Page 2 Hawking Technology reserves the right to revise or updates its products, software, or documentation without obligation to notify any individual or entity. Please direct all inquiries to:techsupport@hawkingtech.com...
Page 3 Federal Communication Commission Interference Statement FCC Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 4 Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation.
Page 5: R&Tte Compliance Statement
R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
Page 6 C O N T E N T S CHAPTER I: PRODUCT INFORMATION 1-1 Introduction and safety information 1-2 Safety Information 1-3 System Requirements 1-4 Package Contents 1-5 Product Overview CHAPTER II: SYSTEM AND NETWORK SETUP 2-1 Build network connection 2-2 Connecting to wireless broadband router by web browser 2-2-1 Windows 95/98/Me IP address setup 2-2-2 Windows 2000 IP address setup 2-2-3 Windows XP IP address setup...
Page 7 2-4-3 Remote Management 2-5 Setup Internet Connection (WAN Setup) 2-5-1 Setup procedure for ‘Dynamic IP’ 2-5-2 Setup procedure for ‘Static IP’ 2-5-3 Setup procedure for ‘PPPoE’ 2-5-4 Setup procedure for ‘PPTP’ 2-5-5 Setup procedure for ‘L2TP’ 2-5-6 Setup procedure for ‘DNS’ 2-5-7 Setup procedure for ‘DDNS’...
Page 8 3-1 Quality of Service (QoS) 3-1-1 Basic QoS Settings 3-1-2 Add a new QoS rule 3-2 Network Address Translation (NAT) 3-2-1 Basic NAT Settings (Enable or disable NAT function) 3-2-2 Port Forwarding 3-2-3 Virtual Server 3-2-4 Port Mapping for Special Applications 3-2-5 UPnP Setting 3-2-6 ALG Settings 3-3 Firewall...
Page 9 4-1 Hardware Specification 4-2 Troubleshooting 4-3 Glossary...
Page 10: Chapter I: Product Information
Chapter I: Product Information 1-1 Introduction and safety information Thank you for purchasing the HWRN1A Hi-Gain 300N Router! This highly efficient router is the best choice for Small office / Home office users, all computers and network devices can share a single xDSL / cable modem internet connection at high speed.
Page 11 • Allows you to monitor the router’s status like: DHCP Client Log, System Log, Security Log and Device/Connection Status • Easy to use Web-based GUI for network configuration and management purposes • Remote management function allows configuration and upgrades from a remote computer (over the Internet) •...
Page 12 1-2 Safety Information In order to keep the safety of users and your properties, please follow the following safety instructions: 1. This router is designed for indoor use only; DO NOT place this router outdoors. 2. DO NOT put this router at or near hot or humid places, like kitchens or bathrooms.
Page 13 electrical power off immediately, and call dealer of purchase for help.
Page 14 1-3 System Requirements One computer (Mac or PC) with an available CD or DVD-ROM drive. Internet Web Browser (Internet Explorer, Safari, etc.) A Wired or Wireless networking adapter (e.g. Airport card, built-in Ethernet adapter, etc.) Broadband Modem (e.g. Cable or DSL)
Page 15 1-4 Package Contents Before you start to use this router, please check if there’s anything missing in the package, and contact your dealer of purchase to claim for missing items: □ Broadband Router (main body, 1 pcs)…………………………… 1 □ Quick Installation Guide (1 pcs) ………………………………… 2 □...
Page 16 1-5 Product Overview Top Panel LED Name Light Status Description Router is switched on and correctly powered Wireless network is switched on or WPS mode is on. Wireless Wireless network is switched off Flashing Wireless LAN activity (transferring or receiving data). WAN port (Internet) is running at 100Mbps Internet WAN port (Internet) is running at 10Mbps...
Page 17: Back Panel
Back Panel Antenna B Antenna C Antenna A Item Name Description Antenna A to C All are 3dBi dipole antennas. Power Power connector, connects to A/C power adapter. Reset Reset the router to factory default settings (clear all settings). Press this button and hold for 10 seconds to restore all settings to factory defaults.
Page 18: Chapter Ii: System And Network Setup
Chapter II: System and Network Setup 2-1 Build network connection Please follow the following instructions to build the network connection between your new WIRELESS router and your computers and other network devices: 1. Connect your xDSL / cable modem to the WAN port of router by Ethernet cable.
Page 19 4. Please check all LEDs on the front panel. ‘PWR’ LED should be steadily on, WAN and LAN LEDs should be on if the computer / network device connected to the respective port of the router is powered on and correctly connected. If PWR LED is not on, or any LED you expected is not on, please recheck the cabling, or jump to ‘4-2 Troubleshooting’...
