Fortinet FortiManager-100 Quick Start Manual

FortiManager Server LED Indicators
LED State
Green
Power
Off
Amber
Flashing
All Ports
Green
Off

Checking the Package Contents

Front
Power LED
Status LED
Connector
Port 1
Ports 2,3,4
CONSOLE
About the FortiManager System
Connect the FortiManager System to a power outlet and to the internal and external networks.
• Place the unit on a stable surface. It requires 1.5 inches (3.75 cm) clearance above and
on each side to allow for cooling.
• Connect the network cable to interface 1.
To power up the FortiManager Server, connect the power cable to the power outlet.
Installing and Powering Up
The FortiManager System is an integrated management and monitoring tool that consists of
one or more FortiManager Servers and managed FortiGate and FortiAnalyzer devices.
The FortiManager Server manages communication between FortiGate devices, and a
FortiAnalyzer device. The FortiManager Server stores and manages all FortiGate device
configurations. It can also act as an on-site FDN server for the FortiGate devices to down-
load virus and attack signatures, and to use the web filtering and antispam service. The
FortiManager Server can also connect to a FortiAnalyzer unit for managing and monitoring
logs and reports for all managed FortiGate devices.

Factory Defaults

User name:
Administrator Account
Password:
IP:
Port 1 Netmask:
Management Access:
IP:
Port 2 Netmask:
Management Access:
IP:
Port 3 Netmask:
Management Access:
IP:
Port 4 Netmask:
Management Access:
Description
The FortiManager Server unit is powered on.
The FortiManager Server unit is powered off.
The correct cable is in use and the connected equip-
ment has power.
Network activity at this interface.
The interface is connected at 100 Mbps.
No link established.
1 2 3 4
10/100
POWER
STATUS LINK / ACT
Power
Connection
Interface
status LEDs
Type Speed Protocol
RJ-45 10/100 Base-T Ethernet
RJ-45 10/100 Base-T Ethernet
DB-9 9600 bps RS-232 serial
admin
(none)
192.168.1.99
255.255.255.0
ping, https, http, ssh
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
© Copyright 2007 Fortinet Incorporated. All rights reserved.
Products mentioned in this document are trademarks or registered trade-
marks of their respective holders.
Regulatory Compliance
FCC Class A Part 15 CSA/CUS
24 January 2007
Back
4 3 2 1
DC+12V
Internal Interface,
switch connectors
1,2,3,4
RS-232 Serial
Connection
Description
Connection to the network
For future use.
Optional connection to the management computer.
Provides access to the command line interface (CLI).
DC+12V
Power cable connects
to power supply.
Optional null modem cable connects to
serial port on management computer.
1
POWER
STATUS
FortiManager 100
02-30002-0356-20070124
USB
USB
(future)
Power Cable Power Supply
4 3 2 1
Straight-through Ethernet cable connects
to hub or switch on the network.
2 3 4
10/100
LINK / ACT
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
Null-Modem Cable
(RS-232)
Q u i c k S t a r t G u i d e
1 2 3 4 10/100
POWER
STATUS LINK / ACT
FortiManager-100
Copyright 2006 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
Documentation
USB
