PRODUCT NO.
FAH106J2T2
WIRING DIAGRAM - # 309107701
OWNER'S GUIDE - # 309000823
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
BASE MODEL NO.
MARKET
FAH106J2T
USA
Publication No.
5995348413
-EN/SERVICE /DJH
ROOM AIR CONDITIONER
BTU-COOLING
10000BTU
ROOM AIR CONDITIONER
010115
345
©2001 White Consolidated Industries, Inc.
All rights reserved
Model No.
FAH106J2T
Advertisement
Related Manuals for Frigidaire FAH106J2T2
Summary of Contents for Frigidaire FAH106J2T2
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAH106J2T2 FAH106J2T WIRING DIAGRAM - # 309107701 OWNER’S GUIDE - # 309000823 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER MARKET BTU-COOLING 10000BTU ROOM AIR CONDITIONER FAH106J2T Publication No. - Page 2 Publication No. FAH106J2T 5995348413 CABINET FRONT AND WRAPPER 08/01...
- Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAH106J2T CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309627504 Cabinet-,U-bend 18.5BLD 309636101 Screen-safety,18.5BLD 309324004 Link-handle 309628004 Louver,horizontal 309628104 Louver-vertical 309628204 Filter,air ,molded plastic ,grey 309629405 Front assy,18.5 bld cool 309307011 Knob-control 309307013 Knob-control...
- Page 4 Publication No. 5995348413 08/01 FAH106J2T CONTROLS...
- Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAH106J2T CONTROLS PART NO DESCRIPTION 309628501 Box-control 5304408739 Switch,GE 3sp l 5304408746 Control-temperature,12AMP 309329801 Clip-sensor bulb 5303316710 Capacitor,370 V ,25+6 mfd 3015312 Screw,8-18AB x 0.500 5303303077 Strap-capacitor 309343109 Cord-service,type C ,230V/18GA...
- Page 6 Publication No. FAH106J2T 5995348413 AIR HANDLING PARTS 08/01...
- Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAH106J2T AIR HANDLING PARTS PART NO DESCRIPTION 309629102 Blade-fan ass’y 3202975 Screw,10-16 x 0.72 ,square drive 309628901 Shroud-condenser 5304408763 Motor-fan,GE 3sp w/lds ,48FR 309627401 Bulkhead 309631701 Blower Wheel 309112101 Clamp-blower 5303012110...
- Page 8 Publication No. FAH106J2T 5995348413 COMPRESSOR PARTS 08/01...
- Page 9 POS. NO 11 # 12 # 16 # # = Fast-moving Parts * = Non-Illustrated Parts FAH106J2T COMPRESSOR PARTS PART NO DESCRIPTION 309603108 Compressor-Goldstar,GK147KAA 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303291330 Gasket,terminal cover 5304416126 Cover-terminal,compressor 5303293809 Washer 5304419130 Overload-,MRA 98996-694 5303294292 Nut-terminal cover...
- Page 10 Publication No. 5995348413 POS. NO 08/01 FAH106J2T WINDOW MOUNTING PARTS PART NO DESCRIPTION 309628603 Trim 309628604 Trim frame-top & sides (2) 5304409304 Block,tapered 5304409305 Seal-bracket end,cond 5304409307 Seal-rear pnl/sides,condenser 5304409308 Seal-rear pnl top/botm,cond 5304409309 Seal-rear pnl/sides,cond 5304409310 Block-cabinet/chassis 309335101 Divider,cond in/out 5304409311 Kit-grille mtg 3015312...
- Page 11 FAH106J2T Publication No. 5995348413 WIRING DIAGRAM # = Fast-moving Parts 08/01 * = Non-Illustrated Parts...
