Position Your Router; Connect Your Router - TP-Link Archer AX6000 User Manual

Chapter 2
2 1

Position Your Router

• The product should not be located in a place where it will be exposed to moisture or
excessive heat.
• Place the router in a location where it can be connected to multiple devices as well as
to a power source.
• Make sure the cables and power cord are safely placed out of the way so they do not
create a tripping hazard.
• The router can be placed on a shelf or desktop.
• Keep the router away from devices with strong electromagnetic interference, such as
Bluetooth devices, cordless phones and microwaves.
• Generally, the router is placed on a horizontal surface, such as on a shelf or desktop.
The device also can be mounted on the wall as shown in the following figure.
Note:
The diameter of the screw head, 5.207 mm<D<8.179 mm, and the distance of two screws is 114 mm. The screw that
project from the wall need around 5 mm based, and the length of the screw need to be at least 20 mm to withstand the
weight of the product.
2 2

Connect Your Router

Before you start:
• Turn off your modem, if any, and remove the backup battery if it has one.
• Place the router horizontally and extend the antennas to the maximum angle.
Follow the steps below to connect your router.
H
NOTE:
5.207＜D＜8.179mm
H＜3mm
Connect the Hardware
7
