  • Page 1 P40w-20 WUHD Curved Panel Monitor User’s Guide Machine Type: 62C1...
  • Page 2 All rights reserved. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 47 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.

  • Page 3: Table Of Contents

    Appendix A. Important safety information .................. A-1 Safety information ................................A-1 General Safety guidelines ............................A-1 Maintenance ..................................A-2 Appendix B. Comfort and accessibility ...................B-1 Arranging your work area ..............................B-1 Positioning your monitor ..............................B-2 © Copyright Lenovo 2021...
  • Page 4 Service information ..............................C-4 Appendix D. Compliance information ................... D-1 Recycling information ................................. D-1 Collecting and recycling a disused Lenovo computer or monitor ................D-1 Disposing of Lenovo computer components ......................D-1 Turkish statement of compliance ............................D-2 Ukraine RoHS ..................................D-2 India RoHS ...................................

  • Page 5: Chapter 1. Get Started With Your Monitor

    P40w-20 Curved Panel Monitor. For a quick overview, ® please see the Setup Poster that was shipped with your monitor. ThinkVision P40w-20 supports Lenovo Display Control Center - ThinkColour. In the box The product package should include the following items: Information Flyer ...

  • Page 6: Notice For Use

    Notice for use To setup your monitor, please see the illustrations below. Note: Do not touch the monitor within the screen area. The screen area is glass and can be damaged by rough handling or excessive pressure. 1. Take out the Top cushion and accessories. 2.

  • Page 7: Set Up The Monitor

    Set up the monitor This section provides information to help you set up your monitor. Connecting and turning on your monitor Note: Be sure to read the Safety Information located in the Flyer before carrying out this procedure. 1. Power off your computer and all attached devices, and unplug the computer power cord. 2.
  • Page 8 Input Connectors (Front view): 1 x Audio Out 1 x USB 3.2 Gen1 Type-A (downstream) 1 x USB 3.2 Gen. 1 Type-C (data only downstream with 27W PD output) – for charging phone, USB SPK…etc. 1-4 P40w-20 Curved Panel Monitor User’s Guide...
  • Page 9 4. Connect one end of the HDMI 2.0 cable to the HDMI connector on the back of the computer, and the other end to the HDMI connector on the monitor. Lenovo recommends that customers who require to use the HDMI input on their monitor purchase the “Lenovo HDMI to HDMI cable OB47070”.
  • Page 10 5. Connect one end of the USB cable to the USB downstream terminal of the monitor, and connect the other end of the USB cable to an appropriate USB port on your device. Note: 1. The USB downstream port does not provide power while the monitor is switched off. 2.
  • Page 11 6. Connect the speaker’s audio cable and audio jack of monitor to transfer audio source from DP, Thunderbolt™ or HDMI. Note 1: The audio output in DP, Thunderbolt™ and HDMI modes. Note 2: Excessive sound pressure from ear-/headphones can cause hearing damage/hearing loss. 7.
  • Page 12 8. Connect one end of the Thunderbolt™ 4 cable to the Thunderbolt™ connector of the computer, and the other end to the Thunderbolt™ connector on the monitor. For more information, go to the following: www.lenovo.com/support/monitor accessories Note 1: P40w-20 monitor supports Thunderbolt™ 4.

  • Page 13: Pbp

    The PbP (Picture-by-Picture) function make the monitor to display two different video sources simultaneously. User can select any one of 3 inputs (DP, HDMI, Thunderbolt) for the left screen, select another input for the right one. For example, the left screen PC1 could be input of DisplayPort, HDMI or Thunderbolt notebook, the right screen PC2 would be rest input.

  • Page 14: Daisy Chain

    Daisy Chain This daisy chain is only available for Thunderbolt PC. The 2 monitor could be Thunderbolt (P40w-20) or USB-C (i.e. ThinkVision P27h-20, T27h-20). The Thunderbolt out of 1st monitor could connect other type Thunderbolt device (i.e. SSD), not limit to monitor.

