RD-8 MKII User Manual

11. Settings

The Settings functions are listed below. All features are accessed by pressing the SETTINGS button and selecting the associated step key.
11.1 MIDI
To enter the MIDI settings page press SETTINGS, select MIDI (STEP BUTTON 1) and
use the TAP/HOLD key to access the various pages described below:
1. Choose the MIDI channel from 1-16, All or Out (The Output setting follows
the MIDI OUT setting in the next step below) for the incoming MIDI IN port.
2. Select the MIDI OUT channel from 1-16.
3. Turn on FORWARD TO USB to send the MIDI output of the unit to the USB OUT.
4. SOFT THRU on/off turns the MIDI OUT jack into a 2nd MIDI THRU port by
sending the data from the MIDI IN to the MIDI OUT port.
5. DEVICE ID sets the units ID from 1-16. This is helpful when dealing with
multiple units via SysEx.
11.2 USB
To enter the USB MIDI settings page press SETTINGS, select USB MIDI
(STEP BUTTON 2) and use the TAP/HOLD key to access the various pages
described below:
1. Choose the USB MIDI channel from 1-16, All or Out (The Output setting
follows the USB MIDI OUT setting in the next step below) for the incoming
USB MIDI IN port.
2. Select the USB MIDI OUT channel from 1-16.
3. Turn on FORWARD TO MIDI sends the USB MIDI output of the unit to the
MIDI OUT.
NOTE: Care should be taken with Forward to MIDI/USB settings when both MIDI
and USB interfaces are connected to the same computer, as there is a possibility
of data loops occurring.
11.3 CLOCK
To enter the CLOCK settings page press SETTINGS, select CLOCK (Step key 3) and
use the TAP/HOLD key to access the various pages described below:
Tempo Preference
Swing Preference
Probability Preference
Flam Preference
Analog Clock Mode
Tempo Preference Options:
1. Global, where all patterns play at the set tempo, even if a different tempo is
stored within a pattern or song.
2. Song, where all patterns within in a song will follow the tempo set within
that song, even if a different tempo is stored within a pattern.
3. Pattern, where all patterns will play at the tempo they have been saved with
and not be affected by global or song tempo changes.
Swing Preference Options:
1. Global, where all patterns Swing settings, even if a different Swing setting is
stored within a pattern or song.
2. Song, where all patterns Swing settings will follow the setting a within that
song, even if a different Swing setting is stored within a pattern.
3. Pattern, where all patterns will play with the Swing settings they have been
saved with and not be affected by global or song Swing changes.
Probability Preference Options:
1. Global, where all the patterns probability settings, even if a different
probability setting is stored within a pattern or song.
2. Song, where all patterns probability settings will follow the probability
setting within that song, even if a different probability setting is stored
within a pattern.
3. Pattern, where all patterns will play with the probability settings they have
been saved with and not be affected by global or song probability changes.
Flam Preference Options:
1. Song, where all patterns flam settings will follow the flam setting within
that song, even if a different flam setting is stored within a pattern.
2. Pattern, where all patterns will play with the flam settings they have been
saved with and not be affected by song flam changes.
Analog Clock Modes
PPQ (Pulses Per Quarter) is the smallest unit of time used for sequencing note
and automation events, both by step sequencers and in the MIDI standard. Most
MIDI sequencers allow the number of PPQ to be varied for more or less temporal
resolution depending on the needs of the performer. The default is 24 PPQ, as
this is the most commonly used setting.
This function allows communication with various analogue clock types as
listed below:
Clock Settings
1 PPS
1 PPQ
2 PPQ
4 PPQ
24 PPQ
48 PPQ
