P/N
REF.#
1
0038470000
Neck, Jeff Beck Stratocaster, R/W
2
0029250000
Tuning Key, (1) Set
3
0029251000
Tuning Key, (1) Set
4
0041615000
Nut Assembly
0041611000
0041613000
0041612000
5
0020810000
Truss Rod Adjustment Nut
0023811000
6
0056230xxx
Body, Jeff Beck Strat, Solid Color
7
0054038000
Neck Mounting Plate
0021424000
0031571000
0023811000
8
0021453000
Strap Button
0021422000
0020491000
0019056000
9
0038463000
Pickguard, Jeff Beck Strat
0021407000
10
0027666000
Pickup, Neck/Middle, Lace Sensor
0048631000
0036878000
11
0038465000
Pickup, Bridge, Dual Lace Sensor
0048631000
0036878000
12
0013446000
Control, 250K, Volume/Tone (2)
0016352000
0022384000
13
0021686000
Control, 250K, Dual
0016352000
0022384000
14
0056149000
Knob, Volume, White
15
0056148000
Knob, Tone, White (2)
16
0020803000
Switch, DPDT Push Push
0022602000
0021404000
17
0053291000
Switch, Lever 5-Position
0021417000
0019554000
18
0024832000
Capacitor, .022uF, (2)
19
0024996001
Resistor, 82K
20
0012869000
Solder Lug
0015116000
21
0021956000
Output Jack
0016352000
0016436000
22
0010280090
Jack Ferrule
0021407000
23
0026095000
Bridge Assy, Am Std Strat
0010272100
Tremolo Claw
0015636000
0018671000
0026103000
Tremolo Arm
0019463000
JEFF BECK STRATOCASTER 0109600
DESCRIPTION
Mounting Screw
Shim, .005
Shim, .010
Truss Rod Adjusting Wrench
Mounting Screw
Tilt Adjustment Screw
Tilt Adjusting Wrench
Mounting Screw
Felt Washer, White
Felt Washer, Black
Mounting Screw
Mounting Screw
Tubing, Latex Cut
Mounting Screw
Tubing, Latex Cut
Mounting Hex Nut
Lock Washer, Intl
Mounting Hex Nut
Lock Washer, Intl
Button, Switch
Mounting Screw
Mounting Screw
Knob, White
Mounting Screw
Mounting Hex Nut
Lock Washer, Intl
Mounting Screw
Mounting Screw
Tremolo Spring
Knob, Tremolo Arm, White
P/N
REF.#
24
0028957000
Pivot Screw, Am. Std.
0028958000
25
0026097000
Bridge Plate
0026098000
0019656000
26
0026099000
Bridge Section (6)
27
0017031000
Intonation Screw (6)
0019395000
0019394000
28
0026779000
Height Adjustment Screw 1&6
0026780000
Height Adjustment Screw 2-5
29
0012180000
Spring, Tremolo Arm
30
0026105000
Back Plate, Tremolo, Black/White/Black
0021407000
DESCRIPTION
Insert, Am. Std.
Tremolo Block
Mounting Screw
Intonation Spring 5&6
Intonation Spring 1-4
Mounting Screw
Body Part Number
0056230541
Vintage White
0056230557
Surf Green
0056230576
Midnight Purple
Pg. 3 of 4
05-24-2000
