Fast Ethernet PoE Switch
Fast Ethernet PoE Switch
8 Ports F
ast Ethernet Switch
8 Ports F
ast Ethernet Switch
Integrated 4 x Power Over Ethernet Ports
Integrated 4 x Power Over Ethernet Ports
"
Save Your Power Infrastructure Cost
"
Save Your Power Infrastructure Cost
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:886-2-7739-6888
FAX:886-2-7739-6887
sales@edimax.com.tw
Europe
Edimax Technology Europe B.V.
TEL:31-499-377344
FAX:31-499-372647
sales@edimax.nl
U.K.
Edimax Technology (UK) Ltd.
TEL:44-870-7740226
FAX:44-870-7740227
info@edimax.co.uk
Poland
Edimax Technology Poland
B.V. SP. Z O.O.
Tel: +48(22)-6079-480
Fax: +48(22)-6079-481
sales@edimax.nl
U.S.A.
Edimax Computer Company
TEL:1-408-496-1105
FAX:1-408-980-1530
sales@edimax.com
Latin America
TEL:1-786-845-8099
FAX:1-786-331-8490
sales_latinamerica@edimax.com
China
TEL:8610-6213-9288
FAX:8610-6213-9231
PoE allows power to be supplied to end devices, such as Wireless AP or
VoIP Phones, directly through the existing LAN cables. By supplying the
power end-span, you can centralize power distribution and backup without
the need to increase infrastructure.
Features :
• Conforms to IEEE 802.3 10BASE-T, IEEE802.3u 100BASE-TX and
IEEE 802.3x flow control standards
• Supports 10/100Mbps auto-detect half/full duplex
• Supports TP auto MDI/MDI-X function for auto TX/RX swap
• Supports 802.3x flow control pause packet for full duplex
PoE Features
• Supports IEEE 802.3af compliant
• Supports Power over Ethernet (PSE) on each PoE-TP port (End-Point)
• Full power(15.4w) support for per PoE-TP port
• Auto detect powered device and consumption levels
• Smart feature for PD on/off, PD detection, power level, PD status and
power feeding priority (X)
• Automatic Fault Detection (Over/Under Voltage & Current)
• Thermal shutdown protection (Tj > 150ºC)
Model NO.
Standards
No. of Ports
Transmission Mode
Transfer Rate
Flow Control
Switching Method
LEDs
Temperature / Humidity
Voltage / Frequency
Power Consumption
Physical Dimension
Safety
"
"
ES-5844P
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX
8*10/100 Mbps RJ-45 ports with 4 PoE ports
10/100Mbps, full/half-duplex (Auto-sensing)
10Mbps: 14880pps (64 Bytes Package)
100Mbps: 148800pps (64 Bytes Package)
IEEE 802.3x flow control for full-duplex
Back pressure in half-duplex operation mode
Store & forward
Power, Link/Act, Speed, PoE activity
0° to 50°C / 5% to 90%
AC 90-264V / 47-63Hz
65W,-48VD,1.35A
44(H) X 220(W) X 130.5(D) mm
FCC Part 15 Class A & CE Mark Approval
ES-5844P
