Basic Specifications

Dimensions Width: 12.6 inches (319 mm)
Depth: 20 (508 mm)
Height: 5.4 inches (137 mm)
Weight 4.9 lb (2.2 kg)
Feeder type Face up loading, face down ejecting
Loading position Left side of paper against left side of feeder
Connector 8-pin DIN male
Temperature Operation: 50 to 90 °F (10 to 32 °C)
Storage: –4 to 140 °F (–20 to 60 °C)
Humidity Operation: 20% to 80%
(without Storage: 10% to 85%
condensation)
Operating Ordinary office or home conditions; avoid
conditions extreme dust, direct sunlight, and strong
light sources.
Reliability Load/eject: MCBF 20,000 sheets
Hinge: MCBF 12,000 cycles
Electrical Input voltage: DC 21.6 to 26.4 V
DC 4.75 to 5.25 V
Input current: 24 V: 0.8 A
5 V: 0.2 A

ADF Document Specifications

Feeder capacity 30 sheets of maximum weight 55 gm
paper, total thickness less than 0.24 inch
(6 mm)
Size Width: 3.3 to 8.5 inches (85 to 216 mm)
Length: 5 to 14 inches (127 to 356 mm)
Thickness 0.0028 to 0.0063 inch (0.07 to 0.16 mm)
Paper quality High-quality paper, bond paper, check
paper, recycled paper
Document type Documents printed with impact printers,
laser printers, or fax machines
Don't use the following paper types: transparencies,
film, coated paper, labels, carbon paper, or paper with
staples, holes, rips, curls, or folds.
  (3621 3HUIH.WLRQ 68

Using EPSON Smart Panel

Follow these steps to use EPSON Smart Panel to scan your
document or photo:
1. Place your original document(s) face down on the
document table.
2. Do one of the following to open the Smart Panel:
❏ Click the
Smart Panel icon on the Windows taskbar.
❏ Open the Apple menu and select
.
PANEL
If you have a modem
and e-mail service, you
can use your scanner
to send photos or
documents.
The control panel on
your computer
screen allows you
to make copies of
printed pages and
photos.
3. Click the icon for your desired scanning option. The
window for that option appears and lets you adjust settings
for your scan. Follow the on-screen steps for each option.
If you select Copy or Photo Print, make sure your
printer is turned on and the correct paper type and
size is loaded in your printer. You can use Photo
Print only with an EPSON Stylus
Stylus Photo printer.
For detailed instructions on using each of the Smart Panel
options, read your electronic manual for EPSON Smart Panel.

EPSON SMART
Optical character
recognition (OCR) converts
a scanned text image into
text that you can edit in a
word processing format.
Automatically scans
Automatically scans
your image and then
your image and
opens it in any
then opens it in
supported
PhotoDeluxe, which
application program
guides you through
on your computer.
steps to create a
print project—such
as a calendar, card,
label, or web page.
®
Color or EPSON
Gives you
an easy
way to
reprint
your
photos in
any size
you want.
