(3621 3HUIH.WLRQ 68
Color correction 1 type for CRT display
3 types for printer output
1 type for user-defined
Interface USB (Type B receptacle connector)
SCSI (High density 50-pin connector)
Light source White cold cathode fluorescent lamp
Reliability 30,000 cycles of carriage movements
(main unit MCBF)
Dimensions Width: 11.4 inches (289 mm)
Depth: 17.4 inches (442 mm)
Height: 3.8 inches (96 mm)
Weight Approx. 9.9 lb (4.5 kg)
Electrical
−
Specification 100 120 V model
Input voltage range AC 100 to 120 V ±10%
Rated frequency 50 to 60 Hz
Input frequency 49.5 to 60.5 Hz
Rated current 0.5 A
Power Approx. 25 W operating
consumption Approx. 10 W stand by
Note: Check the label on the back of the scanner for voltage
information.
Environmental
Temperature Operation: 41 to 95 °F (5 to 35 °C);
50 to 90 °F (10 to 32 °C) when using the
auto document feeder
Storage: –13 to 140 °F (–25 to 60 °C)
–4 to 140 °F (–20 to 60 °C) with the auto
document feeder
Humidity Operation: 10% to 80%; 20% to 80%
(without when using the auto document feeder
condensation) Storage: 10% to 85%
Operating Ordinary office or home conditions; avoid
conditions extreme dust, direct sunlight, and strong
light sources. Make sure the outlet
provides enough power.
Safety Approvals
120 V model
Safety standards UL 1950
CSA C22.2 No. 950
EMC FCC part 15 subpart B class B
  (3621 3HUIH.WLRQ 68
−
220 240 V model
AC 220 to 240 V ±10%
0.3 A
CSA C108.8 class B
230 V model
Safety standards EN 60950
EMC EN 55022 (CISPR Pub 22) class B
CE marking
230 V model Low Voltage Directive 73/23/EEC
EMC Directive 89/336/EEC

USB Interface

Interface type Universal Serial Bus Specification
Revision 1.1
Configuration
Element Description
Configuration Characteristics: Self-powered
Remote wake up feature: Not supported
Maximum power consumption from VBUS:
2mA (5V)
Interface No alternate setting
Number of endpoints used by this interface
(excluding endpoint 0): 2
Class: Vendor specific
Endpoint 1 Bulk IN transfer
Maximum data transfer size: 64 byte
Endpoint 2 Bulk OUT transfer
Maximum data transfer size: 64 byte
String Descriptor Language ID: US English
1: iManufacturer: "EPSON"
2: iProduct: "Perfection1640"
Electrical standard Full Speed mode (12Mbit/s) of
Universal Serial Bus Specification
Revision 1.1
Connector type One receptacle (Type B)
Connector pin arrangement
Pin number
1
2
3
4

AS/NZS 3548 class B
EN 60950
EN 55022 Class B
EN 61000-3-2
EN 61000-3-3
EN 500-24
Signal Connector
VCC
–
DATA
+DATA
GND
