Instructions for
Installation and Use
GB
GB
GB
GB
GB
English, 2
DDD 5340 C
DDD 5340 C
DDD 5340 C
DDD 5340 C
KDD 3340
KDD 3340
KDD 3340
KDD 3340
IDD 6340
IDD 6340
IDD 6340
Contents
Introduction, 3-4
Installation, 5
Features, 8-9
Controls, 10-11
Multifunction Selector Switch
Convection Oven, 19
Top Oven Temperature Charts, 21-22
Main Oven - Fan Grilling
Main Oven Temperature Chart, 30-31
Care and Cleaning, 33-35
You must read these instructions prior to using
your appliance and retain them for future use.
Electric built-in
double oven
, 12
GB
, 23
Advertisement
Table of Contents
Related Manuals for Indesit DDD 5340 C
Summary of Contents for Indesit DDD 5340 C
-
Page 1: Table Of Contents
Convection Oven, 19 Top Oven Cookery Notes, 20 Top Oven Temperature Charts, 21-22 Main Oven - Fan Grilling DDD 5340 C KDD 3340 , 23 Main Oven - Fan Grilling Roasting Chart , 24 Using the Main Oven for Other Functions, 25... -
Page 2: Safety Information
Safety Information • During use the appliance becomes • WARNING: The appliance and its hot. Care should be taken to avoid accessible parts become hot touching heating elements inside the during use. oven. • Care should be taken to avoid •... -
Page 3: Introduction
Top Oven To help make best use of your cooking equipment, DDD 5340 C please read this booklet carefully. Usable Volume: 42Litres KDD 3340 The cooker is designed specifically for domestic use... - Page 4 For Your Safety 3. LEAVE THE PAN TO COOL FOR AT LEAST 60 When used properly your appliance is completely MINUTES BEFORE MOVING IT. Injuries are often safe but as with any electrical product there are caused by picking up a hot pan and rushing certain precautions that must be observed.
-
Page 5: Installation
Installation Electrical Requirements Important For your own safety, we recommend that your cooker It is essential that the lower cupboard is constructed in is installed by a competent person such as one who the manner illustrated i.e. having side, back, and roof is registered with NICEIC (National Inspection panels so joined as to provide no apertures which Council for Electrical Installation Contracting). -
Page 6: Tall Cabinet Ventilation
Tall Cabinet Ventilation Fig. 1 Ventilation Slot required here if cabinet does not fit to ceiling - 51mm x 457mm min. area Ventilation Slot required here if the cabinet does not fit to the ceiling - 51mm x 457mm min. 50 mm area Air Gap... - Page 7 562mm Viewed down through cabinet Cabinet No. 6x25mm screw (4 supplied) Fig. 3 870mm Oven Door Fig. 2 882mm, 870mm if cooker trim is to overlap Connector top edge of shelf Cable if hob fitted Cable to Hob if if fitted Cable Fig.
- Page 8 Features IDD 6340 IDD 6340 IDD 6340 WARNING: DO NOT TOUCH THE GLASS DOORS WHEN THE OVEN IS IN USE AS THESE AREAS CAN BECOME HOT. TOP OVEN TEMPERATURE CONTROL MAIN OVEN TEMPERATURE & FUNCTION CONTROL TOP OVEN/GRILL TOP OVEN PILOT LIGHT THERMOSTAT MAIN OVEN THERMOSTAT LIGHT...
-
Page 9: Features
Features DDD 5340 C DDD 5340 C DDD 5340 C KDD 3340 KDD 3340 KDD 3340 WARNING: DO NOT TOUCH THE GLASS DOORS WHEN THE OVEN IS IN USE AS THESE AREAS CAN BECOME HOT. TOP OVEN MAIN OVEN TEMPERATURE... -
Page 10: Controls
Controls IDD 6340 IDD 6340 IDD 6340 A GRILL SETTING CONTROL MAIN OVEN TOP OVEN THERMOSTAT LIGHT TIMER THERMOSTAT LIGHT TOP OVEN/GRILL PILOT LIGHT B TOP OVEN TEMPERATURE C MAIN OVEN TEMPERATURE CONTROL AND FUNCTION CONTROL Control Description Function Knob Selects the heat at which the grill will cook the food. - Page 11 Controls DDD 5340 C DDD 5340 C DDD 5340 C KDD 3340 KDD 3340 KDD 3340 TOP OVEN MAIN OVEN THERMOSTAT THERMOSTAT TIMER LIGHT LIGHT TOP OVEN/GRILL PILOT LIGHT D MULTIFUNCTION B TOP OVEN TEMPERATURE SELECTOR CONTROL C MAIN OVEN TEMPERATURE...
