be pulled out frequently when drilling to
clear chips from the flutes.

Drilling in Metal

Use a cutting lubricant when drilling metals. The exceptions
are cast iron and brass which should be drilled dry. The
cutting lubricants that work best are sulfurized cutting oil
or lard oil.
Drilling in Masonry
Use carbide tipped masonry bits. Refer to Drilling section.
Keep even force on the drill but not so much that you crack
the brittle material. A smooth, even flow of dust indicates
the proper drilling rate.

MAINTENANCE


WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can cause injury.
Accessories

WARNING: Since accessories, other than those
offered by CRAFTSMAN, have not been tested with
this product, use of such accessories with this tool
could be hazardous. To reduce the risk of injury, only
CRAFTSMAN recommended accessories should be
used with this product.
Recommended accessories for use with your tool are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact CRAFTSMAN, call 1-888-331-4569.
Versatrack™ (Fig. J)

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental can cause injury.

WARNING: To reduce the risk of serious personal
injury, do not use a damaged Versatrack™ hang hook
or Versatrack™ Trackwall. A damaged Versatrack™
hang hook or Versatrack™ Trackwall will not support

the weight of the tool.
WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the Versatrack™ hang
hook is securely tightened.

WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
objects from the hang hook. ONLY suspend tool on the
Versatrack™ Trackwall using the hang hook.
10

WARNING: Ensure that the tool weight does not
exceed the maximum rated weight for the selected
Versatrack™ hook.

WARNING: When hanging objects on a Versatrack™
Trackwall rail, adequately space the tools in order to
not exceed 75 lb (35 kg) per linear foot.
iMPORTAnT: When attaching the Versatrack hang
hook, use only the screw that is provided. Be sure to
securely tighten the screw. Versatrack™ accessories
mount compatible tools securely to the Versatrack™
Trackwall system.
1. Turn tool off, remove battery pack and
remove accessories.

CAUTION: Any product with exposed cutting teeth
must have them covered securely if it is to be on
the Versatrack™ Trackwall.
2. Attach the hang hook 11
a. Place the Versatrack hang hook onto the mounting
location at the base of the tool.
b. Use a screwdriver to secure the hang hook wth the
provided screw 12 . Do not use any other screw for this.
nOTE: Versatrack™ accessories for use with your tool are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact CRAFTSMAN, call 1-888-331-4569.
Fig. J
Belt Hook
Optional Accessory

WARNING: To reduce the risk of serious personal
injury, place the forward/reverse button in the
lock-off position or turn tool off and disconnect
battery pack before making any adjustments or
removing/installing attachments or accessories.
An accidental start-up can cause injury.

WARNING: To reduce the risk of serious personal
injury, ONLY use the tool's belt hook to hang
the tool from a work belt. DO NOT use the belt
hook for tethering or securing the tool to a person or
object during use. DO NOT suspend tool overhead or
suspend objects from the belt hook.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook
is secure.
on the tool.
