Pioneer FH-MG6106ZH-03/X1H/UC Service Manual

Pioneer FH-MG6106ZH-03/X1H/UC Service Manual

Multi-cd control fm/am cassette deck with 6 disc in-dash cd changer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Service
Manual
MULTI-CD CONTROL FM/AM CASSETTE DECK WITH 6 DISC IN-DASH CD CHANGER
FH-MG6106
FH-MG6106
FH-MG6106
FH-MG6106
VEHICLE
DESTINATION
ACURA TL
U.S.A., CANADA
- This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-1011
CRT2406
CX-890
CRT2376
- Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
For details, refer to "Important symbols for good services".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC.
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER EUROPE NV
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2002
HONDA
FH-MG6106ZH-03/X1H/UC
ZH-04
ZH-93
ZH-94
PRODUCED AFTER
HONDA PART No. ID No.
January 2002
39100-S0K-A210
39100-S0K-A310
39100-S0K-A21ZA 3TB1
39100-S0K-A31ZA 3TB1
Mech. Module Remarks
3L
Cassette Mech. Module:Mech.Description, Disassembly
G1
CD Mech. Module:Circuit Description, Mech.Description, Disassembly
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
ZH-03
X1H/UC
X1H/UC
X1H/UC
PIONEER MODEL No.
3TB1
FH-MG6106ZH-03/X1H/UC
3TB1
FH-MG6106ZH-04/X1H/UC
FH-MG6106ZH-93/X1H/UC
FH-MG6106ZH-94/X1H/UC
K-ZZS. JAN. 2002 Printed in Japan
ORDER NO.
CRT2841
X1H/UC
