ABB Welcome M25102 C Series Manual

Outdoor station
Hide thumbs Also See for Welcome M25102 C Series:
Table of Contents

Advertisement

Quick Links

VER:1.1 │
ABB-Welcome
Pos : 2 /Di nA4 - Anleitung en Online/Inhalt/KN X/D oorEntr y/83220- AP- xxx/Titelbl att - 83220-AP- xxx - ABB @ 19\mod_1323249806476_15.doc x @ 111084 @ @ 1
M25102xC
M25102xA-x-
M25102xPx.
M25102xK-x.
M25102xCR.
5102xDN
5101xPx
Outdoor station
│ 10.09.2015

Advertisement

Table of Contents
loading

Related Manuals for ABB Welcome M25102 C Series

Summary of Contents for ABB Welcome M25102 C Series

  • Page 1 VER:1.1 │ │ 10.09.2015 ABB-Welcome Pos : 2 /Di nA4 - Anleitung en Online/Inhalt/KN X/D oorEntr y/83220- AP- xxx/Titelbl att - 83220-AP- xxx - ABB @ 19\mod_1323249806476_15.doc x @ 111084 @ @ 1 M25102xC M25102xA-x- M25102xPx. M25102xK-x. M25102xCR. 5102xDN 5101xPx...
  • Page 2 Module family Camera module Audio module Audio module Audio module Nameplate module 1/2 button 2/4 button Pushbutton Round pushbutton Round pushbutton Round pushbutton Pushbutton 4/8 button 1 button 2 button 3 button 3/6 button Round pushbutton Round pushbutton Round pushbutton Keypad (3 versions) Display with ID 1 button, with NFC/IC...

  • Page 3: Table Of Contents

    Pos : 4 /Busch-J aeger (Neus truktur)/M odul-Str uktur/Online-Dokumentation/Inhal ts verz eic hnis (--> Fü r alle D okumente <--)/Inhalts verz eichnis @ 19\mod_1320649044386_15.doc x @ 109653 @ @ 1 Safety ......................5 Intended use ....................5 Environment ....................5 ABB devices ................. 5 Terminal description ..................7 Audio module ................7 4.1.1 Lock connected with terminals 3 and 4 ........
  • Page 4 ABB-Welcome Requirements for the electrician ..........60 General installation instructions ..........61 Mounting ..................62 === Ende der Liste fü r T extmar ke TOC === — 4 —...

  • Page 5: Safety

    ABB devices Pos : 13 /Busc h-J aeg er (Neustr uktur)/Modul- Struktur /Online-Dokumentati on/U mwel t (--> Fü r alle D okumente <--)/Hinweis e/Hi nweis - U mwelt - ABB El ektr ogeräte @ 19\mod_1323162745839_15.doc x @ 110867 @ @ 1 All packaging materials and devices from ABB bear the markings and test seals for proper disposal.
  • Page 6 ABB-Welcome Environment ABB products meet the legal requirements, in particular the laws governing e lectronic and electrical devices and the REACH ordinance. (EU-Directive 2002/96/EG WEEE and 2002/95/EG RoHS) (EU-REACH ordinance and law for the implementation of the ordinance (EG) No.1907/2006)

