CD RDS RECEIVER AUTORADIO CD RDS REPRODUCTOR DE CD CON RECEPTOR RDS FH-X820BS FH-X720BT Owner’s Manual FH-X721BT Mode d’emploi Manual de instrucciones FH-X520UI Important (Serial number) The serial number is located on the bottom of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card. -
Page 2: Table Of Contents
Table of Contents Before You Start..................3 Getting Started..................4 Radio......................7 CD/USB/iPod/AUX................... 8 Bluetooth....................10 App Mode ....................12 Pandora® ....................13 SiriusXM Satellite Radio............... 13 Settings ....................15 FUNCTION settings ................15 AUDIO settings..................16 SYSTEM settings ................... 17 ILLUMINATION settings............... -
Page 3: Before You Start
Sound can be deceiving. Thank you for purchasing this PIONEER product Over time, your hearing “comfort level” adapts to higher volumes of sound, so what sounds “normal”... -
Page 4: Getting Started
After-sales service for Pioneer products Getting Started Please contact the dealer, distributor from where you purchased this unit or the authorized PIONEER Service Station for after-sales service or any other information. In case the necessary information is not available, please contact the companies listed below:... -
Page 5: Display Indication
FH-X520UI Frequently used operations The available buttons vary depending on the unit. Display window DISP (display) Operation Purpose Head Unit Remote Control Turn on the power* Press SRC/OFF to turn on Press SRC to turn on the the power. power. Press and hold SRC/OFF to Press and hold SRC to turn turn off the power. -
Page 6: Preparing The Remote Control
Indication Description Setting the clock (CLOCK SET) Appears when the iPod control function is set (page 9). When you turn the ignition switch to ON after installation, [SET UP :YES] appears in the Appears when a Bluetooth connection is made (page 10). display. -
Page 7: Radio
Menu Item Description buttons can be also used to select a preset station when [SEEK] is set to [PCH] in the REAR-SP Select when there is a full-range speaker connected to the rear FUNCTION settings (page 15). speaker output leads. [FUL] Best stations memory (BSM) [SW]... -
Page 8: Cd/Usb/Ipod/Aux
Plug in the USB device/iPod using an appropriate cable. CAUTION Use an optional Pioneer USB cable (CD-U50E) to connect the USB device as any device connected directly to the unit will protrude out from the unit, which could be dangerous. -
Page 9: Ipod Control
NOTE Purpose Operation The selected song/album may be canceled if you use functions other than those from the link play 1 Press Alphabetical search (iPod only) to display the list. mode (e.g. fast forward and reverse). 2 Turn the M.C. dial to select the desired category list, then press to enter the iPod control... -
Page 10: Bluetooth
Bluetooth device address and device name. when the unit has already been paired with three devices. [ON], [OFF] Select [Pioneer BT Unit] shown in the device display. A.PAIRING Select [ON] to pair the unit and iPhone automatically when an Make sure the same 6-digit number appears on this unit and the device, then iPhone is connected to the unit via USB. -
Page 11: Bluetooth Audio
Turn the M.C. dial to select [MISSED], [DIALED], [RECEIVED] or [PHONE BOOK], then Press the M.C. dial and then talk into the microphone to input voice commands. press to confirm. To exit the voice recognition mode, press BAND/ The phone number list appears. NOTE Turn the M.C. -
Page 12: Playback Of Application Via Unit
NOTE Press BAND/ to start playback. PIONEER IS NOT LIABLE FOR ANY THIRD PARTY APPS OR CONTENT, INCLUDING WITHOUT LIMITATION THEIR ACCURACY OR COMPLETENESS. THE CONTENT AND FUNCTIONALITY OF SUCH APPS ARE THE Basic operations SOLE RESPONSIBILITY OF THE APP PROVIDER. -
Page 13: Pandora
1 When the station is selected, press and hold the Delete a station M.C. dial. Pandora internet radio is a music service not affiliated with Pioneer. More information is [DELETE YES] appears. 2 Press the M.C. dial. available at http://www.pandora.com. -
Page 14: Basic Operations
NOTE Listening to a channel TuneStart is compatible with SXV200 or later tuner models. Not compatible with SXV100. TuneScan™ Press /DIMMER, then select [CHANNEL]. Scan through short previews of songs you may have missed on music channels stored You can also select the operation mode by the FUNCTION settings (page 15). on the current band of presets. -
Page 15: Settings
FUNCTION settings Purpose Operation The menu items vary according to the source. Selecting the channel or song playing Press the M.C. dial. is only available for FH-X820BS. Switching to the next/previous song during Press Menu Item Description TuneScan Switching to the next/previous channel... -
Page 16: Audio Settings
Menu Item Description Menu Item Description EQ SETTING PLAY [SUPER BASS], [POWERFUL], Select or customize the equalizer curve. Start playback. [NATURAL], [VOCAL], [CUSTOM1], [CUSTOM1] can be set separately for each source. STOP [CUSTOM2], [FLAT] However, each of the below combinations are set to the same setting automatically. -
Page 17: System Settings
*3 Not available when [FUL] is selected in [REAR-SP] in the INITIAL settings (page 7). ILLUMINATION settings *4 Not available when [REAR/REAR] is selected in [SP-P/O MODE] in the INITIAL settings (page 7). *5 Not available when [OFF] is selected in [SUB.W]. Menu Item Description SYSTEM settings... -
Page 18: Mixtrax Settings
Menu Item Description Menu Item Description ILLUMI FX CUT IN FX [ON], [OFF] The illumination effect can be seen when; [ON], [OFF] Turn the MIXTRAX sound effects on/off while – there is an incoming call manually changing the tracks. – you are on a phone call –... -
Page 19: Connections/Installation
Failure to do so this unit. may result in a fire or malfunction. • The black cable is ground. When FH-X820BS Power cord input • To prevent a short-circuit, overheating or installing this unit or power amp (sold... - Page 20 Important optional amplifier. Connect to the constant 12 V supply • Check all connections and systems before terminal. FH-X820BS final installation. • Do not use unauthorized parts as this Connect to terminal controlled by the may cause malfunctions. ignition switch (12 V DC).
-
Page 21: Installing The Microphone
Microphone clip Installing the microphone To install on the steering (Only for FH-X820BS/X720BT/X721BT) column The microphone should be placed directly Slide the microphone base to detach it in front of the driver at a suitable distance from the microphone clip. -
Page 22: Additional Information
→ All the files on the inserted disc are contact your dealer or an authorized – Disconnect the USB device and do not embedded with DRM. Pioneer Service Station for assistance. use it. Turn the ignition switch OFF A subfolder is not played back. – Replace the disc. - Page 23 SiriusXM Satellite Radio (Only – Connect a device that has a → The station could not be deleted. ERROR-10 compatible version of the Pandora for FH-X820BS) – Run the same command for another → The power failed for the Bluetooth application installed. station.
- Page 24 CAUTION before driving. Do not let the USB storage Sampling frequency 16 kHz to 48 kHz • Pioneer cannot guarantee compatibility device fall onto the floor, where it may (LPCM), 22.05 kHz and with all USB mass storage devices, and become jammed under the brake or 44.1 kHz (MS ADPCM)
-
Page 25: Copyright And Trademark
CAUTION playback of audio files on a USB storage are trademarks of Sirius XM Radio Inc. All Inc. and any use of such marks by PIONEER Pioneer accepts no responsibility for data device with numerous folder hierarchies. CORPORATION is under license. Other rights reserved. -
Page 26: Specifications