Page 20: Connecting To Wireless Broadband Router By Web Browser
2-2 Connecting to wireless broadband router by web browser After the network connection is built, the next step you should do is setup the router with proper network parameters, so it can work properly in your network environment. Before you can connect to the router and start configuration procedures, your computer must be able to get an IP address automatically (use dynamic IP address).
Page 21 2. Select ‘Obtain an IP address from a DHCP server’ and then click ‘OK’.
Page 22 2-2-2Windows 2000 IP address setup: 1. Click ‘Start’ button (it should be located at lower-left corner of your computer), then click control panel. Double-click Network and Dial-up Connections icon; click Local Area Connection, and Local Area Connection Properties window will appear. Select ‘Internet Protocol (TCP/IP)’...
Page 23 2. Select ‘Obtain an IP address automatically’ and ‘Obtain DNS server address automatically’, then click ‘OK’.
Page 24 2-2-3Windows XP IP address setup: 1. Click ‘Start’ button (it should be located at lower-left corner of your computer), then click control panel. Double-click Network and Internet Connections icon, click Network Connections, and then double-click Local Area Connection, Local Area Connection Status window will appear, and then click ‘Properties’...
Page 25 2. Select ‘Obtain an IP address automatically’ and ‘Obtain DNS server address automatically’, then click ‘OK’.
Page 26 2-2-4Windows Vista IP address setup: 1. Click ‘Start’ button (it should be located at lower-left corner of your computer), then click control panel. Click View Network Status and Tasks, and then click Manage Network Connections. Right-click Local Area Network, then select ‘Properties’. Local Area Connection Properties window will appear, select ‘Internet Protocol Version 4 (TCP / IPv4), and then click ‘Properties’...
Page 27 2. Select ‘Obtain an IP address automatically’ and ‘Obtain DNS server address automatically’, then click ‘OK’.
Page 29 2-2-5 Router IP address lookup After the IP address setup is complete, please click ‘start’ -> ‘run’ at the bottom-lower corner of your desktop: Input ‘cmd’, then click ‘OK’...
Page 30 Input ‘ipconfig’, then press ‘Enter’ key. Please check the IP address followed by ‘Default Gateway’ (In this example, the IP address of router is 192.168.1.2, please note that this value may be different.) NOTE: If the IP address of Gateway is not displayed, or the address followed by ‘IP Address’...
Page 31 NOTE: If you can’t see the web management interface, and you are being prompted to input user name and password again, it means you didn’t input username and password correctly. Please retype user name and password again. If you are certain that user name and password you typed are correct, please go to ‘4-2 Troubleshooting’...
Page 32 2-3 Using ‘Quick Setup’ This router provides a ‘Quick Setup’ procedure, which will help you to complete all required settings you need to access the Internet in very short time. Please follow the following instructions to complete the ‘Quick Setup’: Please go to Quick Setup Wizard menu by clicking ‘Setup’...
Page 33 And the following message will be displayed: 1. Set Time Zone Here are descriptions of every setup items: Set Time Please press button, a drop-down list Zone (1): will be shown, and you can choose a time zone of the location you live. Time Server Input the IP address / host name of time server Address (2):...
Page 34 2. Broadband Type Please choose the broadband (Internet connection) type you’re using and then click ‘Next’. There are six types of Internet connection, they are: Cable Modem - Please go to section 2-3-1 Fixed-IP xDSL - Please go to section 2-3-2 PPPoE xDSL - Please go to section 2-3-3 PPTP xDSL...
Page 35 2-3-1 Setup procedure for ‘Dynamic IP (Cable Modem)’: Here are descriptions of every setup items: Host Name (1): Please input the host name of your computer, this is optional, and only required if your service provider asks you to do so. MAC address (2): Please input MAC address of your computer here, if your service provider only permits computer with...
Page 36 2-3-2 Setup procedure for ‘Fixed-IP (DSL modem)’: Here are descriptions of every setup items: IP address Please input IP address assigned assigned by your by your service provider. Service Provider (1): Subnet Mask (2): Please input subnet mask assigned by your service provider DNS address (3): Please input the IP address of DNS server provided...
Page 37 2-3-3 Setup procedure for ‘PPPoE xDSL’: Here are descriptions of every setup items: User Name (1): Please input user name assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here. Service Name (3): Please give a name to this Internet service, this is optional...
