- Page 1 HT502PH-D0_NA6SLLD_ENG DVD RECEIVER OWNER’S MANUAL MODEL: HT502PH HT502PH-D0 SH52PH-F, SH52PH-C, SH52PH-S, SH52PH-W Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
- Page 2 CAUTION: The apparatus should not be exposed to water CAUTION (dripping or splashing) and no objects filled with liquids, such RISK OF ELECTRIC SHOCK as vases, should be placed on the apparatus. DO NOT OPEN CAUTION concerning the Power Cord Most appliances recommend they be placed upon CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK...
-
Page 3: Table Of Contents
Introduction Maintenance and Service Maintenance and Service ....3 Before use ......4 Refer to the information in this chapter before Front Panel/Rear Panel . -
Page 4: Before Use
Introduction Before use Types of Playable Discs To ensure proper use of this product, please read this (8 cm / 12 cm disc) owner’s manual carefully and retain it for future reference. Video CD (VCD) (8 cm / 12 cm disc) This manual provides information on the operation Audio CD and maintenance of your DVD/CD Receiver. -
Page 5: Front Panel/Rear Panel
Front Panel/Rear Panel POWER DISC Tray DISPLAY Window VOLUME controller TUNING(-/+)/ SKIP SEARCH(. . /> > ) STOP (x) AUDIO IN connector PAUSE ( X X )/ MONO/STEREO (ST.) USB port FUNC.(-)/PLAY(B) Connect to a USB port of a memory Press and hold down this button device (USB memory etc.) about 3 seconds, then press... -
Page 6: Remote Control
Views the various displays of the RDS options To start a search for a specific PTY type. DIMMER Controls the TV. (LG TV only) (See page15) Changes brightness of the display window on the front panel during in power-on status. -
Page 7: Installation And Setup
Installation and Setup TV Connection Make one of the following connections, depending on Video connection the capabilities of your existing equipment. Connect the MONITOR OUT jack from the DVD/CD Receiver to the VIDEO IN jack on the TV using the Tips: video cable (V). -
Page 8: Optional Equipment Connection
Optional Equipment Connection OPTICAL IN connection (O) Auxiliary device DVD Player Connect an optical output of DVD Player (or Digital (or Digital Device etc) to the OPTICAL IN connector. Device, etc) VIDEO AUDIO (L) AUDIO IN connection (D) AUDIO (R) OPTICAL Connect a output of portable device (MP3 or PMP etc) To AUDIO OUT (L/R) -
Page 9: Speaker System Connection
Speaker System Connection Connect the speakers using the supplied speaker cables. To obtain the best possible surround sound, adjust the speaker parameters (volume, distance, etc.). Front speaker Front speaker (Left) (Right) Center speaker Rear speaker Rear speaker (Right surround) (Left surround) Subwoofer Notes: Be sure to match the speaker cable to the appropriate terminal on the components: + to + and –... -
Page 10: Displaying Disc Information On-Screen
Displaying Disc Information GENERAL OPERATION On - screen 1. Press SETUP. The Setup menu appears. 2. Use v / V to select the desired option then press You can display various information about the disc B to move to the second level. The screen shows loaded on-screen. -
Page 11: Display
DISPLAY Progressive Scan Progressive Scan Video provides the highest quality pictures with less flickering. If you are using the COMPONENT VIDEO OUT jacks, but are connecting the receiver to a standard (analog) television, set Progressive Scan to Off. If you are using the Component Video jacks for connection to a TV or monitor that is compatible with a progressive scan signal, set Progressive Scan to To Turn ON progressive scan:... -
Page 12: Audio
AUDIO 5.1 Speaker Setup Make the following settings for the built-in 5.1 channel Each DVD disc has a variety of audio output options. surround decoder. Set the receiver’s AUDIO options according to the type of audio system you use. 1. Press ENTER, and the 5.1 Speaker Setup menu appears. -
Page 13: Lock (Parental Control)
LOCK (Parental Control) Area Code Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 22. 1. Select “Area Code” on the LOCK menu then press B. 2. Follow the step 2 as shown previous paragraph (Rating). -
Page 14: Operation
Operation General features Buttons Operations Discs Z (OPEN / CLOSE) Opens or closes the disc tray. X (PAUSE) During playback, press X to pause playback. Press X repeatedly to play Frame-by-Frame. DivX SKIP (. / >) During playback, press SKIP (. or >) to go to the next chapter/track or to return to the beginning of the current chapter/track. -
Page 15: Additional Features
Your remote control is capable of operating your points. To enter a marker, press MARKER at the DVD/CD Receiver as well as limited functions of LG desired point on the disc. The Marker icon appears on the TV screen briefly. Repeat to enter up to nine Follow the instructions below to operate your LG TV. -
Page 16: Playing An Audio Cd Or Mp3/Wma File
Playing an Audio CD or Programmed Playback MP3/WMA file The program function enables you to store your favorite tracks from any disc in the receiver memory. A This unit can play Audio CDs or MP3/WMA files. program can contain 300 tracks. MP3/ WMA/ Audio CD 1. -
Page 17: Viewing A Jpeg File
Zoom Viewing a JPEG file JPEG Each time ZOOM is pressed the setting changes in This unit can play discs with JPEG files. the following order. Before playing JPEG recordings, read the notes on Zoom on y Zoom off JPEG Recordings on the right. Press v/ /M to enlarge the video image. -
Page 18: Playing A Divx Movie File
Playing a DivX Movie file DivX disc compatibility with this player is limited as follows: Using this DVD/CD Receiver you can play DivX disc. • Available resolution size of the DivX file is under 1. Insert a disc and close the tray. The MOVIE menu 800x600 (W x H) pixel. -
Page 19: Presetting The Radio Stations
Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM and AM (MW). Preset radio stations in the DVD/CD Receiver’s Before tuning, make sure that you have turned down memory first (see “Presetting radio stations” on the the volume. -
Page 20: Rds Operation
RDS Operation Programme Search (PTY) A major benefit of RDS is its ability to encode This unit is equipped with RDS (Radio Data System), broadcasts with Programme Type (PTY) codes that which brings a wide range of information to FM radio. indicate the type of material being broadcast. -
Page 21: Sleep Timer Setting
The SLEEP indicator and the sleep time appears in the display window. XTS-P ON The unique sound quality of the LG Technology 2. Each time you press SLEEP the setting creates the optimum sound for you to play the changes in the following order. -
Page 22: Reference
Reference Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian... -
Page 23: Troubleshooting
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Correction Symptom Cause • Plug the power cord securely into the • The power cord is disconnected. No power. wall outlet. • Insert a disc. (Check that the DVD or, •... - Page 24 Symptom Cause Correction • The antenna is positioned or connected • Connect the antenna securely. Radio stations cannot poorly. be tuned in. • Adjust the antennas and connect an external antenna if necessary. • The signal strength of the stations is too •...
-
Page 25: Specifications
Specifications Power supply Refer to main label. Power consumption Refer to main label. Net Weight 3.6 kg External dimensions (W x H x D) 430 x 70 x 311 mm Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal Operating humidity 5% to 85% Laser Semiconductor laser, wavelength 650 nm... - Page 26 P/NO : MFL40275845...
