- Page 1 │ 2TMD041800D0010 30.03.2019 Product manual ABB-Welcome IP H81381P.-. IP pushbutton outdoor station H81381P.-.-02 IP pushbutton outdoor station...
-
Page 2: Table Of Contents
Table of contents Notes on the instruction manual ........................3 Safety ................................3 Intended use ..............................4 Environment ..............................5 ABB devices ............................5 Product description ............................6 Control elements ..........................6 Interfaces ............................7 Locks and connections ........................8 Technical data ............................... -
Page 3: Notes On The Instruction Manual
Please keep this manual in a safe place. If you pass the device on, also pass on this manual along with it. ABB accepts no liability for any failure to observe the instructions in this manual. Safety... -
Page 4: Intended Use
Intended use Intended use As part of the ABB-Welcome IP system, this device can only be used with accessories from that system. Security mode This outdoor station runs in "Security mode" by default to guarantee high security. In "Security mode", this outdoor station requires a certificate issued by the management software before it can function normally. -
Page 5: Environment
ABB devices All packaging materials and devices from ABB bear the markings and test seals for proper disposal. Always dispose of the packing materials and electric devices and their components via an authorized collection facility or disposal company. -
Page 6: Product Description
Product description Product description Control elements Function Camera Speaker and microphone integration Round pushbutton End strip │6 Product manual 2TMD041800D0010... -
Page 7: Interfaces
Product description Interfaces Function Reset button Micro USB update connector Plug-in clamps (DC+...GND) for standalone power supply Plug-in clamps (LOCK...GND) for door opener Plug-in clamps (COM...NC...NO) for floating output, door opener LAN (PoE) Connector for next module Connector for exit button Connector for the sensor used for door status detection Connector for 5"... -
Page 8: Locks And Connections
Product description Locks and connections Lock type Operation type Voltage Wiring type Type A Electrical strike Power on to open lock, 12V VDC/AC Type B Electrical strike Type B Power on to open lock, 24V VDC/AC Type A Electrical rim Power on to open 12 VDC lock, 12 V... -
Page 9: Technical Data
Technical data Technical data Designation Value Rating voltage 24 V DC Operating voltage range 20-27 V DC 27 V DC, 300 mA Rating current 24 V DC, 330 mA Operating temperature -40 °C…+55 °C Product dimensions 135mm x 276.9 mm × 17.6 mm Camera type CMOS Camera viewing angle... -
Page 10: Mounting/Installation
Mounting/Installation Mounting/Installation Warning Electric voltage! Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death. – Disconnect the mains power supply prior to installation and/or disassembly! –... -
Page 11: Mounting
Mounting/Installation Mounting 7.2.1 Preparation Use gloves to protect yourself against cuts. 7.2.2 Wiring │11 Product manual 2TMD041800D0010... -
Page 12: Surface-Mounted Installation
Mounting/Installation 7.2.3 Surface-mounted installation 32 mm 40 mm 71 mm 7.2.4 Flush-mounted installation 1. Flush-mounted without pre-installation box 117 mm 46 mm │12 Product manual 2TMD041800D0010... - Page 13 Mounting/Installation 2. Flush-mounted with pre-installation box 126 m m 68 m m │13 Product manual 2TMD041800D0010...
-
Page 14: Cavity Wall Installation
Mounting/Installation 7.2.5 Cavity wall installation │14 Product manual 2TMD041800D0010... -
Page 15: Dismantling
Mounting/Installation 7.2.6 Dismantling 7.2.7 Replacing the nameplate Installation situations Note The following installation situations must be avoided without fail to ensure picture quality: ■ Direct light ■ Direct sunlight ■ Extremely bright picture background ■ Highly reflective walls on the opposite side of the door station ■... -
Page 16: Commissioning
Commissioning Commissioning The outdoor station must be configured via the indoor station. Step1: Outdoor station enters engineering mode Power on the outdoor station, wait a while until all 3 LED indicators go out. ■ ■ Hold the first button on the outdoor station for 10 s until all 3 LED indicators start to flash. The outdoor station will quit engineering mode after 5 minutes. - Page 17 Commissioning On the "System settings" screen, click "Engineering settings", enter the engineering password (default is 345678) to enter the settings page. Step3: Indoor station configures outdoor station On the "Engineering settings" screen, click "Outdoor station settings" to configure the outdoor station.
-
Page 18: Operation
Operation Operation Calling a resident Press the button to start a call (default) and press again to restart the call. Calling the guard unit If the outdoor station has been configured via the indoor station, we can press the pushbutton to call the designated guard unit. -
Page 19: Turn On The Light
Operation Turn on the light If the outdoor station is configured by the indoor station, we can press the pushbutton to switch on the light connected to the IP actuator. Please refer to the product manual for the IP touch 7". │19 Product manual 2TMD041800D0010... -
Page 20: Fcc
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Only operate the device in accordance with the instructions supplied. -
Page 21: Cyber Security
H81381P.-. product, the network, its system and interfaces against any kind of security breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information. ABB Ltd and its affiliates are not liable for damages and/or losses related to such security breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information. -
Page 22: Deployment Guideline
Malware prevention solution The H81381P.-. device is not susceptible to malware, because custom code cannot be executed on the system. The only way to update the software is by firmware upgrades. Only firmware signed by ABB can be accepted. 11.7 Password rule The user must change the engineering password when accessing the engineering settings for the first time. - Page 23 We reserve the right to at all times make technical changes as well as changes to the contents of this document without prior notice. The detailed specifications agreed to at the time of ordering apply to all orders. ABB accepts no responsibility for possible errors or incompleteness in this document.