Page 38 When you finish with all settings, please click ‘OK’ (7); if you want to go back to previous menu, click ‘Back’. MTU - Please use default value if you don’t know what it is, or ask your service provider for a proper value. Connection Type - There are 3 options: ‘Continuous’...
Page 39 Select how you obtain IP address from your service provider here. You can choose ‘Obtain an IP address automatically’ (equal to DHCP, please refer to ‘Cable Modem’ section above), or ‘Use the following IP address’ (i.e. static IP address). WAN interface settings must be correctly set, or the Internet connection will fail even if those settings of PPTP settings are correct.
Page 40 Connection Please input the connection ID here, this is ID (4): optional and you can leave it blank. MTU (5): Please input the MTU value of your network connection here. If you don’t know, you can use default value. Connection Please select the connection type of Internet type (6): connection you wish to use, please refer to last...
Page 41 2-4 Basic Setup In this chapter, you’ll know how to change the time zone, password, and remote management settings. Please start your web browser and log onto router web management interface, then click ‘Admin’ tab. HERE! 2-4-1 Time zone and time auto-synchronization Please follow the following instructions to set time zone and time auto-synchronization parameters: Please click ‘Admin’...
Page 42 Press ‘Continue’ to save the settings made and go back to the web management interface; press ‘Apply’ to save the settings made and restart the router so the settings will take effect after it reboots. NOTE: You can refer to the instructions given in the last chapter: ‘Using Quick Setup’, for detailed descriptions on time zone settings.
Page 43 New Password (2): Please input new password here. Confirmed Please input new password here again. Password (3): When you finish, click ‘Apply’. If you want to keep original password unchanged, click ‘Cancel’. If the password you typed in ‘New Password’ (2) and ‘Confirmed Password’...
Page 44 Please use new password to enter web management interface again, and you should be able to login with new password. 2-4-3 Remote Management This router does not allow management access from Internet, to prevent possible security risks (especially when you defined a weak password, or didn’t change default password).
Page 45 Here are descriptions of every setup item: Host Address (1): Input the IP address of the remote host you wish to initiate a management access. Port (2): You can define the port number this router should expect an incoming request. If you’re providing a web service (default port number is 80), you should try to use other port number.
Page 46 NOTE: When you want to manage this router from another computer over the internet, you have to input the IP address and port number of this router. If your Internet service provider assigns you with a static IP address, it will not be a problem; but if the IP address your service provider assigns to you will vary every time you establish an internet connection, this will be a problem.
Page 47 2-5 Setup Internet Connection (Setup) Internet connection setup can be done by using ‘Quick Setup’ menu described in chapter 2-3. To start configuration, please follow the instructions: Please click ‘Setup’ tab at the top of the web management interface, and complete the time settings and click ‘Next’.
Page 48 2-5-1 Setup procedure for ‘Dynamic IP’: Here are descriptions of every setup items: Host Name (1): Please input host name of your computer, this is optional, and only required if your service provider asks you to do so. MAC Address (2): Please input MAC address of your computer, if your service provider only permits computer with certain MAC address to access internet.
Page 49 Please click ‘Continue’ (1) to go back to previous setup menu; to continue on router setup, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). 2-5-2 Setup procedure for ‘Static IP’: Here are descriptions of every setup items: IP address assigned Please input IP address assigned...
Page 50 Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). If you want to reset all settings in this page back to previously-saved value, please click ‘Cancel’...
Page 51 optional MTU (4): Please input the MTU value of your network connection here. If you don’t know, you can use default value. Connection Please select the connection type of Internet Type (5): connection you wish to use. Continuous – The connection will be kept always on. If the connection is interrupted, the router will re-connect automatically.
Page 52 settings will take effect (Please wait for about 30 seconds while router is rebooting). If you want to reset all settings in this page back to previously-saved value, please click ‘Cancel’ button. 2-5-4 Setup procedure for ‘PPTP’: PPTP requires two kinds of setting: WAN interface setting (setup IP address) and PPTP setting (PPTP user name and password).
Page 53 Now please go to PPTP settings section: Here are descriptions of every setup items: User ID (1): Please input user ID (user name) assigned by your Internet service provider here. Password (2): Please input the password assigned by your Internet service provider here.
Page 54 BEZEQ-ISRAEL (6): If you are connecting to the BEZEQ network in Israel. Please enable this function. Connection Please select the connection type of Internet type (7): connection you wish to use, please refer to section 2-5-3 for detailed descriptions. Idle Time Out (8): Please input the idle time out of Internet connection you wish to use, and refer to section 2-5-3 for detailed descriptions.
