Oven And Accessories - Sharp R-22A0 Operation Manual

1 2
10 9 8 6
13
Hub (inside)
15. Turntable
(glass)
17. Coupling
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it is not
damaged.
• Always operate the oven with the turntable and turntable support fitted correctly. This promotes thorough,
even cooking. A badly fitted turntable may rattle, may not rotate properly and could cause damage to the
oven.
• All food and containers of food are always placed on the turntable for cooking.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start the
oven. This does not affect cooking performance.

OVEN AND ACCESSORIES

OVEN
3
1.
2.
5
3.
4.
5.
6.
7.
14
8.
9.
4 7
10. Door safety latches
11
11. Ventilation openings
12. Outer cabinet
13. Power supply cord
14. Door opening button
12
ACCESSORIES:
Check to make sure the following accessories are
provided:
(15) Turntable (16) Turntable support (17) Coupling
Place the turntable support in the centre of the oven
floor so that it can freely rotate around the coupling.
Then place the turntable on to the turntable support
so that it locates firmly into the coupling.
To avoid turntable damage, ensure dishes and
containers are lifted clear of the turntable rim when
removing them from the oven.
16. Turntable
NOTE: When you order accessories, please mention
support
two items: part name and model name to your
dealer or SHARP authorised service agent.
GB-4
Door
Door hinges
Oven lamp
Waveguide cover (DO NOT REMOVE)
Control panel
Coupling
Door latches
Oven cavity
Door seals and sealing surfaces
