- Page 1 Parts List Warranty Ordering Parts Model MD-5139 Retain This Manual for Reference 170630 IMPORTANT: Please read this manual before commencing assembly of this product. OWNER'S ® IMPEX INC. MANUAL 2801 S. Towne Ave, Pomona, CA 91766 Tel: 800- 999-8899 www.marcypro.com support@impex-fitness.com...
-
Page 2: Table Of Contents
To avoid unnecessary delays, please call our TOLL-FREE customer service number. Our Customer Service Agents will provide immediate assistance. Toll-Free Customer Service Number 1-800-999-8899 Mon. – Fri. 9 a.m. – 5 p.m. PST www.marcypro.com support@impex-fitness.com ©IMPEX INC. www.marcypro.com... -
Page 3: Important Safety Notices
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. -
Page 4: Exercise Guidelines
Muscle soreness is common, especially when you first start exercising. If you are painfully sore for a long time, it may be time to change your program. Eventually, your muscle system will become accustomed to the stress and strain placed on it. ©IMPEX INC. www.marcypro.com... - Page 5 Although you may not feel like doing it, taking a rest day at least once a week is important because it gives your body a chance to heal it self. Continuously working your muscles will result in over- training, which will not benefit you in the long run. ©IMPEX INC. www.marcypro.com...
-
Page 6: Warning Label Placement
The warning labels shown here have been placed on the Cross Brace, Rear Stabilizer, and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown. ©IMPEX INC. www.marcypro.com... -
Page 7: Free And Training Area
FREE AND TRAINING AREA ©IMPEX INC. www.marcypro.com... -
Page 8: Important Assembly Information
Tools required for assembling this equipment: Allen Wrenches (provided by manufacturer), and Adjustable Wrench, or Socket Wrench, or Ratchet Wrench. NOTE: It is strongly recommended that this machine be assembled and moved by two or more people to avoid possible injury. ©IMPEX INC. www.marcypro.com... - Page 9 Secure the Weight Bar to each Safety Stop Frame with two M8 x 3/8” Allen Bolts (#81) on each Safety Stop Frame. Ensure the Bolts are fastened so the Weight Bar won’t slide through the Safety Stop Frame. ©IMPEX INC. www.marcypro.com...
-
Page 10: Cable Assembly Instruction
SMITH MACHINE CABLE ASSEMBLY INSTRUCTION Cable Loop Diagram ©IMPEX INC. www.marcypro.com... - Page 11 D.) Draw the Cable around the Pulley then upward to the left Swivel Pulley Bracket. Repeat Procedure B above to install a Pulley to the Bracket. E.) Draw the Cable around the Pulley then clip to the Left Butterfly (#10). ©IMPEX INC. www.marcypro.com...
- Page 12 J.) Connect a Single Handle Strap (#90) to each end of the Cable with a C-clip (#61). K.) When using the Lat Bar (#29), remove one of the Single Handle Strap and connect the Lat Bar to the Cable end with a Short Chain (#63) and two C-Clips. ©IMPEX INC. www.marcypro.com...
- Page 13 ©IMPEX INC. www.marcypro.com...
- Page 14 ©IMPEX INC. www.marcypro.com...
- Page 15 (#68) and one M10 Aircraft Nut (#86). H.) After completing the entire cable installations, come back to this Short Chain to adjust the tension of the Cable System by adjusting the length of the Chain with the C-clip. ©IMPEX INC. www.marcypro.com...
- Page 16 ©IMPEX INC. www.marcypro.com...
- Page 17 Frame (#97). Secure the end of the Cable with one M10 x 1” Allen Bolt (#68), two Ø ¾” Washers (#66), and one M10 Aircraft Nut (#86). E.) Connect the Shiver Bar (#30) to a Long Chain (#64) with a C-clip (#61). Connect the Long Chain to the Cable with another C-clip. ©IMPEX INC. www.marcypro.com...
- Page 18 ©IMPEX INC. www.marcypro.com...
-
Page 19: Weight Capacity And Dimension
4. Examine the equipment regularly for signs of damage or wear. 5. Replace any defective components immediately and/or keep the equipment out of use until repair. 6. Failure to examine regularly may affect the safety level of the equipment. ©IMPEX INC. www.marcypro.com... -
Page 20: Operating Notes
If the tension is too loose, move C-clip (#61) up to shorten the length of Chain. If the tension is too tight, move C-clip (#61) down to extend the length of Chain. Bench Backrest Adjustment Angles Backrest adjustment angle ranges from -13 to 81 ©IMPEX INC. www.marcypro.com... -
Page 21: Weight Resistance Chart
10 lb. plate creates 5 lb. resistance Butterfly (both arms) 100% 10 lb. plate creates 10 lb. resistance Left Cross-Over 10 lb. plate creates 5 lb resistance Right Cross-Over 10 lb. plate creates 5 lb resistance *Numbers are approximate. Actual resistance may vary. ©IMPEX INC. www.marcypro.com... -
Page 22: Smith Machine Parts List
7 ⅛” x 7 ⅛” Triangle Bracket 5 ⅛” x 2 ¾” Bracket 5 ⅛” x 2 ⅜” Bracket Bracket 4 ¾” x 2” Bracket 6 ¼” x 2” Backrest Board Butterfly Arm Pad Lower Cable 59” Upper Cable 229” ©IMPEX INC. www.marcypro.com... - Page 23 M10 x 3 ⅜” Carriage Bolt Carriage Bolt M10 x 3 ½” Allen Bolt M8 x 2 ½” M8 x ⅜” Allen Bolt M6 x ⅝” Phillips Screw Allen Bolt M6 x 1 ¼” Chrome Panel Screw ©IMPEX INC. www.marcypro.com...
- Page 24 M10 x 1 ⅛” Allen Bolt Allen Bolt M10 x 2 ¾” Allen Screw M6 x ¼” Linear Bearing Linear Bearing Cover Phillips Screw M6 x ¼” Allen Wrench (Tool) Allen Wrench (Tool) Allen Wrench (Tool) Allen Wrench (Tool) ©IMPEX INC. www.marcypro.com...
-
Page 25: Smith Machine Exploded Diagram
MD-5139 SMITH MACHINE EXPLODED DIAGRAM ©IMPEX INC. www.marcypro.com... -
Page 26: Bench Parts List
M10 x 2 ½” Allen Bolt M10 x ¾” Allen Bolt M10 x 1 ¾” Allen Bolt M10 x 6 ¾” Allen Bolt M10 x 8 ¼” Allen Bolt M8 x 2” M8 x ⅝” Allen Bolt Washer Ø ¾” ©IMPEX INC. www.marcypro.com... -
Page 27: Bench Exploded Diagram
Ø ⅝” Washer Aircraft Nut MD-5139 BENCH EXPLODED DIAGRAM ©IMPEX INC. www.marcypro.com... -
Page 28: Warranty
IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages of whatsoever natures.