Page 55 L2TP Please input the IP address of PPTP gateway Gateway (3): assigned by your Internet service provider here. MTU (4): Please input the MTU value of your network connection here. If you don’t know, you can use default value. Connection Please select the connection type of Internet connection type (5): you wish to use, please refer to section 2-5-3 for detailed...
Page 56 Here are descriptions of every setup items: DNS Address (1): Please input the IP address of DNS server provided by your service provider. NOTE: Only IP address can be entered here; DO NOT use the hostname of DNS server! (i.e. only numeric characters and dots are accepted) 10.20.30.40………………………………………………………………...
Page 57 example: DynDNS (http://www.dyndns.org) TZO (http://www.tzo.com) Please go to one of the DDNS service provider’s web pages listed above, and get a free DDNS account by the instructions given on their webpage. Here are descriptions of every setup items: Dynamic DNS (1): If you want to enable DDNS function, please select ‘Enabled’;...
Page 58 Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). If you want to reset all settings in this page back to previously-saved value, please click ‘Cancel’...
Page 59 Wired LAN Configuration Before all computers using wired Ethernet connection (i.e. those computers connected to this router’s LAN port 1 to 4 by Ethernet cable) can communicate with each other and access internet, they must have a valid IP address. There are two ways to assign IP addresses to computers: static IP address (set the IP address for every computer manually), and dynamic IP address (IP address of computers will be assigned by router automatically.
Page 60 Please follow the following instructions to set wired LAN parameters: Please click ‘Local Network’ tab at the top of web management interface, there are three setup groups here: ‘LAN IP’, ‘DHCP Server’, and ‘Static DHCP Leases Table’. Here are setup instructions for each of them: 2-6-1 LAN IP section: Here are descriptions of every setup item: IP address (1):...
Page 61 2-6-2 DHCP Server: These settings are only available when ‘DHCP Server’ in ‘LAN IP’ section is ‘Enabled’, and here are descriptions of every setup item: Lease Time (1): Please choose a lease time (the duration that every computer can keep a specific IP address) of every IP address assigned by this router from dropdown menu.
Page 62 2-6-3 Static DHCP Leases Table: This function allows you to assign a static IP address to a specific computer forever, so you don’t have to set the IP address for a computer, and still enjoy the benefit of using DHCP server. A maximum of 16 static IP addresses can be assigned here.
Page 63 If you want to remove all characters you just entered, click ‘Clear’. After you clicked ‘Add’, the MAC address and IP address mapping will be added to ‘Static DHCP Leases Table’ section. If you want to delete a specific item, please check the ‘Select’ box of a MAC address and IP address mapping (1), then click ‘Delete Selected’...
Page 64: Wireless Lan Configuration
2-7 Wireless LAN Configuration If your computer, PDA, game console, or other network devices which is equipped with wireless network interface, you can use the wireless function of this router to let them connect to Internet and share resources with other computers with wired-LAN connection. You can also use the built-in security functions to protect your network from being intruded by malicious intruders.
Page 65 Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). 2-7-1 Basic Wireless Settings Please click ‘Basic Setup’...
Page 66 e. AP Bridge-WDS: Connect this router with up to four WDS-capable wireless routers, to expand the scope of network. f. Universal Repeater: The router can act as Station and AP at the same time. It can use Station function to connect to a Root AP and use AP function to service all wireless stations within its coverage.
Page 67 Here are descriptions of every setup items: Band (2): Please select the radio band from one of following options: 2.4 GHz (B) 2.4GHz band, only allows 802.11b wireless network clients to connect to this router (maximum transfer rate 11Mbps). 2.4 GHz (N) 2.4GHz band, only allows 802.11n wireless network clients to connect to this router (maximum transfer rate 300Mbps).
Page 68 NOTE: For 802.11b and 802.11g mode, the signals can be transmitted only by antenna 1 (The antenna on the right side of the rear panel). For 802.11n mode: The router is operating in a 2T3R Spatial Multiplexing MIMO configuration. 2 antennas are for signal transmitting and 3 antennas are for signal receiving.
Page 69 NOTE: If you don’t have special reason to limit the type of allowed wireless clients, it’s recommended to choose ‘2.4 GHz (B+G+N) to maximize wireless client compatibility. TIPS: You can try to change channel number to another one if you think the data transfer rate is too slow.
Page 70 access point. Click ‘Select Site Survey’ button, then a “Wireless Site Survey Table” will pop up. It will list all available access points near by. You can select one access point in the table and it will join wireless LAN through this access point. WLAN MAC (5): For some applications, you may need to designate a specific MAC address for the router.
