Gree FP-8XD-E Service Manual

Commercial air conditioners cassette type fan coil unit
Hide thumbs Also See for FP-8XD-E:
Table of Contents

Advertisement

Quick Links

CASSETTE TYP FAN COIL UNIT

Advertisement

Table of Contents
loading

Related Manuals for Gree FP-8XD-E

Summary of Contents for Gree FP-8XD-E

  • Page 1 CASSETTE TYP FAN COIL UNIT...

  • Page 2: Table Of Contents

    Contens ⅠPRODUCT ....................1 1. MODELS LIST ......................... 2 2. NOMENCLATURE OF THE UNIT ................... 4 3. FUNCTION ........................4 4. PRODUCT DATA ......................5 ⅡCONTROL ....................22 1. WIRELESS REMOTE CONTROLLER ................23 1.1 YB1F2(X-FAN) ..........................23 1.1.1 Guide for operation-general operation ..................26 1.1.2 Guide for operation-optional operation ..................

  • Page 3: Ⅰproduct

    PRODUCT ⅠPRODUCT...

  • Page 4: Models List

    PRODUCT 1. MODELS LIST Cooling Air flow Power Supply Model Name Product Code Remarks Volume Capacity (V, Ph, Hz) (m3/h) FP-8XD-E EM52000051 4600/7500 220-240V~ 50Hz FP-8XD/A-E EM5200045010 4640/7500 220-240V~ 50Hz FP-10XD-E EM52000061 5400/9100 1020 220-240V~ 50Hz FP-10XD/A-E EM5200046010 5400/9100 1020 220-240V~ 50Hz FP-12.5XD-E...
  • Page 5 PRODUCT Cooling/Heating Air flow Power Supply Volume Model Name Product Code Capacity Remarks (V, Ph, Hz) FP-51XD/A-K EM520N1170 2750/3400 220-240V~ 50Hz FP-68XD/A-K EM520N1160 3600/4200 EM520N0930 4150/5600 220-240V~ 50Hz FP-85XD/B-T EM520N0940 4160/7800 208-230V~ 60Hz EM520N0910 500/6500 1020 220-240V~ 50Hz FP-102XD/B-T EM520N0920 540/9000 1020 208-230V~ 60Hz...

  • Page 6: Nomenclature Of The Unit

    PRODUCT 2. NOMENCLATURE OF THE UNIT □ □ □ □ □ Description Options Fan coil Fan coil unit Number×10 m3/h(FP-51XD-E;FP-68XD-E);Number×100 Air flow volume /h(8,10,12.5,14,16,18) Structure type XD-Cassette Type Pipes type Default- 2 pipes; T-4 pipes Arranged by A, B,C… Design Sequence Power code E-220-240V~ 50Hz;T-220-240V~ 50Hz, 208-230V~ 60Hz;...

