Samsung SRD-450 Quick Start Manual

Ez view kit
Hide thumbs Also See for SRD-450:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
1.
Connecting with Other Device
2.
Installation
3.
Starting Up
4.
REC & Play
5.
Router & Port Forwarding Setting Up
6.
Web Browsing
7.
Monitoring
EZ View Kit
Quick Start Guide
SRD-450

Advertisement

loading

Related Manuals for Samsung SRD-450

Summary of Contents for Samsung SRD-450

  • Page 1 SRD-450 EZ View Kit Quick Start Guide Connecting with Other Device Installation Starting Up REC & Play Router & Port Forwarding Setting Up Web Browsing Monitoring...

  • Page 2: Connecting With Other Device

    CONNECTING WITH OTHER DEVICE Broadband Modem IP Router or HUB Local PC If you do not use the Internet, just follow the steps below:  11 12 13 14 15 16 24 English-...

  • Page 3: Installation

    INSTALLATION Connect the LAN cable and mouse. Connect the camera to the Video In port. The default connection for use of the Internet is as follows: Mouse Connect the Video and Audio Out connectors to the monitor. For a PC monitor, use the VGA connector for the connection.
  • Page 4 STARTING Up Press the [MENU] button on the remote control or press Connect the power source. the <MENU> button on the launcher menu. The SETUP menu screen appears. Select <SYSTEM SETUP> and enter password when login dialog appears. SYSTEM If the set begins working properly, use the virtual keyboard to enter the password (default: 4321) in the PASSWORD input box.
  • Page 5 REC & pLAY Press the [MENU] button on the remote control or press Select a desired date in the calendar, and a desired the <MENU> button on the launcher menu. timeline in the Time bar, and press the <PLAY> The SETUP menu screen appears. button.
  • Page 6 ROUTER & pORT FORWARDING SETTING Up The following is configuration for the Internet connection. When the router setting is done, select Virtual Server in This is a typical example. the “Advanced” tab where you can configure the Port Forwarding settings. Click “Apply” to apply your IP Router or HUB Cable/ADSL Modem settings.

  • Page 7: Web Browsing

    WEb bROWSING In the address bar of the Internet Explorer, enter the Set IP. Connect to the Web Viewer and enter the User ID and For the internal network, enter the Set Local IP and for the Password. external network, enter the DDNS address. Default ID: admin, PW: 4321 * Refer to the domain name of the set defined in the system information.
  • Page 8 MONITORING Using the iPhone 24-1 Press the <DiSP> button from the Launcher menu or press the [MoDE] on the remote control. Select the Safari browser. Enter the IP address or URL to connect. And touch the <go> button. http:// set IP Address: Port No(Default 8080) Ex)http://f05bb96.websamsung.net:8080 MENU BACKUP...
