OWNER'S
MANUAL
MODEL NO.
STARTING SERIAL #:
L115-294001
POL11544X
POL11544XEX
POL14544X
POL14544X-CA
POL14544XEX
RC11544BS
RC11544BSXP
RC14544BS
RC14544BS-CA
RC14544BSXP
IMPORTANT
IMPORTANT
Read and follow all
Read and follow all
Safety Precautions
Safety Precautions
and Instructions
and Instructions
before operating this
before operating this
equipment.
equipment.
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
17338 REV 15-294
44" ROUGH CUT
TRAIL CUTTER
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE (660) 747-8183 FAX (660) 747-8650
Made In The
USA
of US and Global Parts
Advertisement
Table of Contents
Related Manuals for Swisher POL11544X
Summary of Contents for Swisher POL11544X
- Page 1 OWNER’S MANUAL MODEL NO. STARTING SERIAL #: L115-294001 POL11544X POL11544XEX POL14544X POL14544X-CA POL14544XEX 44” ROUGH CUT RC11544BS RC11544BSXP TRAIL CUTTER RC14544BS RC14544BS-CA RC14544BSXP Assembly IMPORTANT IMPORTANT Operation Read and follow all Read and follow all Safety Precautions Safety Precautions...
- Page 2 Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.
-
Page 3: Safety Precautions
Thank you for choosing Swisher’s 44” Trail Cutter. Before operating your cutter, please read, understand and follow all of the safety precautions and other instructions explained in this manual. As with all power equipment, lawn mowers and cutters can be potentially dangerous if improperly used. - Page 4 • Turn off the blades when not cutting. Before leaving the machine, turn off the blades and stop the engine. • Watch for traffic when operating near or crossing roadways. • Do not operate the cutter if it has been dropped or damaged in any manner or if the mower vibrates excessively.
- Page 5 OPERATING YOUR TRAIL CUTTER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before starting any cutting machine and while operating such a machine. The operation of any mower produces sound waves that are damaging to the human ear.
- Page 6 Stop cutter. STARTING THE ENGINE See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Cutters equipped with an electric start engine will need a battery (sold separately). Swisher recommends using a standard “U1” battery. •...
- Page 7 When offsetting the cutter do so to the side opposite the discharge of the tow vehicle. • Swisher recommends if the tow vehicle is equipped with a mid-mount mower to overlap the cut approximately 6”. This may vary depending on mowing terrain, obstacles, and/or tow vehicle. Always keep safety the first priority.
-
Page 8: Cutter Maintenance
• Reducing the travel speed will help cut dense growth. This allows the blades the time necessary to make its initial cut, and regain momentum to continue cutting and discharging debris properly. The engine may stall if you are mowing too fast! •... -
Page 9: General Troubleshooting
GENERAL TROUBLESHOOTING The unit is not cutting level. • Level deck. Check air pressure of all tires; make sure they are equal. See tires for maximum inflation. • Without the engine running, make certain blades are installed identically. The engine will not start. •... -
Page 10: Safety And Operational Decals
SAFETY AND OPERATIONAL DECALS Replace decal immediately if damaged. Order by part number from Swisher. 1-800-222-8183, 8-5 CT M-F 19976-SWISHER FLAG DECAL OD82-44 RUGGED CUT DECAL OD33-5MPH DECAL OD29-DANGER DECAL OD36-DEFLECTOR DECAL OD55-DANGER DECAL OD10-ENGAGE DECAL OD45-WARNING DECAL OD99112 LARGE SWISHER LOGO... -
Page 11: Hitch Assembly
FRONT SKIRT ASSEMBLY FIGURE 1 Item # Description Part # Nut - Serr Flange, 1/4-20 Grade 5 ZY NB524 Rubber Flapper 10384 Washer - Fender, 1/4X1 1/4OD Gr 2 ZY 11520 Bolt - Serr Flange, 1/4-20 X 3/4 GR5 ZY NB690 HITCH ASSEMBLY FIGURE 2... - Page 12 MOTOR BASE, WHEEL & HEIGHT ADJUSTMENT ASSEMBLIES FIGURE 3 Item # Description Part # Item # Description Part # Nut - 5/16-18 Serrated Flange NB170 Washer - Nylon 1/4 NB194 Motor Base 10343* Nut, Push - 5/16 NB117 Knob Height Adjustment Cover - Rear, 12.5HP Model (Not Shown) 19073* Cover - Rear, 14.5HP Model (Shown)
-
Page 13: Deck Assembly
DECK ASSEMBLY Item # Description Part # FIGURE 4 Deck - Weldment 15727* Screw - .312-18 x .75 26X249 Side Gusset - Left 15056* Nut - 5/16-18 Serrated Flange NB170 Side Gusset - Right 15057* Z Bracket, Jack Support 15055* Front Rail/Deck Support 15054* Remote Cable Mount - Bolt On... - Page 14 BLADE DRIVER ASSEMBLY FIGURE 5 Item # Description Part # Nut - Nyloc 1"-8 NB612 Washer - 1" X 2" X 14GA NB738 Pulley - Blade, 10.3125" 4846 Spacer - Pulley 19822 Bearing - Blade 4845 Shaft - Blade 18844 NB281 Nut - Nyloc 1/2"-13 Washer - USS Flat, 1/2"...
- Page 15 ENGINE PULLEY ASSEMBLY FIGURE 6 Item # Description Part # Engine B&S NB253 5/16''-18 X 1 1/4'' Serrated Flange Bolt 5/16-18 Serrated Flange Nut NB170 Bolt - Serr Flange, 5/16-18 X1 3/4 ZY Gr5 NB515 Spacer For Engine Pulley BB105S 1/4'' X 1'' Key Stock 9031 Engine Pulley- 4.25"OD,1 1/4'' ID...
-
Page 16: Console Assembly
CONSOLE ASSEMBLY FIGURE 8 Item # Description Part # Item # Description Part # T Handle for Console 4463* 1/4 SAE Washer NB274 1/4-20 X 2 1/2 HCC GR2 ZP NB163 1/4-20 Nyloc Nut NB180 1/4-20 X 1 1/4 HCC GR5 ZP NB560 5/16-18 Nyloc Nut NB181... - Page 17 WIRING DIAGRAM, 11.5HP ENGINE FIGURE 9 19193 WIRING DIAGRAM, 14.5HP ENGINE FIGURE 10 10299...
- Page 18 ENGINE TO BLADE PULLEY CONFIGURATION FIGURE 11 P/N 4846 P/N B527 P/N BA50 P/N BB105 Notes...
- Page 19 REPAIR PARTS Your 44’’ Trailcutter has been produced with components designed specific to this machine. Although standard V-belts, springs, bearings, blades, pulleys, hardware, etc. look similar to parts used on other machinery, they may in some cases be made of a different construction and/or materials. Mowers equipped with a 14.5HP engine California compliant mowers are have a separate 2.5 gallon fuel tank.
- Page 20 RECOMMENDED HITCH CONFIGURATIONS AND POSITIONS...
- Page 22 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 23 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 24 All mower parts listed herein may be ordered directly from POL11544X Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the POL11544XEX engine supplied with your mower...