  • Page 7: Product Data

    PRODUCT 4. PRODUCT DATA Model FP-8XD/A-E FP-10XD/A-E FP-12.5XD/A-E FP-14XD/A-E Code EM5200045010 EM5200046010 EM5200047010 EM5200048010 High 1020 1250 1430 Air flow Medium volume 1030 1363 1200 Cooling 4640 5400 6700 7740 Capacity Heating 7500 9100 10500 11200 Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz Power system Input Exterior static pressure...
  • Page 8 PRODUCT Model FP-16XD/A-E FP-18XD/A-E Code EM5200049010 EM5200050010 1060 High 1640 1800 1035 Air flow volume Medium 1460 1760 1327 1584 Cooling 8700 9600 Capacity Heating 12900 14600 Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz Power system Input Exterior static pressure Water flow volume 1.554 1.714 Water system...
  • Page 9 PRODUCT Model FP-8XD-E FP-10XD-E FP-12.5XD-E FP-14XD-E Code EM52000051 EM52000061 EM52000031 EM52000071 Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz Power system Input High 1020 1250 1430 Air flow volume Medium 1030 1363 1198 Cooling 4640 5400 6700 7740...
  • Page 10 PRODUCT Model FP-16XD-E FP-18XD-E Code EM52000081 EM52000041 Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz Power system Input High Air flow volume Medium Cooling 3000 3500 Capacity Heating 4000 5000 Electric heater rated power 1400 Water flow volume 0.49 0.616 Water system Pressure drop Sound pressure level dB(A)
  • Page 11 PRODUCT Model FP-51XD-E FP-68XD-E Code EM52000011 EM52000021 Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz Power system Input High Air flow volume Medium Cooling 3000 3500 Capacity Heating 4000 5000 Electric heater rated power Water flow volume 0.49 0.616 Water system Pressure drop Sound pressure level dB(A) Type...
  • Page 12 PRODUCT Notes: (a) The water working temperature is from 7° C(44.6° F) to 60° C(140° F). (b) The temperature exchange efficiency and enthalpy exchange efficiency are tested under these testing conditions as below:  Cooling efficiency: air 27° C(80.6° F) DB, 19.5° C(67.1° F) WB, water temperature in 7°...
  • Page 13 PRODUCT (W×D×H) Panel TC06 670x670x60 670x670x60 Package Body 775x730x285 775x730x285 dimension Panel TC06 760x760x90 760x760x90 (W×D×H) Body Net weight Panel TC06 Body Panel TB03 Gross weight 20'GP (with panel TB03) 40'GP (with panel TB03) 40'HQ (with panel TB03) Wired remote controller Z4E351B Z4E351B Wireless remote controller...
  • Page 14 PRODUCT Model FP-85XD/B-T FP-85XD/B-T FP-102XD/B-T FP-102XD/B-T Code EM520N0940 EM520N0930 EM520N0920 EM520N0910 Type V-Ph-Hz 208-230V~ 60Hz 220-240V~ 50Hz 208-230V~ 60Hz 220-240V~ 50Hz Power system Input High 1020 1020 Air flow Medium volume Cooling 4600 4500 5400 5000 Capacity Heating 7800 5600 9000 6500 Electric heater rated power...
  • Page 15 PRODUCT (W×D×H) Panel TB03 1033×1038×133 1033×1038×133 1033×1038×133 1033×1038×133 Body 25.0 25.0 25.0 25.0 Net weight Panel T01 Panel TB03 Body 33.0 33.0 33.0 33.0 Gross Panel T01 weight Panel TB03 20'GP(with panel T01) 40'GP (with panel T01) 40'HQ (with panel T01) Loading quantity 20'GP (with panel TB03)
  • Page 16 PRODUCT Cooling pressure drop Heating pressure drop Sound pressure level dB(A) Aluminum Aluminum Aluminum Aluminum Type fin-copper tube fin-copper tube fin-copper tube fin-copper tube Coil ≤1.6MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa Operating pressure Type FN35B-1 FN35B-1 FN35C FN35C Motor Capacitor µF 2.00 2.00 4.00 4.00...
  • Page 17 PRODUCT Model FP-160XD/B-T FP-160XD/B-T FP-180XD/B-T FP-180XD/B-T Code EM520N0860 EM520N0850 EM520N0840 EM520N0830 Type V-Ph-Hz 208-230V~ 60Hz 220-240V~ 50Hz 208-230V~ 60Hz 220-240V~ 50Hz Power system Input 1059 1059 High 1550 1550 1800 1800 Air flow Medium volume 1300 1400 1400 1450 1150 1300 1300 1350...
  • Page 18 PRODUCT (W×D×H) Panel TB03 1033×1038×133 1033×1038×133 1033×1038×133 1033×1038×133 Body 27.0 27.0 32.0 32.0 Net weight Panel T01 Panel TB03 Body 35.0 35.0 41.0 41.0 Gross Panel T01 weight Panel TB03 20'GP(with panel T01) 40'GP (with panel T01) 40'HQ (with panel T01) Loading 20'GP (with panel TB03) quantity...
  • Page 19 PRODUCT Heating pressure drop Sound pressure level dB(A) Type Aluminum fin-copper tube Aluminum fin-copper tube Coil ≤1.6MPa ≤1.6MPa Operating pressure Type FN50K-2 FN50K-2 Motor Capacitor µF 5.00 5.00 Water inlet &outlet inch G3/4" G3/4" Connection pipe size Condensing water drain Body 840×840×320 840×840×320...
  • Page 20 PRODUCT Model FP-200XD/D-K Code EM520N1210 Type V-Ph-Hz 220-240V~ 50Hz Power system Input 1177 High 2000 1000 Air flow volume Medium 1700 1450 Cooling 12000 Capacity Heating 14200 Electric heater rated power Cooling water flow volume 0.62 Heating water flow volume Water system Cooling pressure drop Heating pressure drop...
  • Page 21 PRODUCT Model FP-68XDT/B-K FP-85XDT/B-K FP-125XDT/B-K FP-180XDT/B-K Code EM520N0990 EM520N0960 EM520N0970 EM520N0980 Type V-Ph-Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz 220-240V~ 50Hz Power system Input 1059 High 1250 1800 Air flow Medium volume 1108 1525 1014 1421 Cooling 3500 4100 6000 8000 Capacity Heating...
  • Page 22 PRODUCT Package Body 960×960×257 960×960×257 960×960×310 960×960×394 dimension Panel TB03 1033×1038×133 1033×1038×133 1033×1038×133 1033×1038×133 (W×D×H) Body 25.0 25.0 27.0 32.0 Net weight Panel TB03 Body 33.0 33.0 34.0 41.0 Gross weight Panel TB03 20'GP (with panel TB03) Loading 40'GP (with panel TB03) quantity 40'HQ (with panel TB03) Testing condition:...
  • Page 23 PRODUCT (a) Cooling capacity: air 27° C DB , 19° C WB, water temperature intake 7° C, outlet 12° C. (b) Heating capacity: air 20° C DB , Water temperature intake 70° C, outlet 60° C. (c) Freeze-up : air 27° C DB, 24° C WB , water temperature 6° C intake , 10° C outlet . (d) Sound power level according to ISO 5151.