  • Page 15: True Split

    True Split True Split is called hardware partition, it can use one cable to get two independent displays. Step 1 Connect your PC to monitor thru the Thunderbolt or DisplayPort. Step 2 Enable True Split in OSD. Step 3 Press Win +P to select Extend mode in Windows 10.
  • Page 16 Supported Notebook Left sub-screen Right sub-screen setting USB Speed Thunderbolt 4 DP 1.4 2560x2160@60hz 2560x2160@60hz USB 3.2 Gen 1 DP 1.4 2560x2160@60hz 2560x2160@60hz USB 3.2 Gen 1 Thunderbolt 3 (Alt Mode DP 1.4) DP 1.2 2560x2048@60hz 2560x2048@60hz USB 3.2 Gen 1 DP 1.4 2560x2160@60hz 2560x2160@30hz USB 3.2 Gen 1 Thunderbolt 3...

  • Page 17: Ekvm & Kvm

    eKVM & KVM Built-In KVM Switch give user to operate two PC which connecting USB Type-B and Type-C upstream ports, also user can use USB keyboard or USB mouse to reach the same function, called eKVM. How to enable KVM and/or eKVM Option 1 The hotkey of KVM locate on the specific button of front bezel.
  • Page 18 Option 2 Keyboard hotkey: double click ‘Shift’ function key in 0.5s. Option 3 Mouse hotkey: press and hold 3s of left & right button of mouse. Mouse or Keyboard must be plug on specific USB port on the back for option 2 or 3. ...
  • Page 19 After operating option 2 or option 3, the OSD pops up. The USB devices will be switched to another  upstream port after OSD disappears, else manually press the “Menu key” to switch immediately. While operating option 2 or option 3, and if the USB device is working on data transferring, the port ...

  • Page 20: Network

    Network This monitor can support two PC access Ethernet simultaneously by one LAN port (RJ45). One of the PC connect network thru USB-B port of monitor by USB A-B cable, another PC connect network thru Thunderbolt port. Rather than regular Ethernet, it support Intel vPro managed network on Thunderbolt port. * vPro function support by selected ThinkPad models with Intel CPU Gen 11 Tiger Lake platform.

  • Page 21: Audio Smart Switch (Earphone Plug & Play)

    Audio Smart Switch (Earphone Plug & Play) When plug the earphone onto audio jack of monitor, the PC will delivery the audio signal to monitor automatically. When plug off the earphone, the PC will not delivery the audio signal to monitor, it will delivery to other speakers connecting to PC.

  • Page 22: Best Resolution

    Best Resolution To get the best experience, suggest setting below resolution for your PC. Monitor OSD setting HDMI 1.4 HDMI 2.0 HDMI 2.0 5K HDMI 1.4 2560x1600@60hz 2560x1600@60hz 2560x1600@60hz HDMI 2.0 2560x1600@60hz 4096x2160@60hz 5120x2160@50hz Monitor OSD setting DP 1.2 DP 1.4 DP 1.2 4096x2160@60hz 5120x2160@50hz...
  • Page 23 Monitor OSD setting Supported USB Speed DP 1.2 DP 1.4 Thunderbolt 4 4096x2160@60hz 5120x2160@60hz USB 3.2 Gen 1 Thunderbolt 3 4096x2160@60hz 5120x2160@60hz USB 3.2 Gen 1 (Alt Mode DP 1.4) Thunderbolt 3 4096x2160@60hz 5120x2160@50hz USB 3.2 Gen 1 (Alt Mode DP 1.2) USB-C Gen 1 4096x2160@60hz 5120x2160@50hz...

  • Page 24: Registering Your Option

    Please take a few moments to register your product ® and provide us with information that will help Lenovo to better serve you in the future. Your feedback is valuable to us in developing products and services that are important to you, as well as in developing better ways to communicate with you.

  • Page 25: Product Overview

    Product overview This section will provide information on adjusting monitor positions, setting user controls, and using the cable lock slot. Types of adjustments Tilt Please see the illustration below for an example of the tilt range. Swivel With the built-in pedestal, you can tilt and swivel the monitor for the most comfortable viewing angle. Height Adjustment After pressing the top of the monitor, you can adjust the height of the monitor.

  • Page 26: User Controls

    User controls Your monitor has controls at the right side which are used to adjust the display. For information on how to use these controls, please see “Explore your monitor” on page 2-1. Cable lock slot Your monitor is equipped with a cable lock slot located on the rear of your monitor. Please follow the instructions that came with the cable lock to attach it.