Page 71 Here are descriptions of every setup items: Band (2) Select the band you want to use, two wireless routers must use the same setting. Channel Select the channel you want to use, two wireless Number (3) routers must use the same setting. address (4) Input the MAC address of another wireless router.
Page 72 Here are descriptions of every setup items: Band (2) Select the band you want to use, all the wireless routers must use the same setting. Channel Select the channel you want to use, all the wireless Number (3) routers must use the same setting. MAC address Input the MAC address of other wireless routers.
Page 73 Here are descriptions of every setup items: Band (2) Select the band you want to use, all the wireless routers must use the same setting. ESSID (3) Input the ESSID of your wireless router, the setting should be the same with other wireless routers for the convenience of roaming.
Page 74 MAC address Input the MAC address of other wireless routers. 1 to 4 (6 - 8) Click to set security settings for this connection Security (9) (Please go to section ‘2-7-3 Wireless Security’ for detailed instructions). 2-7-1-6 Setup procedure for ‘Universal Repeater’ In this mode, the router can act as a wireless repeater;...
Page 75 Here are descriptions of every setup items: Band (2) Select the band you want to use, all the wireless routers must use the same setting. ESSID (3) This is the name of wireless router. You can type any alphanumerical characters here, maximum 32 characters.
Page 76 Please click ‘Continue’ to go back to previous setup menu; to continue on router setup, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). 2-7-2 Advanced Wireless Settings This router provides some advanced control of wireless parameters, if you want to configure these settings, please click ‘Wireless’...
Page 77 Here are descriptions of every setup items: Fragment Set the Fragment threshold of wireless radio. Threshold(1): Do not modify default value if you don’t know what it is, default value is 2346. RTS Threshold(2): Set the RTS threshold of wireless radio. Do not modify default value if you don’t know what it is, default value is 2347.
Page 78 Broadcast ESSID(9): Decide if the wireless router will broadcast its own ESSID or not. You can hide the ESSID of your wireless router (set the option to ‘Disable’), so only those people who know the ESSID of your wireless router can get connected. CTS Protect(10): Enabling this setting will reduce the chance of radio signal collisions between 802.11b and 802.11g/n...
Page 79 Please click ‘Continue’ to go back to previous setup menu; to continue on router setup, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). 2-7-3 Wireless Security It’s very important to set wireless security settings properly! If you don’t, hackers and malicious users can reach your network and valuable data without your consent and this will cause serious security problems.
Page 80 Here are descriptions of every setup item: Key Length (2): There are two types of WEP key length: 64-bit and 128-bit. Using ‘128-bit’ is safer than ’64-bit’, but will reduce some data transfer performance. Key Format (3): There are two types of key format: ASCII and Hex. When you select a key format, the number of characters of key will be displayed.
Page 81 and A-F. You must enter at least one encryption key here, and if you entered multiple WEP keys, they should not be same with each other. Enable 802.1x IEEE 802.1x is an authentication protocol. Every Authentication (9): user must use a valid account to login to this wireless router before accessing the wireless LAN.
Page 82 After you finish WEP setting, please click ‘Apply’ button (10) and the following message will be displayed on your web browser: Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting).
Page 83 characters, up to 63), or Hex (64 characters of 0-9, and a-f). Pre-shared Please input the WPA passphrase here. Key (4): It’s not recommended to use a word that can be found in a dictionary due to security reason. After you finish WPA Pre-shared key setting, please click ‘Apply’ button (5) and the following message will be displayed on your web browser: Please click ‘Continue’...
Page 84 Here are descriptions of every setup items: WPA Unicast Please select a type of WPA cipher suite. Cipher Suite: Available options are: WPA (TKIP), WPA2 (AES), and WPA2 Mixed. You can select one of them, but you have to make sure your wireless client support the cipher you selected.
Page 85 2-7-4 Wireless Access Control This function will help you to prevent unauthorized users from connecting to your wireless router; only those wireless devices who have the MAC address you assigned here can gain access to your wireless router. You can use this function with other security measures described in previous section, to create a safer wireless environment.
Page 86 MAC addresses. Enable Wireless To enforce MAC address filtering, Access Control (5): you have to check ‘Enable Wireless Access Control’. When this item is unchecked, wireless router will not enforce MAC address filtering of wireless clients. MAC Address (6): Input the MAC address of your wireless devices here, dash ( - ) or colon ( : ) are not required.