  • Page 24: Ⅱcontrol

    CONTROL ⅡCONTROL...

  • Page 25: Wireless Remote Controller

    CONTROL 1. WIRELESS REMOTE CONTROLLER 1.1 YB1F2(X-FAN)
  • Page 26 CONTROL...
  • Page 27 CONTROL...

  • Page 28: Guide For Operation-General Operation

    CONTROL 1.1.1 Guide for operation-general operation (1) Press ON/OFF button to start the unit after poweringthe main unit on.(Note: Power the unit on every time,the big-guide louver and small-guide louver will beclosed firstly.) (2) Press MODE button to select desired running mode. (3) Press +/ - button to set the desired temperature.(It is unnecessary to set the temperature at AUTO mode) (4) Press FAN button to set fan speed, the AUTO FAN,LOW, MID or HIGH could be selected.

  • Page 29: Changing Batteries And Notices

    CONTROL will be in accordance with the room temp. automatically to select the suitable running method and to make ambient comfortable. (3) About turbo function If start this function, the unit will run at super-high fan speed to cool or heat quickly so that the ambient temp.

  • Page 30: Yb1Fa(X-Fan)

    CONTROL (e) If the remote control cannot operate normally, please take the batteries out, and then reinsert it 30s later; ifit is also abnormal ,please replace the batteries. (f) If the main unit needs to be remote controlled, please aim remote control at the receiver of main unit in orderto improve the receiving sensitivity of the main unit.When the remote control sends out signal, a mark will flicker for about 1s.
  • Page 31 CONTROL (2) MODE button Press this button, Auto, Cool, Dry, Fan Heat mode can be selected circularly. Auto mode is not available in this mode. (3) SLEEP button Press this button to select Sleep On/Sleep Off. If power is on, Sleep Off is default. If the unit is turned off, the Sleep function setting will be not retained in memory.

  • Page 32: Operation Of Wireless Remote Control

    CONTROL off, indoor setting temperature display is default. Note: This function is only available for certain models. (11) TURBO button In Cool or Heat mode, press this button to turn on/off the Turbo function. Note: This is a general remote control, it could be used for multiple types (functions) of air conditioners. For some models without the functions specified here, we preserve the right to not to inform exclusively.

