Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FFC0723FW0
Series
134A
Color
white
Volts
115
Wiring Diagram 297010500
Owner's Guide 297080400
Market
North America
Energy Guide
216793915
Publication No.
5995463840
06/03/22
(EN/SERVICE/RLF)
365
Copyright
FREEZER CHEST
Model No.
FFC0723FW
©
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FFC0723FW
Summary of Contents for Frigidaire FFC0723FW
- Page 1 Product No. FFC0723FW0 Series 134A Color white Volts Wiring Diagram 297010500 Owner's Guide 297080400 Market North America Energy Guide 216793915 FREEZER CHEST Model No. FFC0723FW Publication No. 5995463840 06/03/22 (EN/SERVICE/RLF) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995463840 FFC0723FW0 DOOR 03/06...
- Page 3 POS. NO PART NO. 216480901 216061602 216923001 216113100 216858000 216816802 216446600 5303212828 5304406520 216922700 5303917276 # Functional Parts * Non-Illustrated Parts FFC0723FW0 DOOR DESCRIPTION Gasket, door seal, white Panel-inner lid, white Plug button, 1/4", white Panel-lid Screw, TH#8-18x.500AB, #10 Insert-nameplate Handle Clip, panel mtg Clip, panel mtg kit, (40)
- Page 4 Publication No: 5995463840 03/06 FFC0723FW0 CABINET P08C0673...
- Page 5 POS. NO PART NO. 216502600 297013600 216855702 216855706 216707200 21 # 216787700 297087400 216337700 216478800 216105500 216848200 131168200 216782000 216793915 5303305324 # Functional Parts * Non-Illustrated Parts FFC0723FW0 CABINET DESCRIPTION Plug, drain, interior Plug, drain, exterior Breaker, side Breaker-ends, white Knob, temp control Control-temperature Light, signal, assy w/bracket...
- Page 6 Publication No: 5995463840 P08S0355 03/06 FFC0723FW0 SYSTEM...
- Page 7 POS. NO PART NO. 5300120780 216938600 216952300 216707800 216056400 5308002681 29 # 216966300 216954200 216954300 216985000 216818300 216707700 # Functional Parts * Non-Illustrated Parts FFC0723FW0 SYSTEM DESCRIPTION Condenser Drier-filter Harness-main Screw, PH, 8-32 x 1/2, wiring harness Clip, compressor mtg, SPRING Grommet, compressor Compressor, w/o electricals Controller, compressor, 5 speed...