  • Page 7: Terminal Description

    ABB-Welcome Terminal description Terminal description Audio module Function LED flashes slowly, indicating a call has been established LED flashes fast, indicating that the system is busy LED illuminates, indicating possible communication. LED illuminates, indicating the door is unlocked Call pushbuttons...
  • Page 8 ABB-Welcome Terminal description Functions Connector for camera module Connector for device software update Plug-in clamps (COM-NC-NO) for floating output, door opener (30VAC/DC Plug-in clamps (Lock-GND) for door opener (18V 4A impulsive, 250 mA holding) Plug-in clamps (DC-GND) for additional power supply...
  • Page 9 ABB-Welcome Terminal description 3->OFF, 4->ON=call guard unit/call indoor station 3->ON, 4->ON=switch on lighting/call guard unit Adjust the loudspeaker volume. *Adjust the door lock release time, 1-10s (available for the lock connected with the default lock) — 9 —...
  • Page 10 ABB-Welcome Terminal description *Default lock (1st lock): Released by “Unlock” button of the indoor station. Factory setting is LOCK-GND. 2nd lock: Released by programmable button “1” of the indoor station. Factory setting is COM- NC-NO. — 10 —...
  • Page 11 ABB-Welcome Terminal description Change default lock Default lock can be set at either "Lock-GND" or "NO-NC-COM" Set outdoor station address ="0" Short circuit the "Exit" two terminals for 3s to enter the setting mode (3 LED flashes green to show the setting mode for aluminum outdoor station) (prompt tone “di”...
  • Page 12 ABB-Welcome Terminal description Set the lock time of the default lock Set the time by the potentiometer, from 1-10s Set the lock time of the 2nd lock Set outdoor station address ="0" Short circuit the “DS” two terminals for 3s to enter the setting mode (3 LED flashes green to show the setting mode for aluminum outdoor station) (Prompt tone “di”...

  • Page 13: Lock Connected With Terminals 3 And 4

    ABB-Welcome Terminal description 4.1.1 Lock connected with terminals 3 and 4 — 13 —...

  • Page 14: Camera Module

    ABB-Welcome Terminal description Camera module Functions Connector for additional analog camera Connector for audio module Jumper for setting the video format: PAL /NTSC Adjust the camera view area — 14 —...

  • Page 15: Analog Camera Connected With Terminal 1

    ABB-Welcome Terminal description 4.2.1 Analog camera connected with terminal 1 All the cameras with the video output of 1Vp-p 75Ω ,CVBS (composite video broadcast signal) can be connected with the camera module. Generally, the transmission distance from the analog camera to the outdoor station can reach up to 50 meters by coax cables or about 10 meters by other types of cables.

  • Page 16: Detached Camera Connection

    ABB-Welcome Terminal description 4.2.2 Detached camera connection Camera module can be used as a detached camera. Wiring is shown below. 3 pairs 2-wire bus together Max:10 metres — 16 —...

  • Page 17: Round Pushbutton Module

    ABB-Welcome Terminal description Round pushbutton module Functions Program button Connector for previous module Connector for device software update Connector for Wiegand output. Default format is 26 bits, it can also be extended to 34 bits. Connector for next module — 17 —...
  • Page 18 Lighting switch/call guard unit function is always assigned to the 1st/2nd button, which is set by audio module. User names can be printed by using the labellling tool of the ABB-Welcome configuration software. The round pushbutton module with NFC/IC card reader supports the NFC/IC card.

  • Page 19: Pushbutton Module

    ABB-Welcome Terminal description Pushbutton module Functions Connector for previous module Connector for next module Functions Regardless of the structure of the pushbutton module, the button numbers are listed from top to bottom and from left to right (in the double column mode.)
  • Page 20 ABB-Welcome Terminal description Lighting switch / call guard unit function is always assigned to the 1st/2nd button. User names can be printed by the using the labelling tool of the ABB- Welcome configuration software. — 20 —...

  • Page 21: Keypad Module

    ABB-Welcome Terminal description Keypad module Functions Program button Connector for previous module Connector for device software update USB connector for connection to the PC: Download/upload the configuration. Connector for next module — 21 —...
  • Page 22 ABB-Welcome Terminal description Functions Call resident A visitor inputs an indoor station number (001) or apartment number (e.g. 0101, programmed in advance) to call a resident. *Also, the visitor can select a resident name with the button or the button of the accompanying display module to make a call.

  • Page 23: Display And Card Reader Module

    ABB-Welcome Terminal description Display and card reader module Functions Program button Connector for previous module Connector for device software update Connector for Wiegand output USB connector for connecting to the PC: Download/upload the Configuration. Connector for the next module Functions...
  • Page 24 ABB-Welcome Terminal description LCD display Supports ID or IC card. Swipe the registered card to release the door lock. The card can be programmed through the module itself, or by using a PC to download the program file. (M251021CR is accompanied with an ID card reader, while the M251022CR is accompanied with an IC card reader.)

