HT502TH-DH.NA4ULLD_ENG_MFL34656556
DVD RECEIVER
OWNER'S MANUAL
MODEL: HT552TH
Main Unit - HT552TH-DH
Speakers - SH52TH-S
USB
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and
completely.
FOR THE WARRANTY TERMS & CONDITIONS,
PLEASE REFER TO BACK COVER OF THIS MANUAL.
SH52TH-C
SH52TH-W
R
Advertisement
Table of Contents
Related Manuals for LG HT552TH
Summary of Contents for LG HT552TH
- Page 1 HT502TH-DH.NA4ULLD_ENG_MFL34656556 DVD RECEIVER OWNER’S MANUAL MODEL: HT552TH Main Unit - HT552TH-DH Speakers - SH52TH-S SH52TH-C SH52TH-W Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. FOR THE WARRANTY TERMS & CONDITIONS, PLEASE REFER TO BACK COVER OF THIS MANUAL.
- Page 2 CAUTION: The apparatus should not be exposed to water CAUTION (dripping or splashing) and no objects filled with liquids, such RISK OF ELECTRIC SHOCK as vases, should be placed on the apparatus. DO NOT OPEN CAUTION concerning the Power Cord Most appliances recommend they be placed upon CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK...
-
Page 3: Table Of Contents
Introduction Maintenance and Service Maintenance and Service ....3 Before use ......4 Refer to the information in this chapter before Front Panel/Rear Panel . -
Page 4: Before Use
"DTS" and "DTS Digital SIMPLINK function. Surround” are registered trademarks of Digital Theater • LG TV with SIMPLINK function has the logo as Systems, Inc. Copyright 1996, 2003 Digital Theater shown above. Systems, Inc. All Rights Reserved. -
Page 5: Front Panel/Rear Panel
Front Panel/Rear Panel POWER DISC Tray DISPLAY Window VOLUME controller TUNING(-/+)/ SKIP . /> > ) SEARCH(. STOP (x) AUDIO IN connector PAUSE ( X X )/ MONO/STEREO (ST.) USB port FUNC.(-)/PLAY(B) Connect to a USB port of a memory Press and hold down this button device (USB memory etc.) about 3 seconds, then press... -
Page 6: Remote Control
Changes the resolution depending on your TV. Switches the HDMI mode to HDMI (active) and OFF (inactive). DIMMER Controls the TV. (LG TV only) Changes brightness of the display (See page16) window on the front panel during in power-on status. -
Page 7: Installation And Setup
Installation and Setup TV Connection Make one of the following connections, depending on Video connection the capabilities of your existing equipment. Connect the MONITOR OUT jack from the DVD/CD Receiver to the VIDEO IN jack on the TV using the Tips: video cable (V). -
Page 8: Optional Equipment Connection
Optional Equipment Connection OPTICAL IN connection (O) Auxiliary device DVD Player Connect an optical output of DVD Player (or Digital (or Digital Device etc) to the OPTICAL IN connector. Device, etc) VIDEO AUDIO (L) AUDIO IN connection (D) AUDIO (R) OPTICAL Connect a output of portable device (MP3 or PMP etc) To AUDIO OUT (L/R) -
Page 9: Speaker System Connection
Speaker System Connection Connect the speakers using the supplied speaker cables. To obtain the best possible surround sound, adjust the speaker parameters (volume, distance, etc.). Front speaker Front speaker (Left) (Right) Rear speaker Rear speaker Center speaker (Right surround) (Left surround) Subwoofer Notes: Be sure to match the speaker cable to the appropriate terminal on the components: + to + and –... -
Page 10: Hdmi Connection
Rear of DVD/CD Receiver HDMI Connection About HDMI INPUT MONITOR HDMI (High Definition Multimedia Interface) supports L - AUX - R both video and audio on a single digital connection for HDMI OUT HDMI OUT COMPONENT VIDEO (PROGRESSIVE SCAN) an easy all- digital output to an HDMI or DI-equipped TV. OUT PUT Connection to an HDMI TV requires an HDMI cable while connection to a DVI-equipped TV requires a DVI... -
Page 11: Displaying Disc Information On-Screen
Displaying Disc Information GENERAL OPERATION On - screen 1. Press SETUP. The Setup menu appears. 2. Use v / V to select the desired option then press You can display various information about the disc B to move to the second level. The screen shows loaded on-screen. -
Page 12: Display
DISPLAY TV Aspect 4:3 – Select when a standard 4:3 TV is connected. 16:9 – Select when a 16:9 wide TV is connected. Display Mode The display Mode setting works only when the TV Aspect mode is set to “4:3”. Letterbox –... -
