Frigidaire AEQ6000CE Factory Parts Catalog

Frigidaire aeq6000ce: supplementary guide
Hide thumbs

Advertisement

Quick Links

Download this manual
P16L0043.eps P16V0081.eps P16d0035.eps P16C0232.eps P16M0024.eps
134682200e.eps
Electrolux Major Appliances
North & Latin America
5855 TERRY FOX WAY
MISSISSAUGA, ONTARIO, CANADA L5V
3E4
Product No.
AEQ6000CES0
Series
Frigidaire
Market
Canada
Color
white
Volts
240
Wiring Diagram
134682200
Owner's Guide
134598600
Installation Instructions 134722000
Operating Instructions 134598200
Energy Guide
134598000
Publication No.
5995460655
06/02/09
(EN/SERVICE/KC)
361

ELECTRIC DRYER

Model No.
AEQ6000CE
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire AEQ6000CE

Summary of Contents for Frigidaire AEQ6000CE

  • Page 1: Electric Dryer

    Market Canada Color white Volts Wiring Diagram 134682200 Owner's Guide 134598600 Installation Instructions 134722000 Operating Instructions 134598200 Energy Guide 134598000 ELECTRIC DRYER AEQ6000CE Publication No. 5995460655 06/02/09 (EN/SERVICE/KC) © Copyright 2006 Electrolux Home Products, Inc. Model No. All rights reserved.
  • Page 2 Publication No: 5995460655 02/06 AEQ6000CES0 CABINET/DRUM P16V0081...
  • Page 3 Baffle, heater shield Screw, 10-16AB x 0.375 Bracket, top panel mtg., rear Drum, dryer, stnls stl back, painted wrap, service kit Glide, drum Screw, hex washer head, 8-18 x 0 .375, cup point Screw, quadrex head, 10-14 x 1.00, vane mtg., special...
  • Page 4 Publication No: 5995460655 AEQ6000CES0 FRONT PANEL/LINT FILTER 02/06...
  • Page 5 POS. NO PART NO. 134417000 131168200 134382900 131845802 134440100 134440200 5308027429 134134700 134556210 131744202 134548000 26 # 131843101 131450300 134440000 134610100 131243700 134559200 134559410 131205100 134559510 134559100 134559300 134720900 134611800 134580300 134558510 134558400 134554500 134548100 131303300 134529600 134558600 134550600 58 # 131843500 58*# 131862800...
  • Page 6 Publication No: 5995460655 AEQ6000CES0 CONTROLS/TOP PANEL 02/06...
  • Page 7 POS. NO PART NO. 134557201 134551200 134553100 134556500 134347700 134555500 134553400 134595600 134553300 134557501 134552800 134600000 134402900 22 # 134602100 23 # 134394400 134394200 134557000 134178901 134365000 134553200 134557300 57 # 134503300 # Functional Parts * Non-Illustrated Parts AEQ6000CES0 CONTROLS/TOP PANEL DESCRIPTION Control Board, printed circuit, with housing Knob, program...
  • Page 8 Publication No: 5995460655 AEQ6000CES0 MOTOR 02/06...
  • Page 9 Spacer, idler Thermistor, control Screw, hex head, 1/4-20T x 1.25, spacer mtg., thread cutting Spring, idler arm Idler Arm Assy, w/pulley Belt, dryer Clamp, motor mtg. Motor & Pulley Assy Screw, pan head, 8-18AB x 0.375 Bracket, motor mtg Seal, exhaust tube Screw, pan head, 8-18B x 0.31...

  • Page 10: Wiring Diagram

    Publication No: 5995460655 AEQ6000CES0 WIRING DIAGRAM 02/06...