  • Page 25: Nameplate Module

    ABB-Welcome Terminal description Technical specification M251021CR: Display module with ID card reader Work 125KHz frequency Standard ISO18000-2 Support EM4100, EM4205, EM4305, EM4450, TK4100, T5567/T5577 Compatible card HID 2 Output Wiegand 26, 34 bit format M251022CR: Display module with IC card reader Work 13.56MHz...
  • Page 26 Connector for previous module Connector for next module Labeling of the nameplate module can be printed by using the labelling tool of the ABB- Welcome configuration software. Pos : 18 /DinA4 - Anl eitungen Onli ne/Ueberschriften/1./Bedi enung @ 18\mod_1302613924165_15.doc x @ 103365 @ 1 @ 1...

  • Page 27: Operation

    ABB-Welcome Operation Operation Pos : 19 /DinA4 - Anl eitungen Onli ne/Ueberschriften/2./Nor maler Betrieb @ 18\mod_1302768820965_15.doc x @ 103540 @ 2 @ 1 Pushbutton outdoor station Pos : 20 /DinA4 - Anl eitungen Onli ne/Ueberschriften/3./Bedi enel emente @ 20\mod_1323260220559_15.doc x @ 111647 @ 3 @ 1 5.1.1...
  • Page 28 ABB-Welcome Operation Functions 3-> ON, 4->OFF Switch on light. The light is connected with a switch actuator. The address of the switch actuator must be the same as the address of this outdoor station. Call apartment 01 Call apartment 02...
  • Page 29 ABB-Welcome Operation Guard unit Functions 3-> ON, 4-> ON Switch on lights Call guard unit Call apartment 01 — 29 —...
  • Page 30 ABB-Welcome Operation Configure pushbutton in single or double column modes Functions 2-> OFF Call apartment 01 Call apartment 02 Call apartment 03 Call apartment 04 Functions 2-> ON Call apartment 01 Call apartment 02 Call apartment 03 Call apartment 04...

  • Page 31: Setting The Language For The Voice Messages (If The Audio Module Has A Speech Synthesis Function)

    ABB-Welcome Operation Call apartment 07 Call apartment 08 Guard unit Functions 2-> ON,3-> ON, 4-> ON Switch on lights Call the guard unit Call apartment 01 Call apartment 02 Call apartment 03 Call apartment 04 Call apartment 05 Call apartment 06 5.1.2...
  • Page 32 ABB-Welcome Operation 1st button Single column Double column — 32 —...
  • Page 33 ABB-Welcome Operation Pushbutton outdoor station used as gate station If pushbutton outdoor station is set as a gate station, the gateway as an important system device must be used and it must be set as floor gateway mode. Apartment 01 A...

  • Page 34: Pushbutton Outdoor Station With Display Module

    ABB-Welcome Operation Pushbutton outdoor station with display module The display and card reader module can be assembled with a push button outdoor station. The user can swipe cards to open the door. For this combination, a master card is needed for an electrician to manage this outdoor station.
  • Page 35 ABB-Welcome Operation 30s over, to exit the settings menu. Swipe the MASTER 5s over, choose current Swipe the MASTER option card card, enter the setting Proximity Card Menu_________√ Menu_________05 Card--- ∧ ==＞ ==＞ ==＞ Register Card--- ∧ Program Card--- ∧...

  • Page 36: Pushbutton Outdoor Station With Keypad Module

    ABB-Welcome Operation Pushbutton outdoor station with keypad module The keypad module can be assembled with a push button outdoor station and users can enter the password to open the door. Users can enter the system settings menu by using the following steps. (Press # to confirm and * to cancel.
  • Page 37 ABB-Welcome Operation => *Reset the system password of keypad module: It is possible to reset the system password to the factory setting if you have forgotten it. The restoration of default factory settings does not delete the rest of the information programmed on the system, such as user names and other settings.