Page 87 Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). If you want to reset all settings in this page back to previously-saved value, please click ‘Cancel’...
Page 88 Here are descriptions of every setup items: Enable WPS (1) Check this box to enable WPS function, uncheck it to disable WPS. Wi-Fi Protected WPS-related system information will be displayed Setup Information here: WPS Status: If the wireless security (encryption) function of this wireless router is properly set, you’ll see ‘Configured’...
Page 89 Authentication Mode: The wireless security authentication mode of this wireless router will be displayed here. If you don’t enable security function of the wireless router before WPS is activated, the router will auto set the security to WPA (AES) and generate a set passphrase key for WPS connection.
Page 90 2-7-6 Security Tips for Wireless Network Here are some quick tips to help you improve the security level of your wireless network: 1. Never use simple words (like school, apple and computer) as WEP encryption or WPA passphrase. 2. A complicated (combination of numbers, alphabets, and even symbols) WEP key and WPA passphrase is much safer than simple and short ones.
Page 91: Chapter Iii Advanced Functions
Chapter III Advanced Functions 3-1 Quality of Service (QoS) Quality of service provides an efficient way for computers on the network to share the internet bandwidth with a promised quality of internet service. Without QoS, all computers and devices on the network will compete with each other to get internet bandwidth, and some applications which require guaranteed bandwidth (like video streaming and network telephone) will be affected, therefore an unpleasing result will occur, like...
Page 92 Here are descriptions of every setting: Enable QoS (1): Check this box to enable QoS function, unselect this box if you don’t want to enforce QoS bandwidth limitations. Total Download You can set the limit of total download Bandwidth (2): bandwidth in kbits.
Page 93 clicked. Move Up (9): You can pull up the priority of the QoS rule you selected by clicking this button. Move Down (10): You can lower the priority of the QoS rule you selected by clicking this button. Reset (11): If you want to erase all values you just entered.
Page 94 Here are descriptions of every setup items: Rule Name (a): Please give a name to this QoS rule (up to 15 alphanumerical characters) Bandwidth (b): Set the bandwidth limitation of this QoS rule. You have to select the data direction of this rule (Upload of Download), and the speed of bandwidth limitation in Kbps, then select the type of QoS: ‘guarantee’...
Page 95 single port, just input the port number, like ‘80’. Remote IP Specify the remote (destination) IP address Address: (e): that will be affected by this rule. Please input the starting IP address in the left field, and input the end IP address in the right field to define a range of IP addresses, or just input the IP address in the left field to define a single IP address.
Page 96 If you want to erase all values you just entered. Click ‘Reset’...
Page 97 3-2 Network Address Translation (NAT) Network address translations solve the problem of sharing a single IP address to multiple computers. Without NAT, all computers must be assigned with a valid Internet IP address to get connected to Internet, but Internet service providers only provide very few IP addresses to every user.
Page 98 Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). 3-2-2 Port Forwarding This function allows you to redirect a single port or consecutive ports of Internet IP address to the same port of the IP address on local network.
Page 99 Here are descriptions of every setup items: Enable Port Check this box to enable port mapping, Forwarding (1): and uncheck this box to disable port mapping. Private IP (2): Input the IP address of the computer on local network which provides internet service. Computer Name (3): Pull down the menu and all the computers connected to the router will be listed here.
Page 100 Reset (12): Unselect all mappings. After you finish with all settings, please click ‘Apply’ (13) button and the following message will be displayed on your web browser: Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’...
Page 101 Here are descriptions of every setup items: Enable Virtual Check this box to enable virtual server, Server (1): and uncheck this box to disable virtual server. Private IP (2): Input the IP address of the computer which provides Internet service. Computer Name (3): Pull down the menu and all the computers connected to the router will be listed here.
Page 102 16 alphanumerical characters. Add (8): Add the mapping to virtual server table. Reset (9): Remove all inputted values. Virtual Server All existing virtual server mappings will be Table (10): displayed here. Delete Please select a virtual server mapping by clicking Selected (11): the ‘Select’...
Page 103 3-2-4 Port Mapping for Special Applications Some applications require more than one connection at a time; these applications won’t work with simple NAT rules. In order to make these applications work, you can use this function to let these applications work. Go to ‘Apps and Gaming’...
Page 104 port numbers for this particular application. UDP Port to Open (5): This is the out going (Outbound) range of UDP port numbers for this particular application. Comment (6): The description of this setting. Pop. Applications This section lists the more popular applications that (7): require multiple connections.
Page 105 Note: Only one LAN client can use a particular special application at a time. After you finish with all settings, please click ‘Apply’ (14) button and the following message will be displayed on your web browser: Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’...