  • Page 33: Changing Batteries And Notices

    CONTROL  Press FAN button to set fan speed from AUTOFAN , LOW , MID and HIGH.  Press button to select SWING mode.  Press +and - buttons simultaneously to lock or unlock the wireless remote control. If it is locked, the mark will display;...

  • Page 34: Wired Remote Controller

    CONTROL 2. WIRED REMOTE CONTROLLER 2.1 Introduction to Z5K351(optional) NOTE: Never install the wired remote controller in a place where there is water leakage. Avoid bumping, throwing, tossing or frequently opening the wired remote controller. Time display Sleep display Fan speed display(Auto, High, Middle, Low) MODE button Defrosting display Button for temp.

  • Page 35: Introduction To Z4E351B (Optional)

    CONTROL 2.2 Introduction to Z4E351B (optional) 2.2.1 Symbols on the LCD Introduction to the Symbols on the LCD. Symbol Function Description It indicates the swing function. It indicates the function of air exchange. (It is unavailable for this wired controller.) It indicates the sleeping status.

  • Page 36: Introduction To The Functions Of The Press Keys

    CONTROL It indicates the “ Fan ” mode. It indicates the “ Heat ” mode. It indicates the defrosting mode. (It is unavailable for this wired controller.) It indicates the gate control status. It indicates the locking status. It indicates the shield status. (It appears when all functions, or the function “On/Off ”, “...
  • Page 37 CONTROL Introduction to the Functions of the Press Keys. Press Bottoms Function Description Enter/Cancel It is used to select the desired function or cancel the selected function. ① It is used to adjust the running temperature of the indoor unit among16~30 ℃ . ▲...

  • Page 38: Ⅲ Unit Installation

    UNIT INSTALLATION Ⅲ UNIT INSTALLATION...

  • Page 39: Selection The Mounting Position

    UNIT INSTALLATION 1. SELECTION THE MOUNTING POSITION Especially, the installation place is very important for the fan coil unit because it is very difficult to move from placc aftr the first installation. Decide the mounting position together with the customer as follows: The discharge direction can be selected as shown below.

  • Page 40: Ceiling Opening And Suspension Bolt (M L0) Pitch Flemension

    UNIT INSTALLATION 1.1 Ceiling opening and suspension bolt (M l0) pitch flemension Be suitable for: FP-51XD-E FP-68XD-E Be suitable for: P-85XD/B-T; FP-102XD/B-T; FP-125XD/B-T; FP-140XD/B-T; FP-160XD/B-T; FP-180XD/B-T; FP-200XD/B-T; FP-10XD–E; FP-12.5XD-E; FP-14XD-E; FP-16XD-E; FP-18XD-E;P-8XD/A-E; FP-10XD/A–E; FP-12.5XD/A-E; FP-14XD/A-E; FP-16XD/A-E; FP-18XD/A-E; FP-85XD/B-T; FP-102XD/B-T; FP-125XD/B-T; FP-140XD/B-T; FP-160XD/B-T; FP-180XD/B-T; FP-200XD/B-T; FP-68XDT/B-K;...

  • Page 41: Precautions For Drainage Raising Pipe

    UNIT INSTALLATION Use the drain hose and clamp attached. Insert the drain hose to the drain vent, and then tighten the clamp. Entwine the big sponge on the clamp of drain hose to insulate heat. Heat insulation should be done to indoor drain hose. 3.

  • Page 42: Instruction

    UNIT INSTALLATION 3.1 Instruction (1) The slant gradient of the attached drain hose should be within 75mm so that the drain hole doesn’t has to endure the unnecessary outside force. (2) Please install the drain hose according to the following process if several drain hoses join together.

  • Page 43: Electric Wiring

    UNIT INSTALLATION  For 4 pipes: (7) Check the smoothness of drain after installation. (8) Check the drain state by imitating 600cc water slowly from the outlet vent or test hole. (9) Check the drain in the state of refrigerating after installation of the electric circuit. Warning: Before obtaining access to terminals, all supply circuits must be disconnected.