  • Page 38: Round Pushbutton Outdoor Station With Ic/Nfc

    ABB-Welcome Operation Round pushbutton outdoor station with IC/NFC Enroll the cards For round pushbutton module with NFC/IC card reader, cards can be enrolled or deleted. A maximum of 500 cards can be supported. Programming Function Command Create admin card Swipe card 1x...
  • Page 39 ABB-Welcome Operation Reset to factory default Function Command Disconnect the power supply. —— Reconnect the power supply. White Reset to factory Long-press the “program” button for 5s Red, green, default within 60s. orange cycle Finish reset. —— Technical specifications for round pushbutton module with IC/NFC: Work frequency 13.56MHz...
  • Page 40 ABB-Welcome Operation Set the Wiegand format 1. Swipe admin card to enter system setting. (Orange LED is on.) 2. Short press 1st button to change the Wiegand format to 26 bit or 34 bit. (Default is 26 bit.) The different format is indicated by the LED and sound feedback.
  • Page 41 To the play store (https://play.google.com/store/apps/details?id=com.abb.allegro3_nfcdooropener&hl=en ) 1. Download and install the ABB door opener app from Google Play Store. 2. Turn on the NFC function of your device. 3. Enter setting mode of your round pushbutton module.

  • Page 42: Keypad Outdoor Station

    ABB-Welcome Operation Keypad outdoor station 5.5.1 Call a resident (3 types) Physical address The physical address is the internal code that the outdoor station will send through the bus connection to indoor stations or other devices in the system. For each apartment, physical address means the address of an indoor station that is installed in the apartment.
  • Page 43 ABB-Welcome Operation Physical Add.: Logic Add.: 0101 Turn on the “Logic address” call mode #* system password # => system setting => Configurations => Call Mode Call Mode_______ No. of digit: ∧ Physical Add. ==＞ Logic Add.-------- (1-8 Digits) ∨...

  • Page 44: Call The Guard Unit

    ABB-Welcome Operation 5.5.2 Call the guard unit Press the button to make a call to a guard unit. Accept the call 30 s 120 s ==＞ Guard Unit Guard Unit “*“ to Cancel “*“ to Cancel If an indoor station is in “leave home mode”...

  • Page 45: If A Guard Unit Is In "Intercept Mode

    ABB-Welcome Operation 5.5.4 If a guard unit is in "intercept mode" If a guard unit works in the “intercept mode,” the call from an outdoor station to an indoor station will be intercepted by the guard unit and after the identity is confirmed, the guard unit will forward the call to the indoor station.