Page 106 There is only one option in this page, please select ‘Enable’ or ‘Disable’ to enable or disable UPnP function, then click ‘Apply’ button, and the following message will be displayed on your web browser: Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’...
Page 107 3-2-6 ALG Settings Application Layer Gateway (ALG) is a special function of this router. It includes many preset routing rules for numerous applications which require special support. With these supports, those applications which required special support will be able to work with NAT architecture. Please click ‘Apps and Gaming’...
Page 108 Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting). If you want to reset all settings in this page back to previously-saved value, please click ‘Cancel’...
Page 109 3-3 Firewall Besides NAT, this router also provides firewall function to block malicious intruders from accessing your computers on local network. These functions include inbound attack prevention, and block outbound traffics, like block URLs which have pre-defined keywords. Please follow instructions to enable or disable firewall function: Please click ‘Security’...
Page 110 from connecting to the network; it can also allow or deny computers with specific IP address, protocol, or port. Please click ‘Security’ tab at the top of web management interface, then click ‘Access Control’, and the following message will be displayed on your web browser: Here are descriptions of every setup items: Enable MAC...
Page 111 wireless device indicates ‘aa-bb-cc-dd-ee-ff’ or ‘aa:bb:cc:dd:ee:ff’, just input ‘aabbccddeeff’ Computer Name (3): Pull down the menu and all the computers connected to the router will be listed here. You can easily to select the computer name without checking the IP address of the computer. Comment (4): You can input any text here as the comment of this MAC address, like ‘ROOM 2A Computer’...
Page 112 to decide the behavior of IP filtering table. If you select deny, all IP addresses listed in filtering table will be denied from connecting to the network; if you select allow, only IP addresses listed in filtering table will be able to connect to the network, and rejecting all other network devices.
Page 113 3-3-1-1 Add PC After button is clicked, the following message will be displayed on your web browser:...
Page 114 Here are descriptions of every setup items: Client PC Please input any text to describe this IP Description (a): address, up to 16 alphanumerical characters. Client PC IP Please input the starting IP address in the left address (b): field, and input the end IP address in the right field to define a range of IP addresses, or just input the IP address in the left field to define a single IP address.
Page 115 3-3-2 URL Blocking If you want to prevent computers in a local network from accessing certain website (like pornography, violence, or anything you want to block), you can use this function to stop computers in a local network from accessing the site you define here. This function is useful for parents and company managers.
Page 116 Add (3): Click ‘Add’ button to add the URL / keyword to the URL / Keyword filtering table. Reset (4): Click ‘Reset’ to remove the value you inputted in URL/Keyword field. Current URL All existing URL/Keywords in filtering Blocking Table (5): table will be listed here. Delete Selected (6): If you want to delete a specific URL/Keyword entry, check the ‘select’...
Page 117 3-3-3 DoS Attack Prevention Denial of Service (DoS) is a common attack measure, by transmitting a great amount of data or request to your Internet IP address and server, the Internet connection will become very slow, and server may stop responding because it is not capable of handling too much traffic.
Page 118 but when you activate this function, you will not be able to ping your own router from internet, too. Port Scan (3): Some malicious intruder will try to use a ‘port scanner’ to know how many ports of your Internet IP address are open, and they can collect a lot of valuable information by doing so.
Page 119 3-3-3-1 DoS - Advanced Settings When you click ‘Advanced’ button in DoS menu, the following message will be displayed on your web browser: Here are descriptions of every setup items: Ping of Death (a): Set the threshold of when this DoS prevention mechanism will be activated.
Page 120 After you finish with all settings, please click ‘Apply’ (6) button and the following message will be displayed on your web browser: Please click ‘Continue’ to go back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 30 seconds while router is rebooting).
Page 121 Here are descriptions of every setup items: Enable DMZ (1): Check this box to enable DMZ function, uncheck this box to disable DMZ function. Public IP You can select ‘Dynamic IP’ or ‘Static IP’ here. address (2): If you select ‘Dynamic IP’, you have to select an Internet connection session from dropdown menu;...
Page 122 Current All existing public IP address and private IP DMZ table (7): address mapping will be displayed here. Delete If you want to delete a specific DMZ entry, check Selected (8): the ‘select’ box of the DMZ entry you want to delete, then click ‘Delete Selected’...
Page 123 3-4 System Status The functions described here will provide you with system related information. To enter system status menu, please either click ‘Status’ link located at the upper-right corner of web management interface, or click ‘Status’ button in main menu. 3-4-1 System information and firmware version You can use this function to know the system information and firmware version of this router.