  • Page 44: Wiring Of Unit And The Controller

    UNIT INSTALLATION 4.1 Wiring of unit and the controller 4.1.1 Wiring of the unit (1) For 2 pipes Remove the control box lid, pull the wires inside through rubber bush and wiring according to the WIRING DIAGRAM, then tighten it with clamp. Wiring of the controller ...

  • Page 45: Installation Of Panel

    UNIT INSTALLATION 5. INSTALLATION OF PANEL Set the panel to the unit body by matching the position of the swing flap motor of the decoration panel to the piping position of the indoor unit as shown as below. Install the decoration panel. (1) Hang the latch, which is located on the opposite side of the swing flap motor on the panel, temporarily to the hook of the unit.

  • Page 46: Precautions

    UNIT INSTALLATION 5.1 Precautions Improper screwing of the screws may cause the troubles. If gap is still left between the ceiling and the panel after screwing the screws, readjust the height of the unit body.

  • Page 47: After Fixing Be Sure No Gap Left Between The Ceiling And The Panel

    UNIT INSTALLATION 5.2 After fixing be sure no gap left between the ceiling and the panel Wiring of the decoration panel. Connect the joints for swing flap motor lead wire (at 2 places) installed on the panel.

  • Page 48: Ⅳ Unit Maintenance

    Unit MAINTENANCE Ⅳ Unit MAINTENANCE...

  • Page 49: Troubleshooting

    Unit MAINTENANCE 1.TROUBLESHOOTING Panel TB03 displaying the error code : Error code Error Water pump error Communications error temperature sensor error at the return air inlet Evaporator temp. sensor error temperature sensor error at the wire controller Full water protection Entering cooling temp.
  • Page 50 Unit MAINTENANCE b. Do not dry over fire. c. Do not run the air condition without the air filter. d. The suction grille must be opened by skilled personnel. Fix the air filters ① Fix three air-cleaner on the air filter and then fix the air filter to the suction grille by hanging it to the projected portion above suction grille.
  • Page 51 Unit MAINTENANCE ⑦ Close the suction grille. Refer to step 1. Changing air cleaner ① Open the suction grille See step 1 of “How to clean the air filter” ② Remove the air cleaner Remove the air filter and remove the air cleaner after unscrewing.
  • Page 52 Unit MAINTENANCE ② Fix the flap Set the ribs on the sides of the air outlet to the slit of the flap and then screw together to fix the flap. Before starting the air conditioner for the first time in the season. ①...

  • Page 53: Wiring Diagram

    Unit MAINTENANCE 3. WIRING DIAGRAM FP-8XD-E; FP-10XD–E; FP-12.5XD-E; FP-14XD-E;FP-14XD-E;FP-18XD-E. FP-8XD/A-E; FP-10XD/A–E; FP-12.5XD/A-E; FP-14XD/A-E;FP-16XD/A-E; FP-18XD/A-E.
  • Page 54 Unit MAINTENANCE Model: FP-51XD –E; FP-68XD –E. Model:FP-51XD/A-K;FP-68XD/A-K...
  • Page 55 Unit MAINTENANCE Model:FP-85XD/B-T;FP-102XD/B-T;FP-125XD/B-T;FP-140XD/B-T;FP-160XD/B-T;FP-180XD/B-T;FP -200XD/B-T. Model:FP-68XDT/B-K; FP-85XDT/B-K; FP-125XDT/B-K; FP-180XDT/B-K.

