Summary of Contents for Escort Passport 9500ix

Page 1 Sales: 800-433-3487 Service: 800-543-1608 www.EscortRadar.com ©2008 ESCORT Inc. ESCORT®, PASSPORT®, TrueLock™, SpeedAlert™, AutoLearn™, AutoSensitivity™, AutoVolume™, SmartMute™, MuteDisplay™, SpecDisplay™, and ExpertMeter™ are trademarks of ESCORT Inc. SWS™ is a trademark of SWS, L.C. Features, speciﬁcations and prices subject to change without notice.
Page 2: Quick Reference Card
“Mark” known speed traps, For the ultimate in Laser protection, the cameras and other places of interest. PASSPORT 9500ix can also be used in • Easy-to-use Preferences allow you to conjunction with our Laser Shifter product. customize up to 11 features.
Page 3: Passport 9500Ix Quick Reference Card
Quick Reference Card  Remove card along perforations  PASSPORT 9500ix Quick Reference Card Press the BRT button to go Press the MRK button from one category to change your setting to the next within a category Pilot HWY PILOT LIGHT...
Page 4: Radar Overview
Quick Reference Guide...
Page 5: Mounting Location
PASSPORT, and slide PASSPORT forward or backward to obtain a level position. Depress the adjustment button on the top of PASSPORT (by the word ESCORT) and slide the EasyMount bracket into the slot until it is locked into the position which best ﬁts the angle of your wind-...
Page 6: Auto Power
PASSPORT off if the vehicle has not moved for 4 hours. This is especially useful if your required to get the most out of your PASSPORT 9500ix. To receive satellite vehicle has a hot plug (12 volts all the time). See the Preferences section for details.
Page 7: Audible Alerts
Controls and Features Sensitivity Switch (SEN) visual alerts, (i.e. display or keypad) when The “SEN” button selects PASSPORT’s PASSPORT detects signals. Only the audible sensitivity mode. We recommend the Auto alert will tell you of detected signals. (AutoSensitivity) mode for most driving. In this mode, visual alerts can be seen In the “Auto”...
Page 8: Signal Strength Meter
Controls and Features Speed Alert ExpertMeter PASSPORT’s Speed Alert feature provides PASSPORT’s ExpertMeter option is an a visual indication of your vehicle speed advanced display for experienced during the ﬁrst few seconds of an alert. detector users. Please use PASSPORT for a This allows you to instantly check your few weeks to get familiar with its other speed without looking at your...
Page 9: Overview Of Preferences
How to use Preferences There are 11 user-selectable Preferences An example Here is how you would turn PASSPORT’s so you can customize your 9500ix for your speciﬁc driving needs. The buttons AutoMute feature oﬀ. labeled “MRK” and “BRT” are also used to Enter Preferences by holding both the enter Preferences, REVIEW your current MRK and BRT buttons down for 2 seconds.
Page 10: Speed Alert
Details of Preferences Pilot Light (Power-on indication) SpeedAlert PilotHWY sAlrt ON (Full word) In this setting, PASSPORT will display In this setting, your vehicle’s speed will be “Highway,” “Auto,” or “Auto NoX” as its displayed for a few seconds during an alert. power-on indication.
Page 11: Details Of Preferences
Details of Preferences Units BandsMOD Units ENG (Speed measured in In this setting, PASSPORT will warn you miles per hour) with an audible alert, and associated text In this setting, all speed related features message stating which band has been are displayed in miles per hour (MPH).
Page 12: Interpreting Alerts
Interpreting Alerts Although PASSPORT has a comprehensive (continuous or instant-on) and the location warning system and this handbook is as of the radar source affect the radar alerts complete as we can make it, only you receive. experience will teach you what to expect The following examples will give you from your PASSPORT and how to interpret an introduction to understanding...
Page 13 Radar How Radar Works Because intrusion alarms and motion Trafﬁc radar, which consists of sensors often operate on the same microwaves, travels in straight lines and is frequency as X, and K-band radar, your easily reﬂected by objects such as cars, PASSPORT will occasionally receive non- trucks, even guardrails and overpasses.
Page 14: How Speed Cameras Work
Speed Cameras How Speed Cameras Work How SWS Works There are several types of ﬁxed position Safety Warning System, or SWS, uses a speed cameras used, including radar, laser, modiﬁed K-band radar signal. The SWS induction loop and photo-based. safety radar system has 64 possible Radar and laser based cameras are messages (60 currently allocated).
Page 15: Software Updates
Out Of Warranty Repairs For out of warranty repairs, include prepayment in the amount you were quoted by the ESCORT Customer Service Representative. If the detector has been damaged, abused or modiﬁed, the repair cost will be calculated on a parts and labor basis.
Page 16: Troubleshooting
Troubleshooting Problem Solution PASSPORT beeps brieﬂy at the • An X-band motion sensor or intrusion alarm is located same location every day, but no within range of your route. Use the TrueLock feature to radar source is in sight. ﬁlter this signal out. PASSPORT does not seem sensitive •...
Page 17 Accessories Accessories ESCORT Extended Service Plan The following accessories and replacement ESCORT offers an optional extended parts are available for PASSPORT 9500ix. service plan. Contact ESCORT Sales for details at 800-433-3487. Coiled SmartCord ... $29.95 Straight SmartCord... $29.95 Available in red or blue Direct-wire SmartCord ...
Page 18: Limited Warranty
For how long: One (1) year from the date of the original purchase. What we will do: ESCORT, at our discre- tion, will either repair or replace your Product free of charge. What we will not do: ESCORT will not pay shipping charges that you incur for sending your product to us.