  • Page 46: System Settings

    ABB-Welcome Operation 5.5.5 System settings (In settings, press “#” to confirm and “*” to cancel. The default system password is 345678.) Enter the system settings menu #* system password # Menu__________ Configurations-- ∧ Access Control ∨ Contact Configurations (1) Set the device as an outdoor station or a gate station.
  • Page 47 ABB-Welcome Operation Set the call mode by a Logic Code (1-8 digits). #* system password # => Configurations # => Call mode # => Logic Code # Call Mode_______ ∧ Physical Add. ●- Logic Add.: ∨ (3) System password setting...
  • Page 48 ABB-Welcome Operation Access control (1) Door open code The password can be set using 3-8 digits. The default door open password is "123456” and it can be changed at an outdoor station. Users can set their own passwords at the indoor stations. A total of 6,000 passwords can be stored.
  • Page 49 ABB-Welcome Operation (2) Proximity card (3,000 cards can be registered for outdoor station.) Register cards: #* system password # => Access control # => Proximity card # => Register card # Enter Card No.: Enter Card No.: ==＞ 0123456 0123456...
  • Page 50 ABB-Welcome Operation Resident names must be associated with a physical address. Add the contact by logic address #* system password # => Contact # => Add # => Logic add. # Physical Add.: Logic Add.: 0101 Logic address must be associated with a physical address.
  • Page 51 ABB-Welcome Operation -- ∧ Alexander.G Bodin.K ∨ Christian.G Delete the contact by logic address #* system password # => Contact # => Delete # => Logic add. # Enter Logic Add.: 0101 (4) Clear all #* system password # =>...
  • Page 52 ABB-Welcome Operation System setting (1) Date and time #* system password # => Settings # => Date & time # => Enter time and date => 2016-01-01 07:00 ==＞ Done! “#” to Confirm (2) Door open time for 2nd lock #* system password # =>...
  • Page 53 ABB-Welcome Operation #* system password # => Settings # => Language # Language_______ ● -- ∧ English Franç ais ∨ Italiano (5) Welcome Msg. #* system password # => Settings # => Welcome Msg. # New Message: ==＞ ABB-Welcome! Done! “#”...
  • Page 54 ABB-Welcome Operation #* system password # => Settings # => Reset # => Reset to Factory Default? ==＞ Done! “#” to Confirm “*” to Cancel Reset all settings to factory settings, but other information, e.g. user names, logic addresses and card information cannot be reset.
  • Page 55 ABB-Welcome Operation *Reset the system password of keypad module: It is possible to reset the system password to factory settings if you have forgotten it. The restoration of default factory settings does not delete the other information programmed on the system, such as user names and other settings.

  • Page 56: Keypad Outdoor Station Without Display (Camera + Audio + Keypad)

    ABB-Welcome Operation Keypad outdoor station without display (camera + audio + keypad) 5.6.1 Calling a resident by inputting physical address In standby mode, a visitor can enter the physical address corresponding to the residence to call directly, from 001 to 250.
  • Page 57 ABB-Welcome Operation #* system password # => => Press to choose the language => Enable/disable the access control function Enable access control function: #* system password # => => Disable access control function: #* system password # => => *Reset the system password of keypad module: It is possible to reset the system password to the factory setting if you have forgotten it.

  • Page 58: Advanced Configuration

    ABB-Welcome Advanced configuration Pos : 70 /DinA4 - Anl eitungen Onli ne/Ueberschriften/2./Geraeteei nstellungen @ 18\mod_1302768847744_15.doc x @ 103548 @ 2 @ 1 Advanced configuration Connect to the PC to configure the keypad or display Pos : 75 /Busc h-J aeg er (Neustr uktur)/Modul- Struktur /Online-Dokumentati on/Steuermodul e - Onli ne-D okumentation (--> F ü r all e D okumente <--)/++++++++++++ Seitenumbruc h ++++++++++++ @ 9\mod_1268898668093_0.doc x @ 52149 @ @ 1...

  • Page 59: Technical Data

    ABB-Welcome Technical data Pos : 76 /DinA4 - Anl eitungen Onli ne/Ueberschriften/1./Tec hnisc he D aten @ 18\mod_1302615863001_15.doc x @ 103416 @ 1 @ 1 Technical data Pos : 77 /DinA4 - Anl eitungen Onli ne/Inhalt/KN X/D oor Entr y/83220-AP- xxx/T ec hnische D aten - 83220-AP- xxx @ 18\mod_1303212854559_15.doc x @ 103705 @ @ 1...

  • Page 60: Mounting/Installation

    ABB-Welcome Mounting/installation Pos : 79 /Busc h-J aeg er (Neustr uktur)/Modul- Struktur /Online-Dokumentati on/Übersc hriften (--> Fü r alle D okumente <--)/1. Ebene/M - O/Montage / Installation @ 18\mod_1302613966111_15.doc x @ 103373 @ 1 @ 1 Mounting/installation Pos : 80 /Busc h-J aeg er (Neustr uktur)/Modul- Struktur /Online-Dokumentati on/Sic herheit (--> Fü r alle Dokumente <--)/Warnhinweis e/Sic herheit - Ni eders pannungs- und 230 V-Leitungen @ 18\mod_1302617821491_15.doc x @ 103465 @ @ 1...