  • Page 27: Features And Specs

    Features and specs Table 1-23. Monitor specifications Dimensions Height 641.23 mm (25.24 in.) Depth 279.46 mm (11.0 in.) Width 947.61 mm (37.30 in.) Tilt range Range: -5°/+22° Stand Swivel Range: -45°/+45° Lift Range: 130mm Pivot Supported (GS&UL Approved) 100 mm x 100 mm VESA mount (3.94 in.
  • Page 28 Video input (Thunderbolt™) Input signal Thunderbolt™ Horizontal addressability 5120 pixels (max) Vertical addressability 2160 lines (max) Clock frequency 742.5 MHz Communications VESA DDC /CI Altitude Test Operation 5000 m (16404 ft.) Supported Display Modes Horizontal frequency 30 kHz – 170 kHz (VESA Standard modes Vertical frequency 50 Hz –...

  • Page 29: Chapter 2. Explore Your Monitor

    Chapter 2. Explore your monitor This section describes the user control features used to adjust your monitor image. Quick access controls The direct access controls can be used when the On Screen Display (OSD) is not displayed. Table 2-1 Direct access controls No.

  • Page 30: Osd Controls

    OSD controls The settings adjustable with the user controls are viewed through the On-Screen Display (OSD), as shown below. To use the controls: Press to open the main OSD menu. to move among the icons. Select an icon and press to access that function.
  • Page 31 Table 2-3 OSD functions OSD Icon on Controls and Submenu Description Adjustments Main Menu Brightness Adjusts overall screen brightness Adjusts difference between light and dark Monitor Controls Contrast areas. Enable dynamic contrast ratio. Dynamic Contrast    Over Drive Normal ...
  • Page 32 OSD Icon on Controls and Submenu Description Adjustments Main Menu  USB-B Port   Thunderbolt Port Ethernet   vPro   True Split  PIP/PBP PIP/PBP/Off Swap input source of PIP/PBP Swap (only active after PxP On) PIP/PBP Left/Right PBP Source (only active after PBP On)

  • Page 33: Maximum Resolutions

    Maximum resolutions The display mode the monitor uses is controlled by the computer. Therefore, refer to your computer documentation for details on how to change display modes. The image size, position and shape might change when the display mode changes. This is normal and the image can be readjusted using automatic image setup and the image controls.

  • Page 34: Driver (Optional)

    Note: On LCD monitors, unlike CRTs, a faster refresh rate does not improve display quality. Lenovo recommends using either 5120 x 2160 at a refresh rate of 60 Hz, or 640 x 480 at a refresh rate of 60 Hz.

  • Page 35: Understanding Power Management

    Understanding power management Power management is invoked when the computer recognizes that you have not using your mouse or keyboard for a user-definable period. There are several states as described in the table below. For optimal performance, switch off your monitor at the end of each working day, or whenever you expect to leave it unused for long periods during the day.

  • Page 36: Detaching The Monitor Stand

    Detaching the monitor stand 1.Place the monitor face down in the original packing. 2. Push up the release button of the stand and remove the stand from monitor. Wall Mounting (Optional) Refer to the instructions that come with the VESA compatible base mounting kit. Place the monitor face down in the original packing.

  • Page 37: Chapter 3. Troubleshooting

    Chapter 3. Troubleshooting If you have a problem setting up or using your monitor, you might be able to solve it yourself. Before calling your dealer or Lenovo, try the suggested actions that are appropriate to your problem. Table 3-1. Troubleshooting...
  • Page 38 Table 3-1. Troubleshooting(continued) Problem Possible cause Suggested action Reference Screen is blank and The monitor is in Press any key on the “Understanding power  power indicator is Standby/Suspend keyboard or move the management” on page steady amber or mode mouse to restore operation.

  • Page 39: Appendix A. Important Safety Information

    General Safety guidelines For tips to help you use your computer safety, go to: http://www.lenovo.com/safety Before installing this product, read the Safety Information. This equipment is not suitable for use in locations where children are likely to be present, avoid hurting your child when machine falling down.

