PRODUCT NO.
BASE MODEL NO.
PLEB27T8CCA
PLEB27T8C
WIRING DIAGRAM - # 318046110
OWNER'S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200130
INSTALLATION INSTRUCTIONS - # 318201510
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
37057793G30S1
black
Publication No.
5995379376
021007
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
ELECTRIC
WALL OVEN
Model No.
PLEB27T8C
©2002 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire PLEB27T8C
Summary of Contents for Frigidaire PLEB27T8C
- Page 1 PRODUCT NO. BASE MODEL NO. PLEB27T8CCA PLEB27T8C WIRING DIAGRAM - # 318046110 OWNER’S GUIDE - # 318200919 TIMER INSTRUCTION SHEET - # 318200130 INSTALLATION INSTRUCTIONS - # 318201510 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG FACTORY NO.
-
Page 2: Control Panel
Publication No. PLEB27T8CCA 5995379376 CONTROL PANEL 10/02... - Page 3 DESCRIPTION 318030214 Panel,control ,black ,back 318192803 Panel,control ,stainless ,front 318010501 Clock/Timer,EOC 318028331 Trim,canopy 318015110 Bracket,clock mtg 318027310 Trim,vent 318037200 Cover,oven vent ,stainless 318029603 Trim,top 318022001 Relay Board 318022002 Relay Board,w/transformer 5303317199 Support,snap-in ,(3) 316037700 Seal,vent cover 316037801 Tape,vent cover 5303307406...
-
Page 4: Upper Oven
Publication No. PLEB27T8CCA 5995379376 UPPER OVEN 10/02... - Page 5 Rack,broiler pan 318025200 Shelf,oven 5303317977 Pan,broiler 5303317976 Insert,broiler pan 318089913 Switch,light 5308011085 Receptacle,oven light 5303013071 Bulb/Lamp,oven light 3201911 Cover,oven light ,glass 5304400195 Retainer,light cover 316111203 Sensor,oven temp probe 5303310526 Cover,hinge cutout 5303310514 Housing,oven light 318133758 Insulation,oven wrapper 318133749 Insulation,oven back 5303316994...
-
Page 6: Lower Oven
Publication No. PLEB27T8CCA 5995379376 LOWER OVEN 10/02... - Page 7 DESCRIPTION 318071502 Shield,oven top 318025300 Rack,oven 318025200 Shelf,oven 318089913 Switch,light 5308011085 Receptacle,oven light 5303013071 Bulb/Lamp,oven light 3201911 Cover,oven light ,glass 5304400195 Retainer,light cover 316111203 Sensor,oven temp probe 5303310526 Cover,hinge cutout 5303310514 Housing,oven light 318145515 Trim,bodyside ,(2) 318133758 Insulation,oven wrapper 318133749...
- Page 8 Publication No. PLEB27T8CCA 5995379376 DOOR 10/02...
- Page 9 Insulation,oven door 318156705 Liner,oven door 5303311174 Screw,10-24 x 3/8 318053100 Seal,oven door 318187930 Stainless Panel,oven door ,lower oven ,w/glass 318187932 Stainless Panel,oven door ,upper oven ,w/glass & nmplt 318172903 Stiffener,glass 318042300 Glass,oven door ,heat barrier ,(2) 318042000 Spacer,glass 318053000 Seal,rope 5303310511...
-
Page 10: Wiring Diagram
Publication No. PLEB27T8CCA 5995379376 WIRING DIAGRAM 10/02...