-
Page 12: Multifunction Selector Switch
Multifunction Selector Switch DDD 5340 C DDD 5340 C DDD 5340 C KDD 3340 KDD 3340 KDD 3340 The Multifunction selector switch is used when Light Only operating the main oven. This function switches on the oven light only. With the exception of the O position the main... -
Page 13: The Electronic Programmer
The electronic programmer Programming cooking ! A cooking mode must be selected before DISPLAY programming can take place. •• •• END OF CLOCK icon Programming the cooking duration COOKING icon DURATION TIMER icon 1. Press the button several times until the icon icon and the three digits on the DISPLAY begin to flash. -
Page 14: Grill Pan And Handle
Grill Pan and Handle Using the grill pan kit Top Oven Shelf Positioning for Grilling The grill pan handle is detachable from the pan to facilitate cleaning and storage. Fix the pan handle ENSURE SHELVES ARE securely before use: FITTED CORRECT WAY UP. 1. -
Page 15: Operation When Using The Top Oven For Grilling
Operation when using the Top Oven for Grilling IDD 6340 IDD 6340 IDD 6340 A GRILL SETTING CONTROL TOP OVEN THERMOSTAT TIMER LIGHT TOP OVEN/GRILL PILOT LIGHT B TOP OVEN TEMPERATURE CONTROL Ensure that the timer is set to manual. Step 1 Place the grill pan runner/support in the Step 2... -
Page 16: Conventional Grilling
Conventional Grilling Food which requires browning only should be placed CAUTION - ACCESSIBLE PARTS MAY BECOME under the hot grill, directly on the shelf in the first or HOT WHEN THE GRILL IS IN USE. second runner from the bottom of the oven, CHILDREN SHOULD BE KEPT AWAY. -
Page 17: Operation When Using The Top Oven For Grilling
Operation when using the Top Oven for Grilling KDD 3340 KDD 3340 KDD 3340 DDD 5340 C DDD 5340 C DDD 5340 C A GRILL SETTING CONTROL TOP OVEN THERMOSTAT TIMER LIGHT TOP OVEN/GRILL PILOT LIGHT B TOP OVEN TEMPERATURE CONTROL Ensure that the timer is set to manual. -
Page 18: Using The Top Oven As A Convection Oven
Using the Top Oven as a Convection Oven The top oven should be used to cook small quantities of food. The oven is designed so that the grill element operates at a reduced heat output, this is combined with a heating element situated underneath the floor of the oven. -
Page 19: Operation When Using The Top Oven As A Convection Oven
Operation when using the Top Oven as a Convection Oven A GRILL SETTING CONTROL TOP OVEN THERMOSTAT TIMER LIGHT TOP OVEN/GRILL PILOT LIGHT B TOP OVEN TEMPERATURE CONTROL Ensure that the timer is set to manual. Step 1 Place the shelf in the correct position (see Step 2 Oven Temperature Charts). -
Page 20: Top Oven Cookery Notes
Top Oven Cookery Notes PLATE WARMING Place the plates/dishes on shelf position 1 from the base of the top oven, and turn top oven temperature control (B) to 100°C for 10-15 minutes. Never use the grill setting control (A) when warming plates. -
Page 21: Top Oven Temperature Charts
Oven Temperature Charts - Baking Top Oven Cooking Baking Pre-heat Temperature °C Time in mins. Position in Oven Scones 210/220 10-15 Runner 2 from bottom of oven Small Cakes 180/190 20-25 Runner 2 from bottom of oven Victoria Sandwich 170/180 20-30 Runner 2 from bottom of oven Sponge Sandwich (fatless) - Page 22 Oven Temperature Charts - Meat Top Oven Cooking Meat Pre-heat Temperature °C Time (approx.) Position in Oven Beef/ Lamb 170/180 35 mins per 450g (1lb) + 35 mins over. (slow roasting) Beef/ Lamb 190/200 35-40 mins per 450g (1lb) (foil covered) Pork 170/180 40 mins per 450g (1lb) + 40 mins over...