  • Page 40: Maintenance

    ■ Do not open your monitor cabinet or attempt to service this product yourself. If your monitor is not operating properly or has been dropped or damaged, contact your Lenovo authorized dealer, reseller, or service provider. ■ Adjust only those controls that are described in the operating instructions.

  • Page 41: Appendix B. Comfort And Accessibility

    Appendix B. Comfort and accessibility This section will give you information on adjusting and using your monitor. Good ergonomic practice is important to get the most from your personal computer and to avoid discomfort. Arrange your workplace and the equipment you use to suit your individual needs and the kind of work that you perform.

  • Page 42: Positioning Your Monitor

    Positioning your monitor Prolong exposure to computer screens may cause temporary visual fatigue. Factors including working environment, working habit and posture, screen flicker and blue light contribute to this condition. To minimize visual fatigue certain adjustments can be made on the work stations or using suitable computer screens with features that alleviate eye strain.

  • Page 43: Tips For Healthy Work Habits

    Tips for healthy work habits Long exposures to computer screens may cause eye strain. Symptoms include headache, burning eyes, blurred vision and discomfort. To minimize eye strain, computer users can adjust working habits to let their eyes relax and recover. Break Times ...

  • Page 44: Low Blue Light

    The monitors achieve the requirement of Low blue Light (Hardware Solution). Accessibility information Lenovo is committed to providing greater access to information and technology to people with disabilities. With assistive technologies, users can access information in the way most appropriate to their disability. Some of these technologies are already provided in your operating system;...

  • Page 45: Appendix C. Service And Support

    In addition, if your option is installed in a Lenovo computer, you might be entitled to service at your location. Your technical support representative can help you determine the best alternative.
  • Page 46 Warranty service and support: +358-800-1-4260(Finnish) France Warranty service and support (hardware): 0810-631-213(French) Germany Warranty service and support: 0800-500-4618 (toll-free)(German) Greece Lenovo Business Partner (Greek) Guatemala Dial 999-9190, wait for operator, and request to reach 877-404-9661 (Spanish) Honduras Dial 800-0123(Spanish) Hungary...
  • Page 47 020-513-3939 (Dutch) New Zealand 0508-770-506 (English ) Nicaragua 001-800-220-2282 (Spanish) Norway 8152-1550(Norwegian) Panama Lenovo Customer Support Center: 001-866-434(Toll-Free)(Spanish) Peru 0-800-50-866 (OPCION 2) (Spanish) Philippines 1-800-8908-6454 (GLOBE subscribers) 1-800-1441-0719 (PLDT subscribers) (Tagalog, English) Poland Laptops and tablets branded with logo Think: 48-22-273-9777...

  • Page 48: Service Information

    Customer Support Centre, please see Appendix C, “Service and support ” on page C-1. Service parts The following parts are for use by Lenovo service, or Lenovo authorized dealers to support the customer warranty. Parts are for service use only. The table below shows information for model 61C1-GAR6-WW.

  • Page 49: Appendix D. Compliance Information

    Collecting and recycling a disused Lenovo computer or monitor If you are a company employee and need to dispose of a Lenovo computer or monitor that is the property of the company, you must do so in accordance with the Law for Promotion of Effective Utilization of Resources.

  • Page 50: Turkish Statement Of Compliance

    The Lenovo product meets the requirements of the Republic of Turkey Directive on the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (EEE). Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other countries, or both. Ukraine RoHS India RoHS RoHS compliant as per E-Waste (Management &...

  • Page 51: Tco Certified

    TCO Certified D-3 P40w-20 Curved Panel Monitor User’s Guide...
  • Page 52 Appendix D Compliance information D-4...
  • Page 53 Energy Star is an energy saving program for consumer electronics led by the U.S. government. It was launched in 1992 by EPA and DOE to reduce energy consumption and greenhouse gas emissions. Energy Star logo is a symbol of energy conservation and environmental protection.

  • Page 54: Appendix E. Notices And Trademarks

    Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk.

  • Page 55: Trademarks

    Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo The Lenovo logo ThinkCentre ThinkPad ThinkVision Microsoft, Windows, and Windows NT are trademarks of the Microsoft group of companies. Other company, product, or service names may be trademarks or service marks of others.
