READ AND SAVE THESE INSTRUCTIONS
Setting
5 - 6
9 - 10
P/N 216960000A (Mar 2004)
2
2
3
4
5
7
8
11
Advertisement
Table of Contents
Related Manuals for Frigidaire AFFU2068DW1
Summary of Contents for Frigidaire AFFU2068DW1
-
Page 1: Table Of Contents
READ AND SAVE THESE INSTRUCTIONS Product Registration Energy Saving Ideas Important Safety Instructions First Steps Setting the Temperature Control Freezer Optional Features Care and Cleaning Power Failure/Freezer Failure Avoid Service Checklist Warranty P/N 216960000A (Mar 2004) 5 - 6 9 - 10... -
Page 2: Product Registration
This Owner’s Guide provides operating instructions for your model. Use your freezer only as instructed in this Owner’s Guide. • The freezer should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of direct sunlight. -
Page 3: Important Safety Instructions
A child might suffocate if he crawls into a freezer to hide or play. Remove the door of a freezer when not in use, even if you plan to discard the freezer. Many communities have laws requiring you to take this safety precaution. -
Page 4: First Steps
Leveling The freezer must have all bottom corners resting firmly on a solid floor. The floor must be strong enough to support a fully loaded freezer. NOTE: It is VERY IMPORTANT for your freezer to be level in order to function properly. If the freezer is not leveled during installatioin, the door may be misaligned and not close or seal properly, causing cooling, frost, or moisture problems. -
Page 5: The Temperature Control
NOT be loaded into freezer until freezer has operated for 4 hours. • When loading freezer, freeze only 3 pounds of fresh food per cubic foot of freezer space at one time. Distribute packages to be frozen evenly throughout the freezer. - Page 6 Security Lock with Pop-Out Key This security lock fastens the door snugly, ensuring that stored food is secure. To lock or unlock the freezer, push the key into the lock and turn. The key pops out of the lock after it has been turned.
-
Page 7: Care And Cleaning
Pan (some models) beneath the drain outlet (Figure 2). A ½ inch garden hose adapter can be used to drain the freezer directly into a floor drain (Figure 3). If your model is not equipped with an adapter, one can be purchased at most hardware stores. -
Page 8: Power Failure/Freezer Failure
If the power failure continues, pack seven or eight pounds of dry ice into the freezer every 24 hours. Look in the Yellow Pages under "Dry Ice," "Dairies," or "Ice Cream Manufacturers" for local dry ice suppliers. Always wear gloves and use caution when handling dry ice. -
Page 9: Avoid Service Checklist
Temperature control is in the OFF position. See Setting the Temperature Control section. • Freezer may not be plugged in or plug may be loose. Be sure plug is tightly pushed into electrical outlet. • House fuse has blown or circuit breaker has tripped. Check / reset circuit breaker or replace fuse with 15 amp time delay fuse. - Page 10 Foods with strong odors are in the freezer. Cover the food tightly. • Freezer is not level. It rocks on the floor when it is moved slightly. This condition can force the cabinet out of square and misalign the door.
-
Page 11: Warranty
FREEZER WARRANTY Your freezer is protected by this warranty WARRANTY PERIOD FULL ONE-YEAR One year from original purchase date WARRANTY Second through fifth LIMITED 2 years from original YEAR WARRANTY purchase date (Sealed System) Sixth through tenth LIMITED 6 years from original... - Page 12 Notes...
