OUTDOOR FIRE PIT TABLE
ITEM: 96113
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST

Advertisement

Table of Contents
loading

Related Manuals for Barton 96113

Summary of Contents for Barton 96113

  • Page 1 OUTDOOR FIRE PIT TABLE ITEM: 96113 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in fire and/or serious injury. Save all warnings and instructions for future reference. SAFETY WARNING DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as owner’s manuals, service manuals or instruction sheets supplied with this product or optional equipment.
  • Page 3 IMPORTANT SAFETY INFORMATION FOR OUTDOOR USE ONLY. Never use inside house, or other unventilated or enclosed areas. This fire pit consumes air (oxygen). Do not use in unventilated or enclosed areas to avoid endangering your life. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 4 FEATURES DESCRIPTION This antique bronze fire pit is ideal for heating and keeping warm in yard, deck, and patio. It has solid steel construction with bronze finish for incredibly durable and rustic decorated look that suits outdoor living as well as serves as an outdoor wine table. It is hammered bronze finish for fitting outdoor wooden or wicker patio furniture.

  • Page 5: Parts List

    PARTS LIST Icluded Hardware...
  • Page 6 ASSEMBLY 1. Attach the back panel (G) with leg (J) using four M6x12 screws (AA). Repeat for left panel (H) and Right panel (I). 2. Attach the two pieces of cylinder plate tubes (O) with the left/right side panels using eight M6x12 screws (AA)
  • Page 7 ASSEMBLY 3. Disassemble the M8x25 screw from the cylinder fixed bracket (P), attach it to the cylinder plate (N) using three M6x12 screws (AA) and a M6 nut (DD). Then attach the plate to the bracket with four M6x12 screws (AA).
  • Page 8 ASSEMBLY 5. Attach the front door (M) to the legs using four M6x12 screws (AA). 6. Attach the connector II (E) to the legs using two M6x12 screws (AA), repeat with the other three pieces.
  • Page 9 ASSEMBLY 7. Attach the connector I (C) to the table (D) with one M6x12 screw (AA). Repeat with the other three table parts. Attach the four tables using four M6x12 screws (AA). 8. Attach the table to connect II (E) using eight M6x12 screws (AA) and M6 nut (DD).
  • Page 10 ASSEMBLY 9. Attach the connector III (F) to the table and legs with three M6x12 screws (AA), repeat with the other three parts. 10. Attach the burner (B) to the table with four M6x12 screws (BB) and four M6 nuts (DD).
  • Page 11 ASSEMBLY 11. Attach the knob (L) to the lid (A) with one M4x6 screw (EE) and one washer (CC). Put the lid on. 10. Connect the hose and regulator to the cylinder. The propane and cylinder are sold separately. Use a standard 20lb propane tank only.
  • Page 12 ASSEMBLY A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a propane cylinder with a damaged valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the US Department of Transportation (DOT) or the standard for cylinders, spheres and tubes for transportation of dangerous goods and commission, CAN/CSA-B339.

  • Page 13: Operation

    OPERATION CHECKING FOR LEAKS 1. Make 2-3oz of leak check solution (One part Dish washing liquid and three parts water. 2. Apply several drops of solution where the hose attaches to the regulator. 3. Apply several drops of solution where regulator attaches to the cylinder. 4.

  • Page 14: Operation And Maintenance

    OPERATION and MAINTENANCE WHEN THE FIRE PIT IS ON: The burner will display tongues of blue and yellow flame. These flames should not be yellow or produce thick black smoke, indicating an obstruction of airflow through the burners, The flame should be blue with straight yellow tops.

  • Page 15: Troubleshooting And Warranty

    TROUBLESHOOTING and WARRANTY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