Page 13: Audio
AUDIO 5.1 Speaker Setup Make the following settings for the built-in 5.1 channel Each DVD disc has a variety of audio output options. surround decoder. Set the receiver’s AUDIO options according to the type of audio system you use. 1. Press ENTER, and the 5.1 Speaker Setup menu appears. -
Page 14: Lock (Parental Control)
LOCK (Parental Control) Area Code Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 23. 1. Select “Area Code” on the LOCK menu then press B. 2. Follow the step 2 as shown previous paragraph (Rating). -
Page 15: Operation
Operation General features Buttons Operations Discs Z (OPEN / CLOSE) Opens or closes the disc tray. X (PAUSE) During playback, press X to pause playback. Press X repeatedly to play Frame-by-Frame. DivX SKIP (. / >) During playback, press SKIP (. or >) to go to the next chapter/track or to return to the beginning of the current chapter/track. -
Page 16: Additional Features
DivX Your remote control is capable of operating your To enter a Marker DVD/CD Receiver as well as limited functions of LG You can start playback from up to nine memorized Follow the instructions below to operate your LG TV. -
Page 17: Playing An Audio Cd Or Mp3/Wma File
Playing an Audio CD or Programmed Playback MP3/WMA file The program function enables you to store your favorite tracks from any disc in the receiver memory. A This unit can play Audio CDs or MP3/WMA files. program can contain 300 tracks. MP3/ WMA/ Audio CD 1. -
Page 18: Viewing A Jpeg File
Viewing a JPEG file JPEG JPEG disc compatibility with this player is limited as follows: This unit can play discs with JPEG files. • Depending upon the size and the number of Before playing JPEG recordings, read the notes on JPEG files, it could take a long time for the JPEG Recordings on the right. -
Page 19: Playing A Divx Movie File
Playing a DivX Movie file DivX disc compatibility with this player is limited as follows: Using this DVD/CD Receiver you can play DivX disc. • Available resolution size of the DivX file is under 1. Insert a disc and close the tray. The MOVIE menu 800x600 (W x H) pixel. -
Page 20: Presetting The Radio Stations
Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM and AM (MW). Preset radio stations in the DVD/CD Receiver’s Before tuning, make sure that you have turned down memory first (see “Presetting radio stations” on the the volume. -
Page 21: Rds Operation
RDS Operation Programme Search (PTY) A major benefit of RDS is its ability to encode This unit is equipped with RDS (Radio Data System), broadcasts with Programme Type (PTY) codes that which brings a wide range of information to FM radio. indicate the type of material being broadcast. -
Page 22: Sleep Timer Setting
The SLEEP indicator and the sleep time appears in the display window. XTS-P ON The unique sound quality of the LG Technology 2. Each time you press SLEEP the setting creates the optimum sound for you to play the changes in the following order. -
Page 23: Reference
Reference Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian... -
Page 24: Troubleshooting
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Correction Symptom Cause • Plug the power cord securely into the • The power cord is disconnected. No power. wall outlet. • Insert a disc. (Check that the DVD or, •... - Page 25 Symptom Cause Correction • The antenna is positioned or connected • Connect the antenna securely. Radio stations cannot poorly. be tuned in. • Adjust the antennas and connect an external antenna if necessary. • The signal strength of the stations is too •...
-
Page 26: Specifications
Specifications Power supply Refer to main label. Power consumption Refer to main label. Net Weight 3.6 kg External dimensions (W x H x D) 430 x 70 x 311 mm Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal Operating humidity 5% to 85% Laser Semiconductor laser, wavelength 650 nm... - Page 27 2. The dealer (or his service agent) who sold the product will be reimbursed for any labour provided in the repair of this LG equipment, for a period of 12 months from the original date of purchase. These claims must be made in accordance with the published scale of service charges and relevant claims procedure.