  • Page 56: Disassembly And Assembly Procedure Of Main Parts

    Unit MAINTENANCE 4. DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS Model;FP-8XD-E; FP-10XD–E; FP-12.5XD-E; FP-14XD-E; FP-16XD-E; FP-18XD-E;P-8XD/A-E; FP-10XD/A–E; FP-12.5XD/A-E; FP-14XD/A-E;FP-16XD/A-E; FP-18XD/A-E; FP-85XD/B-T; FP-102XD/B-T: FP-125XD/B-T; FP-140XD/B-T; FP-160XD/B-T; FP-180XD/B-T; FP-200XD/B-T; FP-85XD/B-T; FP-102XD/B-T: FP-125XD/B-T; FP-140XD/B-T; FP-160XD/B-T; FP-180XD/B-T; FP-200XD/B-T; FP-68XDT/B-K; FP-85XDT/B-K; FP-125XDT/B-K; FP-180XDT/B-K. Disassembly Procedures of Indoor Unit ( Panel T01) Remark: Make sure that the unit is stopped running and power supply is cut off before removal of the motor.
  • Page 57 Unit MAINTENANCE Loosen two screws fixing the electric box ④ Disassemble the and then disconnect each wiring terminals, electrical box after that take the electric box out upward. ⑤ Disassemble the Loosen the screws fixing the flow-guide loop flow-guide loop and then turn it counter clockwise.
  • Page 58 Unit MAINTENANCE Loosen the screws on the mounting plate and take it out. Loosen the screws on the baffle of the pipe outlet, and then press it downward to pull out the buckles on both side, after that, take the baffle away. Loosen the screws and clamps on the ⑧...
  • Page 59 Unit MAINTENANCE Model: FP-51XD –E; FP-68XD –E. Disassembly Procedures of Indoor Unit Remark: Make sure that the unit is stopped running and power supply is cut off before removal of the motor. Process Pictorial View Handling Description Push the left and right buckles on the grille of ①...
  • Page 60 Unit MAINTENANCE Loosen two screws on the cover of the electric box and then remove it away. ④ Disassemble the Disconnect the wiring terminals of the motor electrical box and the temperature sensing bulb, then loosen two screws fixing the electric box, after that, remove the electric box away.
  • Page 61 Unit MAINTENANCE ⑦ Disassemble the Loosen two screws on the left fender and left fender then take it out upward. ⑧ Disassemble the Loosen the screws on the fan blade and then fan blade take it out. Loosen the screws on the connection board ⑨...

