Frigidaire AEQB6000E Factory Parts Catalog

Frigidaire aeqb6000e: supplementary guide
Hide thumbs

Advertisement

Quick Links

Download this manual
P16L0043.eps P16V0078.eps P16d0035.eps P16C0232.eps P16M0024.eps
134682200e.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
AEQB6000ES0
Series
Frigidaire
Market
North America
Color
white
Volts
240
Wiring Diagram
134682200
Owner's Guide
134609100
Installation Instructions 134721800
Operating Instructions 134609300
Publication No.
5995460671
06/02/10
(EN/SERVICE/KC)
361

ELECTRIC DRYER

Model No.
AEQB6000E
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire AEQB6000E

Summary of Contents for Frigidaire AEQB6000E

  • Page 1: Electric Dryer

    Series Frigidaire Market North America Color white Volts Wiring Diagram 134682200 Owner's Guide 134609100 Installation Instructions 134721800 Operating Instructions 134609300 ELECTRIC DRYER AEQB6000E Publication No. 5995460671 06/02/10 (EN/SERVICE/KC) © Copyright 2006 Electrolux Home Products, Inc. Model No. All rights reserved.
  • Page 2 Publication No: 5995460671 02/06 AEQB6000ES0 CABINET/DRUM P16V0078...
  • Page 3 Baffle, heater shield Screw, 10-16AB x 0.375 Bracket, top panel mtg., rear Drum, dryer, stnls stl back, painted wrap, service kit Glide, drum Screw, hex washer head, 8-18 x 0 .375, cup point Screw, quadrex head, 10-14 x 1.00, vane mtg., special...
  • Page 4 Publication No: 5995460671 AEQB6000ES0 FRONT PANEL/LINT FILTER 02/06...
  • Page 5 POS. NO PART NO. 134417000 131168200 134382900 131845802 134440100 134440200 5308027429 134134700 134556210 131744202 134548000 26 # 131843101 131450300 134440000 134610100 131243700 134559200 134559410 131205100 134559510 134559100 134559300 134720900 134611800 134580300 134558510 134558400 134554500 134548100 131303300 134529600 134558600 134550600 58 # 131843500 58*# 131862800...
  • Page 6 Publication No: 5995460671 AEQB6000ES0 CONTROLS/TOP PANEL 02/06...
  • Page 7 POS. NO PART NO. 134557201 134551200 134553100 134556500 134347700 134555500 134553400 134595600 134553300 134557501 134552800 134600000 134402900 22 # 134602100 23 # 134394400 134394200 134557000 134178901 134365000 134553200 134557300 57 # 134503300 # Functional Parts * Non-Illustrated Parts AEQB6000ES0 CONTROLS/TOP PANEL DESCRIPTION Control Board, printed circuit, with housing Knob, program...
  • Page 8 Publication No: 5995460671 AEQB6000ES0 MOTOR 02/06...
  • Page 9 Spacer, idler Thermistor, control Screw, hex head, 1/4-20T x 1.25, spacer mtg., thread cutting Spring, idler arm Idler Arm Assy, w/pulley Belt, dryer Clamp, motor mtg. Motor & Pulley Assy Screw, pan head, 8-18AB x 0.375 Bracket, motor mtg Seal, exhaust tube Screw, pan head, 8-18B x 0.31...

  • Page 10: Wiring Diagram

    Publication No: 5995460671 AEQB6000ES0 WIRING DIAGRAM 02/06...
