CHARCOAL GRILL
1
HEAVY-DUTY
MODEL #DGN405SNC/
#DGN405SNC-D
Français p. 19
Español p. 37
Rev. 7/11/19
Advertisement
Related Manuals for Dyna-Glo DGN405SNC
Summary of Contents for Dyna-Glo DGN405SNC
- Page 1 HEAVY-DUTY CHARCOAL GRILL MODEL #DGN405SNC/ #DGN405SNC-D Français p. 19 Español p. 37 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday – Friday, or email customerservice@ghpgroupinc.com...
- Page 2 TABLE OF CONTENTS Package Contents ....................... 3 Hardware Contents......................4 Preparation .......................... 4 Safety Information ....................... 5 Assembly Instructions......................6 Operating Instructions ....................... 14 Care and Maintenance ...................... 16 Warranty ..........................16 Replacement Parts List ..................... 17 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product.
- Page 3 SAFETY INFORMATION • Use caution when lifting and moving the unit to avoid back strain or back injury. Do not move the unit while it is in use. • DO NOT operate the unit near or under flammable or combustible materials such as decks, porches or carports.
- Page 4 PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Side Shelf Right Leg Assembly Lid and Firebox Assembly Caster Lid Handle Assembly Storage Basket Smoke Stack Assembly Axle Charcoal Access Door Wheel Crank Handle Left Leg Assembly Damper Handle – Right Charcoal Tray Damper Grate...
- Page 5 HARDWARE CONTENTS (shown actual size) M8 Nut M5 Shoulder Bolt M6x12 Bolt Qty. 2 Qty. 8 M8 Washer Qty. 27 Qty. 2 M6x20 Bolt Qty. 14 M5 Lock Nut Qty. 8 M6x30 Bolt Qty. 2 Cotter Pin Wrench Qty. 7 Hinge Bolt Qty.
- Page 6 ASSEMBLY INSTRUCTIONS 1. Insert axle (P) into left leg assembly (R). Attach one wheel (Q) to each side of axle (P) using one M8 washer (DD), and one M8 nut (EE). Hardware Used M8 Washer M8 Nut 2. Attach two casters (N) to right leg assembly (M) and secure with wrench (JJ).
- Page 7 ASSEMBLY INSTRUCTIONS 4. Attach two cart braces (L) to right leg assembly (M) using two M6x12 bolts (AA) on each side. Hardware Used M6x12 Bolt 5. Attach storage basket (O) to cart braces (L). NOTE: Make sure four hooks on storage basket (O) are fully inserted into holes on cart braces (L).
- Page 8 ASSEMBLY INSTRUCTIONS 7. Secure lid and firebox assembly (B) on top of left leg assembly (R) and right leg assembly (M) using six M6x20bolts (BB). Hardware Used M6x20 Bolt 8. Attach damper (H) to inside of lid and firebox assembly (B) using four M5 shoulder bolts (CC) and four M5 lock nuts (II).
- Page 9 ASSEMBLY INSTRUCTIONS 10. With shelf upside down, attach side shelf support – left rear/right front (W) and side shelf support – left front/right rear (I) to side shelf (A) using four M6x12 bolts (AA) on each side. Repeat for remaining shelf (A). Hardware Used M6x12 Bolt 11.
- Page 10 ASSEMBLY INSTRUCTIONS 13. Attach ash tray handle (K) to ash tray (J) using two M6x12 bolts (AA). Hardware Used M6x12 Bolt 14. Insert ash tray (J) into lid and firebox assembly (B). 15. Attach smoke stack assembly (D) to lid and firebox assembly (B) using three M6x12 bolts (AA).
- Page 11 ASSEMBLY INSTRUCTIONS 16. Attach temperature gauge (X) and temperature gauge nut bezel (Y) to lid and firebox assembly (B) using pre-assembled nut. 17. Attach lid handle assembly (C) to lid and firebox assembly (B) using two M6x12 bolts (AA). Hardware Used M6x12 Bolt 18.
- Page 12 ASSEMBLY INSTRUCTIONS 19. Attach charcoal tray (S) to inside of lid and firebox assembly (B) using four M6x12 bolts (AA). Hardware Used M6x12 Bolt 20. Place two grates (T) on lid and firebox assembly (B). 21. Attach one M6x30 bolt (GG) on each side of lid and firebox assembly (B).
- Page 13 ASSEMBLY INSTRUCTIONS 22. Insert one end of warming rack (U) onto M6x30 bolt (GG) and into the hole on lid and firebox assembly (B). Repeat for other side. 23. Fully tighten M6x30 bolts (GG) on each side of lid and firebox assembly (B).
- Page 14 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday – Friday. PART DESCRIPTION PART # Hardware pack 406-03026-00 Owner’s/instruction manual 70-10-032 Smoke stack - stainless steel 404-01002-05 Lid assembly-WITHOUT handle, temperature gauge/bezel, smoke stack, badge 406-03003-04 DynaGlo badge 213-02002...
- Page 15 REPLACEMENT PARTS LIST Printed in China...