  • Page 62: Exploded Views And Spare Part Lists

    Unit MAINTENANCE 5. EXPLODED VIEWS AND SPARE PART LISTS Model: FP-8XD-E; FP-10XD–E; FP-12.5XD-E; FP-14XD-E;FP-16XD-E; FP-18XD-E exploded views and spare parts list.
  • Page 63 Unit MAINTENANCE FP-8XD-E FP-10XD-E FP-12.5XD-E Discription Quantit EM52000050 EM52000060 EM52000030 Name of Parts Part Code Part Code Part Code Tube Exit plate 02217102 02217102 02217102 Body Fixing Plate 01332701 01332701 01332701 Front Side Plate 01302718 01302718 01302718 Left Side Plate...
  • Page 64 Unit MAINTENANCE Electric Box Cover II 20102703 20102703 20102703 Main 30225904 30225904 30225904 Capacitor 33010026 33010010 33010010 Drainage Plastic 06122702 06122702 06122702 Evap Support 01072703 01072703 01072703 Nut with Washer M6 70310012 70310012 70310012 Fan Fixer 10312701 10312701 10312701 Water Pump 43130324 43130324 43130324...
  • Page 65 Unit MAINTENANCE Cable-cross Loop 76515202 76515202 76515202 Tube sensor 3900012125 3900012125 3900012125 sensor insert B 42020063 42020063 42020063 Heat exchanger 01187104 01187104 01187104 Water Tray 20182701 20182701 20182701 Screw 70140032 70140032 70140032 Electric Plate 01412721 01412721 01412721 Flow-guide Loop 10372722 10372722 10372722 Electric Box...
  • Page 66 Unit MAINTENANCE FP-8XD/A-E; FP-10XD/A–E; FP-12.5XD/A-E; FP-14XD/A-E;FP-16XD/A-E; FP-18XD/A-E exploded views and spare parts list.
  • Page 67 Unit MAINTENANCE FP-8XD/A-E FP-10XD/A-E FP-12.5XD/A-E Discription Quantit EM52000450 EM52000460 EM52000470 Name of Parts Part Code Part Code Part Code Tube Exit plate 02217102 02217102 02217102 Body Fixing Plate 01332701 01332701 01332701 Front Side Plate 01302718 01302718 01302718 Left Side Plate 01302715 01302715 01302715...
  • Page 68 Unit MAINTENANCE Main PCB 30225904 30225904 30225904 Capacitor 33010026 33010010 33010010 Drainage pipe 4367120 05230026 05230026 Evap Support 01072703 01074042 01074042 Nut with Washer 70310012 70310012 70310012 Fan Fixer 10312701 10312701 10312701 Water Pump 43130324 43130324 43130324 Pump Gasket 76712702 76712702 76712702 Pump Support...
  • Page 69 Unit MAINTENANCE Cable-cross Loop 76513101 76513101 76513101 Tube sensor 3900012125G 3900012125G 3900012125G sensor insert B 42020063 42020063 42020063 Heat exchanger 01127102 01127104 01127104 Water Tray 20182701 20182701 20182701 Screw 70140032 70140032 70140032 Electric Plate 01412721 01412721 01412721 Flow-guide Loop 10372722 10372701 10372701 Electric Box...
  • Page 70 Unit MAINTENANCE FP-51XD –E; FP-68XD –E exploded views and spare parts list. FP-51XD –E FP-68XD –E Discription EM52000010 EM52000020 Quantity Name of Parts Part Code Part Code Remote Controller 30512506 30512506 Water Tray 20182703 20182703 Water Tray Foam for Fresh Air In taking 12312702 12312702 Water Tray Foam...
  • Page 71 Unit MAINTENANCE Water Tray support 01332706 01332706 Front Side Plate 01302741 01302741 Body Fixer 01332705 01332705 Right Side Plate 01302743 01302743 Tube-exit plate 01382719 01382719 Cable-cross Loop 76512701 76512701 Wire Clamp 71010102 71010102 Electric Box Assy 01402705 01402705 Terminal Board(5bit) 42011142 42011142 Transformer...
  • Page 72 Unit MAINTENANCE FP-51XD/A-K; FP-68XD/A-K exploded views and spare parts list. FP-51XD –E FP-68XD –E Discription EM52000010 EM52000020 Quantity Name of Parts Part Code Part Code Rear Grill 26909400007 26909400007 Fan Motor 150101000011 150101000011 Water Tray Assy 01289400004 01289400004 Water Pump 43138220 43138220 Supporter...
  • Page 73 Unit MAINTENANCE Base Plate Assy 02229400007 02229400007 Body Installing Support 01332705 01332705 Left Side Plate Sub-Assy 01319400012 01319400012 Electric Box Assy 01396001501 01396001501 Terminal Board 42011142 42011142 Breadboard Holder 26909407 26909407 Main Board 30224000089 30224000089 Capacitor CBB61 3301074716 3301074716 Transformer 4311022602 4311022602 Front Side Plate Sub-Assy...
  • Page 74 Unit MAINTENANCE FP-85XD/B-T;FP-102XD/B-T;FP-125XD/B-T;FP-140XD/B-T;FP-160XD/B-T;FP-180XD/B-T;FP-200X D/B-T exploded views and spare parts list.
