Frigidaire AEQB7000ES0 Operating Instructions Manual

Before Operating Your Dryer

Read your dryer Owner's Guide. It has important
safety and warranty information. It also has many
suggestions for best drying results.
To reduce the risk of fire, electric shock
or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS in your dryer Owner's Guide before
operating this appliance.

Operating Steps

Read "Drying Procedures" in your Owner's Guide. It
explains these operating steps in detail.
1. Prepare items for drying.
2. Check that lint filter is clean and in place.
3. Load the dryer. If desired, add a dryer fabric
softener sheet. Close the door.
4. Select the appropriate cycle and settings for
each load.
• Turn the Cycle Selector knob to select the cycle.
The estimated drying time will be displayed.
• A suitable drying temperature, dryness level and
options will automatically be indicated for each
cycle. See the "Dryer Setting Chart" for more
details.
• To change the temperature and dryness level,
press Temperature or Dryness until the desired
selections are made.
• To select or delete an option, press Options;
then, while the indicator is blinking, press
Select. The indicator will light when the option
has been selected. it will no longer be lighted
when the option has been deleted.
• If a temperature, dryness level or option is not
available for a cycle, it will not light.
DRYER OPERATING INSTRUCTIONS
• Adjustments to the cycle will be remembered
each time that cycle is selected in the future.
• To return to factory settings, press Start/Pause
and Select at the same time and hold until the
signal sounds.
5. Press Start/Pause to begin the cycle.
• To pause the cycle press Start/Pause. To
resume the cycle, press Start/Pause again.
• To stop or change the cycle, press Cancel.
6. A signal will sound at the end of the cycle and
periodically during Extended Tumble when the
Signal option is selected. When the cycle
ends, remove items immediately and hang or fold.
7. Clean the lint screen after every load.

Cycle Selection

Turn the Cycle Selector knob to the desired cycle. For
best results, follow the fabric care label instructions on
items to be dried. If the selection is changed after the
cycle starts, the indicator lights will blink, the signal
will beep and "ERR" will be displayed. To change the
selection after the cycle has begun, press Cancel
before making another choice. Just turning the knob
to another selection will not change the cycle. The
signal will beep and the status lights will flash, but the
original cycle will continue.
Auto Dry
Auto Dry cycles take the guesswork out of drying time.
Loads dried using the Towels, Heavy Duty, Normal, Perm
Press, and Delicates cycles will dry automatically at
the selected temperature to the desired dryness level.
The dryer uses sensing bars to sense the moisture
level of the load as it tumbles through heated air. Auto
Dry cycles save time and energy and protect fabrics.
The estimated drying time will be displayed for about
5 minutes. Then the display will change to "Ad" to
indicate drying time is automatically being determined
by the sensors. When the load has reached the
selected dryness level, it will continue to tumble,
unheated, during a Cool Down period. This helps reduce
wrinkling and makes items easier to handle during
unloading. The estimated Cool Down time will be
displayed.
Drying time varies depending on size and dampness of
load and fabric type. If the load is too small or almost
dry, the sensing bars may not detect enough moisture
to continue the cycle and the cycle may end after a few
minutes. Select a Timed Dry setting to dry such loads.
Room temperature and humidity, type of installation and
electrical voltage or gas pressure can also affect drying
time.
Towels
Select this Auto Dry cycle for towel loads.
Heavy Duty
Select this Auto Dry cycle for sturdy work clothes.
Normal
Select this Auto Dry cycle for cotton items.
Perm Press
Select this Auto Dry cycle for cottons and blends with
a no-iron finish.
Delicates
Select this Auto Dry cycle for knits and delicate items.
PN 134609300 (0511)
