Char-Broil 463320708 Product Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MODEL 463320708 • PRODUCT GUIDE
THIS GRILL IS FOR OUTDOOR USE ONLY.
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
1-800-241-7548
.
463320708 • 80016488 • 11-15-07

Advertisement

loading

Related Manuals for Char-Broil 463320708

Summary of Contents for Char-Broil 463320708

  • Page 1 MODEL 463320708 • PRODUCT GUIDE THIS GRILL IS FOR OUTDOOR USE ONLY. CAUTION: WARNING: Read and follow all safety statements, assembly Failure to follow all manufacturer’s instructions could instructions, and use and care directions before result in serious personal injury and/or property attempting to assemble and cook.
  • Page 2 CAUTION CAUTION CAUTION: Indicates a potentially hazardous situation or For residential use only. Do not use for commercial unsafe practice which, if not avoided, may result in minor cooking. or moderate injury. 2 • 463320708...

  • Page 3: Table Of Contents

    Registration Card ........27 463320708 • 3...
  • Page 4 Check the telephone Retainer Strap by the sun. directory under “Gas Companies” for nearest certified LP • Do not store an LP cylinder in an area where children play. dealers. 4 • 463320708...

  • Page 5: For Your Safety

    Nipple has to be centered into the LP cylinder valve. WARNING If “growing” bubbles appear do not use or move the LP cylinder. Contact an LP gas supplier or your fire department! 463320708 • 5...

  • Page 6: Grill Service Center

    • Do not use grill until leak-tested. • If a leak is detected at any time, STOP and call the fire department. • If you cannot stop a gas leak, immediately close LPcylinder valve and call LP gas supplier or your fire department! 6 • 463320708...
  • Page 7 • Always close LP cylinder valve and remove If ignitor does not work, follow match lighting instructions. coupling nut before moving LP cylinder from After Lighting: Turn knobs to HI position for warm-up. specified operation position. Lighting instructions continued on next page. 463320708 • 7...
  • Page 8 • Cooking surfaces: If a bristle brush is used to clean any of stays lit. the grill cooking surfaces, ensure no loose bristles remain on cooking surfaces prior to grilling. It is not recommended to clean cooking surfaces while grill is hot. 8 • 463320708...
  • Page 9 • Store grill indoors ONLY if LP cylinder is turned off and Firebox disconnected, removed from grill and stored outdoors. Electrode burner • When removing grill from storage, follow “Cleaning the Burner bracket Assembly” instructions before starting grill. 463320708 • 9...
  • Page 10 • When reheating takeout foods or fully cooked meats like hot dogs, grill to 165° F, or until steaming hot. 2 Burner Cooking Great indirect cooking on low. Produces slow, even heating. Ideal for slow roasting and baking. 10 • 463320708...
  • Page 11 The methods below are suggestions for cleaning stainless steel surfaces. Choose a cleaning method appropriate for your needs. It is recommended that you use a Char-Broil® grill cover to help prolong the life and prevent discoloration of your grill.

  • Page 12: Parts List

    Bradley Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collection by Char-Broil ™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™, The Minute Grill™, The Edge™, The Tuscan Collection™, and The Urban Grill™...

  • Page 13: Parts Diagram

    PARTS DIAGRAM – Model No. 463320708 463320708 • 13...

