- Page 1 WH-D8 & WH-D10 subwoofer WH-D8 WH-D10...
-
Page 2: Important Safety Information
USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER IMPORTANT SAFETY INFORMATION Unplug the apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any... -
Page 3: Installation
USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER INTRODUCTION The WH-D8 & WH-D10 is the latest in a long line of distinguished Wharfedale active subwoofers. These technologically advanced subwoofers will complement the finest electronics and decor. Please read these instructions carefully before installing your subwoofers. A few minutes studying this manual will ensure superb performance from your subwoofer for many years. - Page 4 USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER Before Connecting the Subwoofer • Level the subwoofer taking care to make sure it sits squarely on all its spikes. • Switch off you amplifier and all connected source units at the mains. •...
- Page 5 USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER CONNECTING THE SUBWOOFER TO THE SYSTEM Control Panel of the WH-D0 Subwoofer ① Power Indicator Auto Sense Switch ⑤ ② Volume Control Line Level Inputs ⑥ C r o s s o v e r F r e q u e n c y IEC Mains Input Socket ③...
- Page 6 USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER A/V Processor Connections Your subwoofer has been designed for optimum performance with a digital processor. If your A/V processor has a line level or LFE subwoofer output you should use this connection. You will need to purchase a single screened RCA phono lead from your dealer.
-
Page 7: Operating Your Subwoofer
Initial Settings Volume Control: Set the subwoofer volume control to the minimum before proceeding. Crossover Control: Adjust frequency to integrate WH-D8 or WH-D10 subwoofer with your system requirement. Phase Switch: The Phase switch should be initially set to 0°. Switching On Plug in the mains plug and switch the power on. -
Page 8: Troubleshooting
USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER TROUBLESHOOTING Before investigating a problem, always switch off the system at mains. If your system is not working properly please work through this checklist before returning a unit to your dealer. Possible Cause Symptom No Sound System not switched on;... - Page 9 USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER Subwoofer Maintenance Subwoofer should only ever be cleaned with a soft dry cloth to remove fingermarks, etc. Never touch subwoofer drive units as they can be damaged by improper handling. Never use a vacuum cleaner to clean a subwoofer grille. Brush it carefully by hand with a soft brush.
-
Page 10: Specifications
USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER Specifications WH-D8 WH-D10 Description/Format Active Dynamic-Drive IB subwoofer system Active Dynamic-Drive IB subwoofer system Drive Units 1 x (8")200mm cone long-throw 1 x (10")250mm cone long-throw Frequency Response 40 - 120Hz ±3dB 35 - 150Hz ±3dB... - Page 11 USER INSTRUCTIONS: WH-D8 & WH-D10 SUBWOOFER...
- Page 12 IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK Tel: +44(0)1480 452561 Fax: +44(0)1480 413403 http://www.wharfedale.co.uk IAG reserves the right to alter the design and specifications without notice. All rights reserved IAG Group Ltd. Wharfedale is a member of the International Audio Group. CODE: WH14-MNL006a...
