SHDVR-04
SHDVR-08
SHDVR-16
H.264 Network DVR
GUI Display with USB Mouse Control
1.
GUI DISPLAY WITH USB MOUSE CONTROL
1.1
Connect USB Mouse
1.2
Quick Menu Bar
1.3
Main Menu
2.
FRONT AND REAR PANELS
2.1
Front Panel
2.2
Rear Panel
3.
BASIC OPERATION
3.1
Live Page
3.2
Record Icon
3.3
Playback
3.4
User Level Switch
3.5
VGA Output Resolution Support
3.6
System Sources Reallocation
4.
REMOTE SURVEILLANCE
5.
PACKAGE CONTENTS
6.
SECURITY CAMERAS
Please read instructions thoroughly before operation and retain it for future reference.
For the actual display & operation, please refer to your DVR in hand.
Copyright © 2011
Quick Setup Guide
QSG_V1.2_R201201-V05
Advertisement
Table of Contents
Related Manuals for Sentry SHDVR-04
Summary of Contents for Sentry SHDVR-04
- Page 1 SHDVR-04 SHDVR-08 SHDVR-16 H.264 Network DVR Quick Setup Guide GUI Display with USB Mouse Control GUI DISPLAY WITH USB MOUSE CONTROL Connect USB Mouse Quick Menu Bar Main Menu FRONT AND REAR PANELS Front Panel Rear Panel BASIC OPERATION Live Page...
-
Page 2: Gui Display With Usb Mouse Control
1. GUI DISPLAY WITH USB MOUSE CONTROL 1.1 Connect USB Mouse Connect your USB mouse to one of the USB ports on the DVR front panel, and check if there’s a mouse icon ( ) on the screen, indicating the USB mouse is detected properly. -
Page 3: Quick Menu Bar
1.2 Quick Menu Bar Move to the arrow mark to extend the quick menu bar and show the five functions as follows: Quick Menu: Open Click to show the channel switch panel and select the channel you want. For details, please refer to “3.2 Quick Menu Bar” in the user manual. - Page 4 1.3 Main Menu Right-click anywhere on the screen to show the main menu as follows, and right-click again to exit. Main Menu Click to set the status display, QUICK START image settings, and date & time. Click to set the date display and DATE SETUP daylight saving.
-
Page 5: Main Menu Structure
Main Menu Structure QUICK START GENERAL CHANNEL TITLE EVENT STATUS DATE DISPLAY MOUSE SENSITIVITY PRIORITY (For Selected Model Only) RECORD CONFIG TIME SETUP DATE TIME DATE SETUP DATE INFO DISPLAY DATE OF MODE FORMAT DAYLIGHT DAYLIGHT SAVING SYSTEM TOOLS LANGUAGE ADMIN PASSWORD OPERATOR PASSWORD UPGRADE... - Page 6 DETECTION MOTION ALARM AREA ALERT EXT. ALERT INT. BUZZER KEY BUZZER VLOSS BUZZER MOTION BUZZER ALARM BUZZER HDD BUZZER ALARM DURATION (SEC) HDD NEARLY FULL (GB) NETWORK NETWORK SNTP E-MAIL DDNS DE-INTERLACE ADVANCED CONFIG DISPLAY (For Selected Models Only) FULL SCREEN DURATION QUAD SCREEN DURATION (For Selected Models Only) DWELL SCREEN DURATION...
-
Page 7: Front And Rear Panels
2. FRONT AND REAR PANELS 2.1 Front Panel LED Indicators HDD is reading or recording. An alarm is triggered. Timer recording is on. Under playback status. DVR is powered on. (▲) / (▼) / (◄) / (►) Press ▲... - Page 8 PLAY Press to playback the latest recorded data. SLOW In the playback mode, press to show slow playback. ZOOM Press to enlarge the picture of selected channel in the FRAME or FIELD recording mode. Press to display each channel in full screen one by one starting from CH1. When the last channel is displayed, it will repeat from CH1 again.
-
Page 9: Rear Panel
USB port There are two USB ports on the front panel, one for connecting your USB mouse for mouse control, and the other one for connecting your USB flash drive for video backup. It’s not allowed to have two USB mice or two USB flash drives connected on Note: the front panel. - Page 10 For example, the audio data from audio CH1 will be recorded with the video data from video CH1. AUDIO OUT Connect to a speaker with 1 mono audio output. Note: To know how many audio outputs your DVR supports, please refer to its specifications.
-
Page 11: Basic Operation
3. BASIC OPERATION 3.1 Live Page Icon Function Icon Function Icon Function Live audio Playback audio Audio channel channel (1~4) channel (1~4) Digital zoom on Digital zoom off Timer recording Network Internet LAN connected disconnected connected USB flash drive USB mouse No USB device / device connected... - Page 12 Event Recording When the motion detection or alarm is on, the motion icon ( ) or alarm icon ) shows on the screen for any motion or alarm event. Timer Recording When timer recording is on, you will see “ ”...
-
Page 13: Playback Control
Playback Control Fast Increase the speed for fast forward. Click Forward once to get 4X speed forward and click twice to get 8X speed, etc., and the maximum speed is 32X. Fast Rewind Increase the speed for fast rewind. Click once to get 4X speed rewind and click twice to get 8X speed, etc., and the maximum speed is 32X. -
Page 14: Event Search
Event Search Click to quickly search the recorded files by event lists: RECORD / MOTION / ALARM / TIME, or select FULL to show all the event logs. To quickly search the time you want, select “QUICK SEARCH”. Set the time range you want, and select “SUBMIT”... - Page 15 When the operator password is entered, will be shown on the status bar of the screen, and the main menu is NOT allowed to access. The operator user level needs to be set in the main menu “SYSTEM” “TOOLS”. To switch between these two user levels, click the current user level icon to switch to the key lock mode, and move your mouse to show the password input keypad, and enter the password of the user level you want.
-
Page 16: System Sources Reallocation
Note: To have the best image quality on your LCD monitor, make sure (1) the selected DVR VGA output resolution is supported by your monitor, and (2) the VGA output settings on both the LCD monitor and DVR are consistent. If the image is not positioned or scaled properly, please go to your monitor’s menu for adjustment. -
Page 17: Remote Surveillance
4. REMOTE SURVEILLANCE Remote access via different platforms is widely supported: ® ® ® A) For mobile platforms, iPhone , Android , Windows Mobile & BlackBerry available with the free program, EagleEyes, installed. ® ® ® B) For web browsers, Internet Explorer , Mozilla Firefox , Safari , Google Chrome... -
Page 18: Package Contents
5. PACKAGE CONTENTS SHDVR-04 / SHDVR-08 / SHDVR-16 One (1) 4CH DVR or SHDVR-08 or SHDVR-16 One (1) Remote Control (batteries included) One (1) Remote Control User Manual One (1) Power Adapter with Power Cord ... - Page 19 6. SECURITY CAMERAS 24 IR Waterproof Bullet Color Camera 42 IR Day & Night Effio-E Weatherproof Bullet Color Camera 650 TVL 500 TVL / 600 TVL / 700 TVL EIR24-3650 EIR42X-450VF / EIR42X-460VF / EIR42X-470VF 35 IR True Day & Night Weatherproof 36 IR Day &...