  • Page 14: Assembly

    ASSEMBLY – Model No. 463320708 • Place legs as shown (A). Left leg assembly has large holes on ends of legs. Hook tank exclusion wire into right and left leg assemblies (B). Tank Exclusion Wire Right Leg Assembly Match Holder Left Leg Assembly 14 •...
  • Page 15 Place bottom shelf with cut out hole for LP cylinder next to legs with axle holes. Attach to right and left leg assemblies with 1/4- 20x1-1/2" screws and 1/4-20 flange nuts. 1/4-20 Flange Nut Qty. 4 1/4-20x1-1/2" Machine Screw Qty. 4 Bottom Shelf 463320708 • 15...
  • Page 16 Push leg extenders into right legs. Leg Extenders 1” Hitch Pin Wheel Spacer Axle Washer Qty. 1 Qty. 2 Qty. 1 Wheel Spacer Axle Rod Wheel Wheel Spacer Hitch Axle Washer "Cone" side of wheel against leg 16 • 463320708...
  • Page 17 Carefully lower the grill head onto the cart. Make sure the regulator hose is hanging outside the cart. Attach with 1/4-20x1/2" screws, 7mm lock washers and 7mm flat washers. Grill Head 7mm Flat Washer 7mm Lock Washer 1/4-20x1/2" Qty. 4 Qty. 4 Machine Screw Qty. 4 463320708 • 17...
  • Page 18 Attach shelf with flange nuts on each side (C). 1/4-20 Fiber Washer 1/4-20x1/2" Flange Nut Qty. 4 Machine Screw Qty. 4 Qty. 4 Right Side Shelf • Attach fascia to firebox with #8x3/8" self-tap screws. #8x3/8" Fascia, Right Side Shelf Self-Tap Screw Qty. 2 18 • 463320708...
  • Page 19 Attach sideburner shelf with flange nuts on each side (C). • Attach fascia to firebox with #8x3/8" self-tap screws (D). Fiber Washer 1/4-20x1/2" Qty. 4 Machine Screw Qty. 4 Sideburner Shelf 1/4-20 #8x3/8" Flange Nut Self-Tap Screw Qty. 4 Qty. 2 Back of cart Left Fascia 463320708 • 19...
  • Page 20 Press sideburner control knob onto valve stem (E). • Place grate onto sideburner shelf (F). #8x3/8" Screw Wing Nut Qty. 2 Qty. 1 Sideburner Sideburner Bezel Sideburner Valve Correctly assembled burner-to-valve engagement Sideburner Ignitor Wire Burner Clip Sideburner Control Knob Sideburner Grate 20 • 463320708...
  • Page 21 Swing Away is installed upside-down. • Unscrew ignitor cap and place AA battery into ignitor slot with positive end (+) facing outward. Screw ignitor cap onto ignitor. Swing Away Pivot Wire Leg Wire Cooking Grate AA Battery 463320708 • 21...
  • Page 22 See Use and Care section to correctly Leak Test and CAUTION perform the Burner Flame Check. • Failure to install tank correctly may allow gas hose to be damaged in operation, resulting in the risk of fire. LP Tank Tank Thumbscrew 22 • 463320708...

  • Page 23: Troubleshooting

    • Wires are loose or disconnected. • Reconnect wires or replace electrode/wire assembly. • Wires are shorting (sparking) between • Replace ignitor wire/electrode assembly. ignitor and electrode. • Dead battery. • Replace with a new AA-size alkaline battery. 463320708 • 23...
  • Page 24 • The worn nozzles don’t have enough “bite” to engage the valve. Try cylinder. with worn threads. a second LP dealer. One burner does not • Grease buildup or food particles in • Clean carry-over tube(s) with wire brush. light from other end(s) of carryover tube(s). burner(s). 24 • 463320708...
  • Page 25 • Electrodes are wet. • Has moisture accumulated • Use paper towel to remove moisture. on electrode and/or in burner ports? • Electrodes cracked or • Inspect electrodes for • Replace cracked or broken electrodes. broken “sparks at cracks. crack”. 463320708 • 25...

  • Page 26: Warranty

    Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-800-241-7548 and then clearly marked on the outside of the package and the package is shipped freight/postage pre-paid to the address above. 26 • 463320708...
  • Page 27 Merci d’avoir bien voulu remplir ce questionnaire. Vos réponses nous aideront et aideront d’autres compagnies à vous communiquer des offres spéciales susceptibles de vous intéresser. Si vous préférez ne pas recevoir d’informations concernant ces offres spéciales, veuillez cocher ici 463320708 • 27...
  • Page 28 Always ensure control knobs are in OFF position and regulator is attached to tank BEFORE opening tank valve to avoid low flames. Perform leak test regularly. Thank You for Your Purchase! Char-Broil, LLC • Columbus, GA 31902 • Printed in China...