-
Page 23: Ddd 5340 Ckdd 3340
Main Oven - Fan Grilling KDD 3340 KDD 3340 KDD 3340 DDD 5340 C DDD 5340 C DDD 5340 C Fan grilling is a combination of heat from the grill General Recommendations element and the oven fan circulating the hot air Most types of meat and poultry cooked by this around the food. -
Page 24: Main Oven - Fan Grilling Roasting Chart
Main Oven - Fan Grilling Roasting Chart KDD 3340 KDD 3340 KDD 3340 DDD 5340 C DDD 5340 C DDD 5340 C Shelf positions are counted from the base upwards ie: lowest shelf position is 1. Weight Time Plus Extra... -
Page 25: Using The Main Oven For Other Functions
Control C - Model IDD 6340 It is very important to strictly adhere to the Control D - Model DDD 5340 C basic principles of food handling and hygiene KDD 3340 to prevent the possibility of bacterial growth. This defrosts by circulating the air around the food, time to defrost will depend on type and size of the food. -
Page 26: Main Oven - Convention Oven
Main Oven - Convention Oven DDD 5340 C KDD 3340 KDD 3340 KDD 3340 DDD 5340 C DDD 5340 C Important NEVER line the shelves, the floor or the sides of the oven with aluminium foil as overheating and damage may result. -
Page 27: Main Oven - Fan Oven (All Models)
This light will then automatically cycle on and off during cooking as the oven temperature is controlled. 4. After use always return both controls to the off position and close the oven door. DDD 5340 C KDD 3340 IDD 6340... -
Page 28: Main Oven - Fan Oven Cookery Notes
Main Oven - Fan Oven Cookery Notes Since a fan oven heats up more quickly, and It should be noted that at the end of a cooking generally cooks food at a lower temperature than a period there may be a momentary puff of steam conventional oven, pre-heating the oven is often when the oven door is opened, this will disperse in a unnecessary. - Page 29 Main Oven - Fan Oven Cookery Notes Temperature and Time Frozen Meat and Poultry The oven is provided with two shelves. A third is Joints of meat and whole birds should be defrosted available as an optional extra, contact Genuine Parts slowly, preferably in a domestic refrigerator (allowing and Accessories Hotline (see back page) for further 5-6 hours per 450g,1 lb), or at room temperature...
-
Page 30: Main Oven Temperature Chart
Main Oven Temperature Chart DDD 5340 C KDD 3340 Conventional Oven It is not necessary to pre-heat the fan oven before roasting. Note: Where times are stated, they are approximate only. Meat Pre-heat Temperature °C Time (approx.) Position in Oven... - Page 31 Main Oven Temperature Chart DDD 5340 C KDD 3340 Baking Conventional Oven Food Pre-heat Temperature °C Time in mins. Shelf Position Scones 220/230 10-15 2nd from bottom Small Cakes 180/190 15-25 3nd from bottom Victoria Sandwich 160/170 20-30 3nd from bottom...
-
Page 32: Main Oven Grilling
Main Oven Grilling DDD 5340 C KDD 3340 DO NOT allow young children near the appliance Grilling Procedure: 1. Open the main oven door fully and position the rod when the grill is in use as the surfaces can get extremely hot. -
Page 33: Care And Cleaning
Care and Cleaning It should not normally be necessary to clean the Warning: Before cleaning, please ensure that the electricity supply to the appliance is switched off panels with water. If the user feels it is desirable to do so, wipe them over with a clean, soapy cloth, and the appliance is fully cold. - Page 34 Care and Cleaning 3. OVEN DOORS 5. HOW TO CLEAN THE LAMP LENS CONTROL PANEL TOP OVEN LAMP (not all models) OVEN DOORS MAIN OVEN LAMP Warning: To avoid electric shocks - please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold, before cleaning lamp lens.
- Page 35 Care and Cleaning Take particular care not to damage the inner Respecting and conserving the surface of the door inner glass that is coated with environment a heat reflective layer. Do not use scouring pads, • Whenever possible, avoid pre-heating the oven or abrasive powder, which will scratch the glass.
-
Page 36: If Something Goes Wrong
If Something Goes Wrong? Before calling a Service Engineer, please check through the following lists. THERE MAY BE NOTHING WRONG. Problem Check Slight odour or small amount of smoke when grill / oven used for This is normal and should cease after a short period. first time If you find that the timer display is blank, then it is likely that there is no electricity supply to your oven. -
Page 37: If It Still Won't Work/ Disposal Of The Appliance
If it Still Won't Work Contact the Service Office Disposal of your product To minimise the risk of injury to children please If something is still wrong with your appliance after dispose of your product carefully and safely. you have been through the 'Something Wrong' list: Remove all doors and lids. -
Page 38: Guarantee Information
Product Guarantee and Repair Information Guarantee Recycling and Disposal Information 12 Months Parts and Labour Guarantee As part of Hotpoint’s continued commitment to helping the environment, Hotpoint reserves the right to use quality, recycled components to keep down Your appliance has benefit of our manufacturer’s guarantee, which covers customer costs and minimise material wastage. - Page 40 07/2016 - 195149258.00 XEROX FABRIANO Indesit Company S.P.A. Viale Aristide Merloni,47 60044 Fabriano (AN) www.indesit.com...