  • Page 75 Unit MAINTENANCE FP-85XD/B-T FP-102XD/B-T Discription EM520N0930/EM520N0940 EM520N0910/EM520N0920 Quantity Name of Parts Part Code Part Code Tube-exit Plate Body Fixing Plate 01332701 01332701 Front Side Plate 01302717 01302717 Left Side Plate 01302740 01302740 Base Plate 01222701 01222701 Rear Side Plate 01302719 01302719 Bottom Foam 52012720...
  • Page 76 Unit MAINTENANCE Evap Support 01072003 01072003 Nut with Washer 70310012 70310012 Fixer 10312701 10312701 Water Pump 43130324 43130324 Pump Gasket 76712702 76712702 Pump Support 01332001 01332001 Water Level Switch 45018012 45018012 Pump Drainpipe 05232721 05232721 Right Side Plate 01302710 01302710 Cable-cross Block 76512702 76512702...
  • Page 77 Unit MAINTENANCE Flow-guide Loop 10372722 10372722 10372722 Electric Box asm 01396000019 01396000030 01396000025 Electric Box 26909439 26909439 26909439 Wire Clamp 71010102 71010102 71010102 Terminal Board 42011221 42011221 42011221 Tube sensor 390001982G 390001982G 390001982G Transformer 4311022602 4311022602 4311022602 Electric Box 20102702 20102702 20102702 Cover I...
  • Page 78 Unit MAINTENANCE Above data is subject to change without notice,pls refer the SP in global service website. FP-160XD/B-T FP-200XD/B-T Discription Quantity EM520N0830/EM520N0840 EM520N0810/EM520N0820 Name of Parts Part Code Part Code Tube-exit Plate 02206000001 02206000001 Body Fixing Plate 01332701 01332701 Front Side Plate 01302713 01302713 Left Side Plate...
  • Page 79 Unit MAINTENANCE Remote Controller 30510516 30510516 Evap Support 01072708 01072708 Nut with Washer 70310012 70310012 Fixer 10312701 10312701 Water Pump 43130324 43130324 Pump Gasket 76712702 76712702 Pump Support 01332721 01332721 Water Level Switch 45018012 45018012 Pump Drainpipe 05230026 05230026 Right Side Plate 01302712 01302712 Cable-cross Block...
  • Page 80 Unit MAINTENANCE FP-68XDT/B-K exploded views and spare parts list. FP-68XDT/B-K Discription Quantity EM520N0990 Name of Parts Part Code Tube Exit Plate Assy 01346000095 Body Fixing Plate 01332701 Front Side Plate 01302717...
  • Page 81 Unit MAINTENANCE Left Side Plate 01302740 Base Plate 01222701 Rear Side Plate 01302719 Bottom Foam 52012720 Motor Gasket 76712711 Motor Support 01702701 Motor 15704901 Centifugal Fan 10312721 Evap Connection 01072004 Deflation Valve 07108206 Valve chest (air release valve) 07336000028 Valve chest (air release valve) 0733600001501 Water Tray 20182701...
  • Page 82 Unit MAINTENANCE FP-85XDT/B-K exploded views and spare parts list. FP-85XDT/B-K Discription Quantity EM520N0960 Name of Parts Part Code Tube Exit Plate Assy 01346000095 Body Fixing Plate 01332701...
  • Page 83 Unit MAINTENANCE Front Side Plate 01302717 Left Side Plate 01302740 Base Plate 01222701 Rear Side Plate 01302719 Bottom Foam 52012720 Motor Gasket 76712711 Motor Support 01702701 Motor 15704901 Centifugal Fan 10312721 Evap Connection 01072004 Deflation Valve 07108206 Valve chest (air release valve) 07336000028 Valve chest (air release valve) 0733600001501...
  • Page 84 Unit MAINTENANCE FP-125XDT/B-K exploded views and spare parts list. FP-125XDT/B-K Discription Quantity EM520N0970 Name of Parts Part Code Tube Exit Plate Assy 01346000094 Body Fixing Plate 01332701 Front Side Plate 01302718...
  • Page 85 Unit MAINTENANCE Left Side Plate 01302715 Base Plate 01222701 Rear Side Plate 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Motor Support 01702701 Motor 15704102 Centifugal Fan 10312705 Evap Connection 01072710 Deflation Valve 07108206 Valve chest (air release valve) 07336000028 Valve chest (air release valve) 0733600001501 Water Tray 20182701...
  • Page 86 Unit MAINTENANCE FP-180XDT/B-K exploded views and spare parts list. FP-180XDT/B-K Discription Quantity EM520N0980 Name of Parts Part Code Tube Exit Plate Assy 01346000094 Body Fixing Plate 01332701 Front Side Plate 01302713...
  • Page 87 Unit MAINTENANCE Left Side Plate 01302711 Base Plate 01222701 Rear Side Plate 01302709 Bottom Foam 52012721 Motor Gasket 76712711 Motor Support 01702701 Motor 15704903 Centifugal Fan 26904115 Evap Connection 01072733 Deflation Valve 07108206 Valve chest (air release valve) 07336000028 Valve chest (air release valve) 0733600001501 Water Tray 20182701...
  • Page 88 No.：JF00300710...