  • Page 61: General Installation Instructions

    ABB-Welcome Mounting/installation General installation instructions • Terminate all branches of the wiring system via a connected bus device (e.g., indoor station, outdoor station, system device). • Do not install the system controller directly next to the bell transformer and other power supplies (to avoid interference).
  • Page 62 ABB-Welcome Mounting/installation os: 84 /Busch-J aeger (Neus truktur)/M odul-Str uktur/Online-Dokumentation/Ü berschriften (--> Fü r alle Dokumente <--)/2. Ebene/M - O/M ontage @ 18\mod_1302615960458_15.doc x @ 103424 @ 2 @ 1 Mounting Pos : 85.1 /DinA4 - Anl eitungen Onli ne/Inhalt/KN X/DoorEntr y/83220-AP- xxx/M ontag e - M odul e/Montage - Montagedose -- 83220-AP- xxx @ 19\mod_1323250406848_15.doc x @ 111098 @ @ 1 Prepare a pair of gloves to protect yourself from cutting.
  • Page 63 ABB-Welcome Mounting/installation Cover frame Flush-mounted — 63 —...
  • Page 64 ABB-Welcome Mounting/installation Rain hood Components of the outdoor station — 64 —...
  • Page 65 ABB-Welcome Mounting/installation Functions Cover frame Modules Flash-mounted box Rain hood Mount each module at the cover frame Insert each module into the cover frame from behind until it clicks in place. All modules can be inserted, e.g. the camera module, audio module, push button module, keypad module, display and card reader module, nameplate module.
  • Page 66 ABB-Welcome Mounting/installation Use cables to connect the modules together one by one. Ensure that the audio module is connected next to the camera module. The distance zones for the installation of the outdoor station When selecting the installation site, ensure that the minimum distance to the right side is adhered to for the removal of the end strip.
  • Page 67 ABB-Welcome Mounting/installation Wires Prepare the installation box. Strip the wires. – The insulated section of the cable end must not be longer than 10 mm. Assemble the frame into the flush-mounted box Hang the device in the installation box. Fasten the safety loop.
  • Page 68 ABB-Welcome Mounting/installation Option 2: Flush-mounted with a rain hood Option 3: Surface-mounted with a rain hood Option 4: Cavity wall installation — 68 —...
  • Page 69 ABB-Welcome Mounting/installation — 69 —...
  • Page 70 ABB-Welcome Mounting/installation Dismounting outdoor station Use the enclosed mounting tool to remove the end strip. Remove the screw that is used to affix the cover frame. Push up and pull out the outdoor station on the bottom of the cover frame.
  • Page 71 ABB-Welcome Mounting/installation Replace the nameplates Remove the pushbutton cover and write the user names on the label. *Use a labelling sheet with appropriate software to correctly format and print the labels. Adjust the angle of the camera Fig. 1 Adjust the angle of the camera Unscrew the camera.
  • Page 72 ABB-Welcome Mounting/installation Screw on the camera. — 72 —...
  • Page 73 ABB-Welcome Mounting/installation Extension of the outdoor station Make a hole for the cable. Use the joining fixtures to assemble the flush-mounted boxes horizontally. Run the connection wires between the boxes. *The extension is useful for multi-outdoor station connections. Pos : 94 /Busc h-J aeg er (Neustr uktur)/Modul- Struktur /Online-Dokumentati on/Steuermodul e - Onli ne-D okumentation (--> F ü r all e D okumente <--)/++++++++++++ Seitenumbruc h ++++++++++++ @ 9\mod_1268898668093_0.doc x @ 52149 @ @ 1...
  • Page 74 We reserve the right to at all times make technical changes as well as changes to the contents of this document without prior notice. The detailed specifications agreed to at the time of ordering apply to all orders. ABB accepts no responsibility for possible errors or incompleteness in this document.