Page 124 3-4-2 Internet Connection Status You can use this function to know the status of current Internet connection. Please click ‘Status’ menu at the top of web management interface, and the following message will be displayed on your web browser: This information will vary depending on the connection status. 3-4-3 Device Status You can use this function to know the status of your router.
Page 125 This information will vary depending on the device status. 3-4-4 System Log All important system events are logged. You can use this function to check the event log of your router. Please click ‘System Log’ tab at the top of web management interface, and the following will be displayed on your web browser:...
Page 126 The system events will be displayed in this page, and here are descriptions of every buttons: Save (1): Save current event log to a text file. Clear (2): Delete all event logs displayed here. Refresh (3): Refresh the event log display. 3-4-5 Security Log All information about network and system security is kept here, and you can use this function to check the security event log of your router.
Page 127 3-4-5 Active DHCP client list If you’re using the DHCP server function of this router, you can use this function to check all active DHCP leases issued by this router. Please click ‘Active DHCP client’ tab at the top of web management interface, and the following message will be displayed on your web browser: All information about active DHCP leases issued by this router will be...
Page 128 3-5 Configuration Backup and Restore You can backup all configurations of this router to a file, so you can make several copied of router configuration for security reason. To backup or restore router configuration, please follow the instructions: Please click ‘Admin’ tab located at the upper-right of web management interface, then click ‘Configuration Tools’.
Page 129 Click ‘Browse’ button first, you’ll be prompted to provide the filename of the firmware upgrade file. Please download the latest firmware file from the Hawking Technologies website, and use it to upgrade your router. After a firmware upgrade file is selected, click ‘Apply’ button, and the router will start firmware upgrade procedure automatically.
Page 130 3-7 System Reset If you think you network performance is bad, or you find the behavior of the router is strange, you can perform a router reset. Sometimes it will solve the problem. To do so, please click ‘Admin’ tab located at the upper-right corner of web management interface, then click ‘Reset’.
Page 131: Chapter Iv: Appendix
Chapter IV: Appendix 4-1 Hardware Specification Switch: IC+ IP175C (5 Port Switch) Flash: 4MB SDRAM: 16MB WAN Port: 10/100M UTP Port x 1 LAN Ports: 10/100M UTP Port x 4 Antenna: 3dBi Dipole Antenna x 3 (2T3R Spatial Multiplexing MIMO configuration.
Page 132 4-2 Troubleshooting If you found the router is working improperly or stops responding to you, don’t panic! Before you contact your dealer of purchase for help, please read this troubleshooting first. Some problems can be solved by yourself within very short time! Scenario Solution Router is not...
Page 133 with your computer directly attached to the device provided by your Internet service provider. d. Check PPPoE / L2TP / PPTP user ID and password again. e. Call your Internet service provide and check if there’s something wrong with their service.
Page 134 management interface: IP address of the router! password is wrong b. Password is case-sensitive. Make sure the ‘Caps Lock’ light is not illuminated. c. If you really forgot the password, do a hard reset. Router becomes hot a. This is not a malfunction, as long as it is not so hot that you cannot touch it for a prolonged period of time b.
Page 135 4-3 Glossary Default Gateway (Router): Every non-router IP device needs to configure a default gateway’s IP address. When the device sends out an IP packet, if the destination is not on the same network, the device has to send the packet to its default gateway, which will then send it out towards the destination.
Page 136 A network mask is also a 32-bit binary pattern, and consists of consecutive leading 1’s followed by consecutive trailing 0’s, such as 11111111.11111111.11111111.00000000. Therefore sometimes a network mask can also be described simply as “x” number of leading 1’s. When both are represented side by side in their binary forms, all bits in the IP address that correspond to 1’s in the network mask become part of the IP network address, and the remaining bits correspond to the host ID.
Page 137 Application Protocol Port Number Telnet SMTP POP3 H.323 1720 SNMP SNMP Trap HTTP PPTP 1723 PC Anywhere TCP 5631 PC Anywhere UDP 5632 PPPoE: Point-to-Point Protocol over Ethernet. Point-to-Point Protocol is a secure data transmission method originally created for dial-up connections; PPPoE is for Ethernet connections.
Page 138 transmission over the Internet. Both TCP and UDP are transport layer protocol. TCP performs proper error detection and error recovery, and thus is reliable. UDP on the other hand is not reliable. They both run on top of the IP (Internet Protocol), a network layer protocol.
