SETUP INSTRUCTIONS
2014
690 SMC R EU
690 SMC R AU/GB
Art. no. 3213155en

Advertisement

Table of Contents
loading

Related Manuals for KTM 690 SMC R EU 2014

Summary of Contents for KTM 690 SMC R EU 2014

  • Page 1 SETUP INSTRUCTIONS 2014 690 SMC R EU 690 SMC R AU/GB Art. no. 3213155en...
  • Page 3 KTM accepts no liability for delivery options, deviations from illustrations and descriptions, as well as misprints and other errors.

  • Page 4: Means Of Representation

    MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 SETUP Unpacking and setting up the vehicle – Remove the box and the plastic packaging. Info To avoid damaging the motorcycle during the setup, leave the protective film on the vehicle until you have finished. – Check the vehicle for transport damage. –...
  • Page 6 SETUP – Mount and tighten the rear mirror adapter and rear mirror on both sides. – Position all controls in their exact positions on the handlebar. Tighten all screws. – Mount and tighten screw M8 of the right hand guard. 600646-01 –...
  • Page 7 – Fit the heel protector. ( p. 10) – Refuel. ( p. 11) – Print out the current PDI form found on KTM DEALER.NET and perform the delivery inspection. – Set kilometers or miles. ( p. 12)
  • Page 8 WORK Removing the seat –  Pull on strap and raise the rear of the seat at the same time. – Pull back the seat and lift it off. 101977-10 Mounting the seat 101988-10 –   Hook slot of the seat onto screw , press the rear downward and at the same time push it forward.

  • Page 9: Recharging The Battery

    – Do not discard batteries with the household waste. Dispose of faulty batteries in an environmentally compatible manner. Give the battery to your authorized KTM dealer or dispose of it at a collection point for used batteries. Warning Environmental hazard Hazardous substances cause environmental damage.
  • Page 10 WORK Main work – Connect the battery charger to the battery. Switch on the battery charger. Battery charger (58429074000) You can also use the battery charger to test rest potential and start potential of the battery, and to test the alternator. With this device, you cannot overcharge the bat- tery.

  • Page 11: Closing Filler Cap

    WORK Opening the filler cap Danger Fire hazard Fuel is highly flammable. – Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no fuel is spilt, especially on hot vehicle components. Clean up spilt fuel immediately. –...
  • Page 12 WORK –  Remove screws – Open the filler cap. ( p. 9) – Take off the rear fairing. – Close the filler cap. ( p. 9) 100314-10 Fitting rear fairing – Position the license plate holder and cable harness. –...
  • Page 13 WORK Warning Forfeiture of homologation and insurance cover The vehicle is homologated as 2-seater. If the heel protector is fitted instead of the footrest bracket, the vehicle no longer conforms to the homologation and must not be operated in this form without alterations to the registration papers. –...

  • Page 14: Setting The Clock

    WORK 3.13 Setting the clock Condition The motorcycle is stationary. – Switch on the ignition by turning the ignition key to position ON – Press the MODE button repeatedly until the ODO mode is active. – Keep the MODE button and the SET button pressed simultaneously. The time display begins to flash.

  • Page 15: Technical Data - Tightening Torques For Chassis

    TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS – Screw, chain guard EJOT 2 Nm (1.5 lbf ft) – Screw, combination instrument EJOT 1 Nm (0.7 lbf ft) – Screw, license plate holder, bottom EJOT 3 Nm (2.2 lbf ft) – Screw, side cover on spoiler EJOT 1 Nm (0.7 lbf ft)
  • Page 16 TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS Loctite ® 243™ Screw, connection lever on frame 30 Nm (22.1 lbf ft) Screw, foot brake lever 25 Nm (18.4 lbf ft) Loctite ® 243™ – Screw, fork stub 15 Nm (11.1 lbf ft) –...
  • Page 17 SUBSTANCES Super unleaded (ROZ 95/RON 95/PON 91) Standard/classification – DIN EN 228 (ROZ 95/RON 95/PON 91) Guideline – Only use unleaded super fuel that matches or is equivalent to the specified fuel grade. – Fuel with an ethanol content of up to 10 % (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.
  • Page 18 *3213155en* 3213155en 01/2014 KTM-Sportmotorcycle AG 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...

This manual is also suitable for:

690 smc r au 2014690 smc r gb 2014
