Contents Unpacking the TV / Accessory’s Installing / Removing the Base Stand Front / Right Side View and Controls Rear View and Sockets Remote Control Installing Batteries in the Remote Control Remote Control Operation Range Making Video and Audio Connections Connecting an AV Device with an HDMI Cable Turning the TV on for the First Time OSD Menu...
your new 24" LED TV. TOKEN Stand feet Remote Control TV set Adapter Power Cable Batteries User Manual Quick Start Guide Quick Start Guide User Manual...
The parts Stand feet Installation Place the TV face down on a soft and flat surface (blanket, foam, cloth, etc.) to prevent any damage to the TV. 1.Place the stand in position as shown,fix it M4 x 8 Note: Wall hanging height of the whole machine shall not exceed 2m. Machines need to be mounted on rigid surfaces such as cement or concrete.
Light Sockets POWER IN HDMI1 HDMI2 Note: The indicator light under the CI is on during when the battery is full. 12V LIGHTS LED lights To connect to power supply. POWER IN Headphone out To connect to the earphones. To connect to a computer or other devices with a VGA interface. GA / PC AUDIO IN TV Antenna To connect to aDVD player,Digital Set-Top-Box,or other devices with component(YPbPr)
Connect the end of the RF coaxial cable of the aerial and the rear bottom of your TV. Do not switch on with power switch until you have completed all the connections. Switch on with power switch. Light Sockets USB1/2 Common Interface POWER IN HDMI1...
Picture Mode Standard Contrast Brightness Saturation Tint PICTURE Sharpness Color Temperature Normal Aspect Ratio Auto Noise Reduction Middle Enter Enter Select Exit Exit Saturation Press the buttons to increase or decreases the saturation. Normal Normal Auto...
Sound Mode Standard 120Hz 500Hz 1.5KHz 5KHz SOUND 10KHz Balance Auto Volume Surround Sound SPDIF Mode Auto Enter Enter Select Exit Exit Sports Auto Volume This feature automatically adjusts the audio level when the TV is turned on.This function is activated by selecting”Off”. Surround Sound Turn on/off the surround sound function by selecting “Surround”...
Allows you to set up a variety of channel options. 1. Press the Menu button and then press the buttons to select the CHANNEL menu. and then press the to select 2. Press the buttons the following channel options and then p ress the button.
Page 17
DVB-T Mannual Tuning 1.Select DVB-T Mannual Tuning,press the button to confirm. ATV Mannual Tuning ATV Mannual Tuning Storage To 1 Press the buttons to change the numbered location of the found channel. NTSC. Frequency Unregistered...
Page 20
Programme Edit Use up/down keys to select program edit.Press to enter the menu. Delete Press the RED button to delete the highlighted channel, a red circle will appear next to the cahnnel name. Press the RED button again to confirm delete. Press the MENU to return to the main menu.
Lock Setting Lock Lock System Set Password Block Program Parental Guidance LOCK Key Lock Hotel Mode Enter Enter Select Exit Exit Lock System Lock System Set Password: If you had already changed the password,enter the current password. Block Program: This feature is available only for digital TV and the tuned-in channel must support it. Key Lock:Press the buttons to select the “Key Lock”...
Page 22
Lock Setting Lock System Press the up/down buttons to select the “Lock System” Lock System option and than press the right button to choose Set Password between ON and OFF. Block Program Parental Guidance LOCK Key Lock Hotel Mode Set Password Press the up/down buttons to select the “Set Password”...
Time Setting Time Clock Press the button to set date and time. Off Time Press the button to set off time. Sleep Timer The sleep timer automatically switches the TV to standby after the preset time has elapsed.The clock will be set automatically when receiving a digital signal.Time must be set before using Sleep Timer function. Press up/down buttons to select a period of time after which the TV automatically switches to standby mode: OFF/10/20/.../180/240 min and then press the button to confirm.The timer begains to count down from...
Option Setting Option OSD Language Allows you to select the on screen display menu language. Audio Languages Select the audio languages.The availability of this function depends on the tuned-in channel.(can only be selected in DTV mode) Subtitle Language Select the subtitle language.The availability of this function depends on the tuned-in channel.(can only be selected in DTV mode) Hearing Impaired Allows you to show more information in subtitles for the hearing-impaired in some programmes(can only be...
USB1/2 Common Interface Sat Dish Mini YPbPr Mini AV PC Audio STANDBY...
Page 26
Multimedia Operation Basic Operation 1.Press the SOURCE button on tje remote control to display the input source menu,select the USB source with the up/down buttons and press the button to enter the Multimedia menu below. Input Source Satellite YPbPr HDMI1 HDMI2 2.Press left/right buttons to select the files on the USB device(PHOTO,MUSIC,MOVIE,TEXT)to view or play.
1.Photo Photo viewing Press left/right buttons to select the option on the menu,and press the button to activate. Play: Play the photo. Prev./Next: Go to on a picture/Go to the next picture. Stop: Stop auto turning pages. Repeat: Select the repeat mode from Repeat All, Repeat One,Repeat None.
3.Movie Watch a film Press left/right buttons to select the option on the menu,and press the button to activate. Play: Play the movie. Retreat quickly. Fast forward. Prev./Next: Go to a video/Turn to the next video. Stop: Stop playing. Repeat: Select the repeat mode from Repeat All, Repeat One,Repeat None.
